2-641260-1
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn DIP Socket SKT 8 POS 2.54mm Solder ST Thru-Hole Tube DIP Sockets CONN IC SOCKET 8POS DIP TIN IC Socket DIP8 2.54mm Diplomate IC & Component Sockets DIP-8 W/RET TAILS Conn DIP Socket SKT 8 POS 2.54mm Solder ST Thru-Hole Tube Product Highlights:DIP SocketNumber of Positions = 8Row-to-Row Spacing = 7.87 mmThru HoleMount Style = VerticalSearch Keywords:IC sockets, solderless, NIC, Network Interface Cards, PC Cards, EIA RS-415, MIL-S-83734, dual in-line IC package, Socket,DIP;8Pins;DualLeaf;Open;SolderTail;0.31In.;BerylliumCopper;Tin |
| 分类 |
商业参数
| 产品 | DIP / SIP Sockets | 产品类别 | IC & Component Sockets |
| 标准包装数量 | Bulk | 工厂包装数量 | 52 |
合规参数
| RoHS | Lead free / RoHS Compliant | 抗辐射加固 | No |
电气参数
| 接触电阻 | 30 mohm | 绝缘电阻 | 10000 Mohm |
机械参数
| 深度 | 10.01mm | 间距 | 2.54 mm |
| 宽度 | 5.33mm | 高度 | 5.33 mm |
| 长度 | 10.03mm | 底座类型 | DIP |
| 包装方式 | Tube | 排间距 | 7.62mm |
| 端接方式 | Solder | 触头类型 | Stamped |
| 安装类型 | Through Hole | 接触镀层 | Tin |
| 安装样式 | PCB | 引脚数 | 8 (2 x 4) |
| 排数 | 2 | 触头材料 | Beryllium Copper |
| 壳体材料 | Thermoplastic | 总长度 | 10.03 mm |
| 尺寸/外形 | 10.03 x 5.33 x 10.01mm | 端接样式 | Through Hole |
| 触点数 | 8 | 绝缘材料 - 类型 | Thermoplastic |
| 位数 | Not Required | 位置或引脚数（网格） | 8 (2 x 4) |
产品信息
| 类型 | DIP Socket | 连接器性别 | SKT |
| 系列 | Diplomate DL, AMP | 已删除 | Compliant |
| 产品特性 | Closed Frame | 主要用途 | Closed Frame |
| 输出配置 | Through Hole | ||
环境参数
| 工作温度 | +105°C | ||
