点击放大查看
175964-2
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Housing PL 8 POS 2.5mm Crimp ST MULTILOCK Connectors and Contacts 040 MLC II PLUG HSG ASSY 8P Housing, 2 row, 8 way, Rec, Multilock Headers & Wire Housings 8P MLC2 PLUG ASSY 04 Conn Housing PL 8 POS 2.5mm Crimp ST Product Highlights:HousingPlug040 Plug ConfigurationNumber of Rows = 2Number of Positions = 8Search Keywords:Wire-to-wire, Wire-to-board, Hybrid, High Density, I/O, WIRE-BOARD CONNECTOR, 8POS, 2.5MM Housing,2row,8way,Rec,Multilock TE Connectivity Multilock 040 II 系列 2 行 2.5mm 节距 8 路 直 公 PCB 壳体 |
| 分类 |
商业参数
| 产品类别 | Headers & Wire Housings | 标准包装数量 | Bulk |
| 工厂包装数量 | 100 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 海关税号 | 85411000 |
| 无铅定义 | Not relevant for lead free process | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
电气参数
| 开关功能 | Unlatched | ||
机械参数
| 颜色 | Black | 深度 | 23mm |
| 间距 | 2.5 mm | 宽度 | 14.1mm |
| 重量 | 0.003 | 包装方式 | Bulk |
| 排间距 | 0.205" (5.20mm) | 触头类型 | Female Socket |
| 第二连接器 | With | 外壳颜色 | Black |
| 安装类型 | Straight | 连接器类型 | Plug |
| 紧固类型 | Latch Lock | 安装样式 | Free Hanging |
| 排数 | 2 | 锁定特性 | Rear Lock |
| 壳体材料 | PBT | 面板安装类型 | Without |
| 触点数 | 8 | 接触件端接 | Crimp |
| 位数 | 8 | 连接器/触点类型 | 40 |
| 第二连接器加载位数 | 8 | ||
产品信息
| 备注 | Contacts Not Provided | 类型 | Housing |
| 连接器性别 | PL | 系列 | 040 Mark II |
| 编码、键控 | No | 产品子类型 | Housing |
| 连接类型 | Wire | 专有名称 | MULTILOCK |
| 适用产品/相关产品 | MULTILOCK Wire-to-Board Connector | ||
