206306-5
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn CPC SKT 37 POS Crimp ST Panel Mount 37 Terminal 1 Port CPC Connectors CONN RCPT CPC 37POS PANEL MOUNT Standard Circular Connector 23-27 RECEPTACLE 206306-5 Conn CPC SKT 37 POS Crimp ST Panel Mount 37 Terminal 1 Port Product Highlights:ConnectorNumber of Positions = 37ReceptacleFor Use With Socket ContactsNot PreloadedSearch Keywords:Circular Plastic, Cabled Power, POWERBAND, coaxial, power, DIN 57627, III+ contacts, CMC, Metal Shell CPC, TETRASEAL, IEC IP 65, IEC IP 67, input/output, box to box, circular industrial, sealed, discrete wire, crimp, input/output, box to box, circular, Circular Plastic Connectors, CPC HOUSING, RECEPTACLE, CIRCULAR, 37WAY CPC RECEPT ASSEMBLY SIZE 23-37 |
| 分类 |
商业参数
| 商标名 | CPC Series 1 | 其他名称 | 2063065 |
| 产品类别 | Standard Circular Connector | 标准包装数量 | Bulk |
| 工厂包装数量 | 100 | ||
合规参数
| RoHS | Not applicable / RoHS Compliant | 海关税号 | 85369010 |
| 合规性 | No | 无铅定义 | Not relevant for lead free process |
| RoHS/ELV合规状态 | RoHS compliant, ELV compliant | 材料阻燃等级 | UL 94V-0 |
电气参数
| 通道数量 | 37 | ||
机械参数
| 密封型 | No | 重量 | 0.05 |
| 包装方式 | Bulk | 外壳尺寸 | 23 |
| 方向 | A | 外壳样式 | Receptacle |
| 端接方式 | Crimp | 螺纹尺寸 | 1-3/8 - 18 UNEF-2A |
| 触点尺寸 | 16 | 触头类型 | Crimp |
| 外壳表面处理 | :- | 外壳颜色 | Black |
| 安装类型 | Panel Mount | 连接器类型 | Receptacle for Female Contacts |
| 紧固类型 | Threaded | 安装样式 | Panel |
| 连接器样式 | Receptacle | 插入件材料 | Brass |
| 本体材料 | :Nylon (Polyamide) | 壳体材料 | Nylon |
| 面板安装类型 | Square Flange | 端接样式 | Wire |
| 第一触头极性 | Socket | 配接方向 | Keyed |
| 触点数 | 37 | 位数 | 37 |
| 外壳尺寸-插件 | All Plastic | 外壳材料及表面处理 | Thermoplastic |
| 螺纹/螺钉/孔尺寸 | 4-40 | 第二连接器安装特性 | Reverse |
产品信息
| 备注 | 5 Locating Key Arrangement. | 类型 | CPC |
| 连接器性别 | RCP | 系列 | Series 1 |
| 钥匙类型 | A | 预加载 | No |
| 产品子类型 | Connector | 其他规格 | Without |
| 适用产品/相关产品 | Socket Contacts | ||
