6-104068-6
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Shrouded Header HDR 80 POS 1.27mm Solder ST Thru-Hole Tube .050 X .100 AMPMODU System 50 CONN HEADER VERT .050 80POS 30AU Headers & Wire Housings 80 POS HDR VERT DUAL ROW Conn Shrouded Header HDR 80 POS 1.27mm Solder ST Thru-Hole Tube Product Highlights:Header AssemblyNumber of Positions = 80Number of Rows = DualShroudedVertical Mount AngleSearch Keywords:wire to wire, wire to board, IDC, latching, high density, co-planar, horizontal, pcb connectors, AMPMODU WIRE-BOARD CONN, HEADER, 80POS, 0.05IN TE Connectivity AMPMODU System 50 系列 1.27mm节距 80路 (2排) 直 PCB 针座, 焊接端接, 1A , 通孔 80 SYSTEM 50 HDR DRST SHRD |
| 分类 |
商业参数
| 商标名 | AMPMODU | 产品类别 | Headers & Wire Housings |
| 标准包装数量 | Rail / Tube | 工厂包装数量 | 9 |
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85366910 |
| 无铅定义 | Wave solder capable to 240°C, Wave solder capable to 260°C, Wave solder c | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | UL 94V-0 | ||
电气参数
| 量程（°/s） | :TE - AMPMODU System 50 Series | 额定电压 | 30 VAC |
| 供电电压 | 30 | 击穿电压 | 500 |
| 绝缘电阻 | 5,000 | 最小供电电压 | 30VAC |
机械参数
| 颜色 | Black | 深度 | 8.73 mm |
| 间距 | 1.27 mm | 高度 | 9.9 mm |
| 重量 | 0.003 | 包装方式 | Tube |
| 遮蔽类型 | Yes | 排间距 | 0.100" (2.54mm) |
| 端接方式 | Solder | 外壳颜色 | Black |
| 安装类型 | Vertical | 连接器类型 | Shrouded |
| 接触镀层 | Gold Over Nickel | 安装样式 | Thru Hole |
| 排数 | 2 | 高度（英寸） | 0.390" (9.91mm) |
| 触头材料 | Phosphor Bronze | 壳体材料 | Thermoplastic |
| 总长度 | 56.99 mm | 包装数量 | Tube |
| 端接样式 | Through Hole | 触点数 | 80 |
| 接触件端接 | :Through Hole Vertical | 位数 | 80 |
| 接触长度 - 配合 | 0.125" (3.18mm) | 端子柱长度 | 2.54 [0.100] |
| 接触镀层厚度 | 30µin (0.76µm) | 堆叠高度（配合） | 0.450" (11.43mm) |
产品信息
| 备注 | **Circuit identification feature omitted on 10 and 12 position headers. | 类型 | Shrouded Header |
| 连接器性别 | HDR | 系列 | AMPMODU System 50 |
| 制造商全称 | AMP | 产品子类型 | Header Assembly |
| 加载位置数 | All | ||
