8-55889-3
| 制造商 | TE Connectivity Ltd. |
| 描述 | Quick Disconnect Terminal 14-16AWG RCP 40.64mm Tin Loose Piece Quick Disconnect Receptacles - Insulated CONN RECEPT 14-16AWG 0.250 BLUE Quick Disconnect Terminal 14-16AWG RCP 40.64mm Tin Loose Piece Product Highlights:Proprietary Name = PIDG FASTONReceptacle Style = StraightWire Range = 1.25-2.00² [16-14] mm [AWG]Tab Fit = 6.35 x 0.81 mmInsulation Diameter = 4.83 [.190] Max. mm [in]Search Keywords:Terminals and Splices PRE-INS SEALED .25 RECPT 16-14 |
| 分类 |
商业参数
| 标准包装数量 | 500 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 无铅定义 | Not relevant for lead free process |
| RoHS/ELV合规状态 | RoHS compliant, ELV compliant | ||
电气参数
| 最大电压 | 1000 | 输出1频率 | 是 |
机械参数
| 颜色 | Blue | 表面处理 | Tin |
| 材料（通用） | Brass | 包装方式 | Bulk |
| 插片宽度 | 6.35 x 0.81 [.250 x .032] | 绝缘类型 | Fully Insulated Heat Shrink |
| 导线线规 | 14-16 AWG | 端接方式 | Crimp |
| 安装类型 | Free Hanging (In-Line) | 插片厚度 | 0.032" (0.81mm) |
| 端子类型 | Standard | 接触镀层 | Tin |
| 连接器样式 | Straight | 连接器用途 | 线缆 |
| 插入力 | Normal | 触头材料 | Brass |
| 总长度 | 1.600" (40.64mm) | 包装数量 | Loose Piece |
| 绝缘高度 | Insulation Support | 端接样式 | 母端 |
| 绝缘直径 | 4.83 [.190] Max. | 绝缘材料 - 类型 | Polyolefin |
| 按钮/帽颜色 | 蓝色 | 绝缘材料 - 材质 | No |
| 法兰上方插针尺寸 | 6.35 mm [ .25 in ] | 法兰下方引脚尺寸 | .81 mm [ .032 in ] |
| 线规或范围 - mm² | 1.25-2.00² [16-14] | 外径-未扩张 | 4.83 mm [ .19 in ] |
产品信息
| 连接器性别 | Female | 纹理 | Dimple without wire stop |
| 专有名称 | PIDG FASTON | 其他规格 | 否 |
环境参数
| 工作温度 | -55 – 125 | ||
相关型号
1-520935-2
te connectivity / amp
Conn Housing RCP 2 POS 15.11mm Crimp ST Cable Mount Positive Lock Connectors CONN RCPT HSG 2POS .250 RED Terminals HSG RECP.POSI LOCK&STD FAST250 Positive Lock Connectors Product Highlights:Receptacle HousingTab Fit = 6.35 x 0.81 mmLine = FASTON .250Number of Positions = 2Color = RedSearch Keywords:UL-310, terminals and splices, Quick Connect/Disconnect Tabs and Receptacles, Lighting Interconnection Products, DIN 46244, Series 110, PL 250 HOUSING REC RED 6/6 NYLON V2
1-480416-8
te connectivity / amp
Conn Housing RCP 1 POS Crimp ST Loose Piece FASTON Uninsulated Receptacles & Housings CONN RCPT HSG .250 1POS NATRL Headers & Wire Housings HSG 250 S CIR FAST 4/6 NAT FASTON Uninsulated Receptacles & Housings Product Highlights:HousingNumber of Circuits = 1Tab Fit = 6.35 mmNylon MaterialHousing Color = NaturalSearch Keywords:Quick Connect/Disconnect Tabs and Receptacles, relay connectors, fast-on, AMPIP, Blade Receptacle, Blade Tab, Packard Style Tab, E-SPRING FASTON 250 HSG NYLON NAT
170823-2
te connectivity / amp
Connector Accessories Insulation Sleeve Soft Vinyl Chloride Clear Loose Piece FASTON Uninsulated Receptacles & Housings CONN INSULATION SLEEVE .250 FASTON .250,Connector sleeve,natural Terminals INSU SLV 250 SER Connector Accessories Insulation Sleeve Soft Vinyl Chloride Clear Loose Piece Product Highlights:Insulation SleeveInsulation Diameter = 2.50 [.098] Max. mm [in]Soft Vinyl Chloride MaterialHousing Color = NaturalLine = FASTON .250Search Keywords:Quick Connect/Disconnect Tabs and Receptacles, relay connectors, fast-on, AMPIP, Blade Receptacle, Blade Tab, Packard Style Tab, E-SPRING CONNECTORSLEEVE,NATURAL TE Connectivity 24mm 压接端子盖
1-735075-0
te connectivity / amp
Conn Housing RCP 1 POS Crimp ST Loose Piece FASTON Uninsulated Receptacles & Housings CONN RCPT HSG .250 1POS NATRL Crimp, Faston, housing, 6.35mm, 1 way Terminals FASTON HSG FEM 6 35 1W Conn Housing RCP 1 POS Crimp ST Loose Piece Product Highlights:HousingNumber of Circuits = 1Tab Fit = 6.35 mmPolyamide 6.6 MaterialHousing Color = NaturalSearch Keywords:Quick Connect/Disconnect Tabs and Receptacles, relay connectors, fast-on, AMPIP, Blade Receptacle, Blade Tab, Packard Style Tab, E-SPRING HOUSING, FASTON, 6.35MM, 1WAY TE Connectivity AMP FASTON 系列 1 触点 尼龙 66 压接端子外壳 FASTON .258 SERIES (6.35 MM)
521229-1
te connectivity / amp
Conn Housing RCP 2 POS ST Headers & Wire Housings 250 FASTON RECPT HSG FASTON Uninsulated Receptacles & Housings CONN RCPT HSG .250 2POS NATRL 250 FASTON RECPT HSG 250 FASTON RECPT HSG Search Keywords:Quick Connect/Disconnect Tabs and Receptacles, relay connectors, fast-on, AMPIP, Blade Receptacle, Blade Tab, Packard Style Tab, E-SPRING PL 250 HOUSING RECEPTACLE NYLON 6/6
59827-1
