1604060-4
| 制造商 | TE Connectivity Ltd. |
| 描述 | Conn Battery M 2 POS Crimp ST Cable Mount 2 Terminal 1 Port Bulk Power Connectors CONN PLUG 2POS 1/0AWG SILVER Power to the Board 350A 1/0AWG GRAY 40 Conn Battery M 2 POS Crimp ST Cable Mount 2 Terminal 1 Port Bulk Search Keywords:Power Wiring Devices, Battery Connectors & Battery Assemblies, Anderson plug, Anderson connectors, Anderson power, Anderson APP, Anderson powerpole, Power Series, FPR, Finger Probe Resistant |
| 分类 |
商业参数
| 产品类别 | Power to the Board | 标准包装数量 | Bulk |
| 工厂包装数量 | 1 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | ||
电气参数
| 额定电压 | 600V | 最大额定电流 | 350A |
机械参数
| 颜色 | Gray | 包装方式 | Bulk |
| 导线线规 | 1/0 AWG | 端接方式 | Crimp |
| 安装类型 | Cable Mount | 连接器类型 | Assembly (Kit), Non Gendered |
| 接触镀层 | Silver | 紧固类型 | Spring Retention |
| 排数 | 1 | 连接器样式 | 2 Poles |
| 触头材料 | Copper Alloy | 位数 | 2 |
| 绝缘材料 - 材质 | Polycarbonate (PC) | 线规或范围 - AWG | 1 |
产品信息
| 类型 | Battery | 连接器性别 | M |
环境参数
| 工作温度 | -20°C ~ 105°C | ||
文档与媒体
相关型号
1604050-4
te connectivity / amp
Conn Housing RCP 2 POS Crimp ST Power Connectors CONN HOUSING 2POS GRAY Power to the Board HSG SUB-ASY GRAY 350A Conn Housing RCP 2 POS Crimp ST Product Highlights:Housing350 AMP SeriesConnector Type = 2-Pole Battery ConnectorCurrent = 350 Amps.Housing Color = GraySearch Keywords:Power Wiring Devices, Battery Connectors & Battery Assemblies, Anderson plug, Anderson connectors, Anderson power, Anderson APP, Anderson powerpole, Power Series, FPR, Finger Probe Resistant 350A HOUSING SUB-ASSY,GRAY
1604055-1
te connectivity / amp
Contact PIN Crimp ST Cable Mount Loose Piece Power Connectors CONN TERM NON GENDERED 1/0AWG Power to the Board CONTACT 350A 1/0AWG Contact PIN Crimp ST Cable Mount Loose Piece Search Keywords:Power Wiring Devices, Battery Connectors & Battery Assemblies, Anderson plug, Anderson connectors, Anderson power, Anderson APP, Anderson powerpole, Power Series, FPR, Finger Probe Resistant 350 Series 0-1 AWG 350 A Crimp Contact Closed Barrel Power Connector CONTACT,350A,1/0 AWG,L/P
