点击放大查看

5-102398-5

制造商	TE Connectivity Ltd.
描述	Conn IDC Connector RCP 14 POS 2.54mm IDT ST Cable Mount .100 AMPMODU Headers, Housings & Contacts CONN RECEPT 14POS .100 IDC GOLD Headers & Wire Housings HSG DUAL 14P 26-22 WIRE-BOARD CONNECTOR RECEPTACLE 14POS, 2 14 AMPMODU MT ASSY DR.100CL SN
分类	连接器解决方案压接与焊接端子/接头压接端子（通用）

对参数有疑问？问 AI 助手

商业参数

商标名	AMPMODU	产品类别	Headers & Wire Housings
标准包装数量	Trays	工厂包装数量	170

合规参数

RoHS

Lead free / RoHS Compliant

海关税号

85366910

电气参数

最大额定电流

3 A

机械参数

颜色	Black	间距	2.54 mm
重量	0.002	包装方式	Tray
导线类型	Discrete or Ribbon Cable	导线线规	22-26 AWG
排间距	0.100" (2.54mm)	端接方式	IDT
触头类型	Female Socket	安装类型	Free Hanging (In-Line)
连接器类型	Receptacle	接触镀层	Gold Over Nickel
安装样式	Wire	排数	2
触头材料	Copper Alloy	壳体材料	Thermoplastic
电缆端接方式	IDC	端接样式	IDC
第一触头极性	Socket (Female)	触点数	14
位数	14	接触镀层厚度	30µin (0.76µm)

产品信息

类型	IDC Connector	连接器性别	RCP
系列	AMPMODU MT	产品特性	Closed End
产品子类型	Receptacles / Sockets - Housings

环境参数

工作温度

- 65 C to + 105 C

文档与媒体

PDF 文档

580372.pdf

在线文档

5-102398-5?RQPN=5-102398-5
