点击放大查看
102681-3
| 制造商 | TE Connectivity Ltd. |
| 描述 | Connector Accessories 16 POS Cover Thermoplastic Black .100 AMPMODU Headers, Housings & Contacts CONN COVER FRONT 16POS POLAR.100 Cover,Latching,16Position,AMPMODU Cover; Latching; 16 Position; AMPMODU Headers & Wire Housings 16 AMPMODU MT COVER Connector Accessories 16 POS Cover Thermoplastic Black Product Highlights:AccessoryAccessory Type = CoverNumber of Positions = 16Cover Type = LatchingCover Side = FrontSearch Keywords:AMPMODU, NIC, Network Interface Cards, PC Cards, wire to board, wire to wire, TS 100 System, discrete wire, IEC 603-8, smt, signal, pcb connectors, MTE, MTE 16 AMPMODU MT COVER DR .100CL |
| 分类 |
商业参数
| 商标名 | AMPMODU | 产品类别 | Headers & Wire Housings |
| 标准包装数量 | Bulk | 工厂包装数量 | 1 |
合规参数
| RoHS | Lead free / RoHS Compliant | 标准 | RoHSCompliant,ELVCompliant |
| 无铅定义 | Not relevant for lead free process | RoHS/ELV合规状态 | RoHS compliant, ELV compliant |
| 材料阻燃等级 | Yes | ||
电气参数
| 额定电压 | 4 V | 开关功能 | Latched |
| 最大额定电流 | 3 A | ||
机械参数
| 颜色 | Black | 深度 | 19.05 mm |
| 间距 | 2.54 mm [ .100 in ] | 材料（通用） | Thermoplastic |
| 导线线规 | 30-20 | 外壳样式 | 锁闩 |
| 触点尺寸 | Front | 柱间距 | 2.54 [.100] |
| 安装类型 | Straight | 安装样式 | 低 |
| 排数 | 2 | 外形（宽 x 高） | Low |
| 触头材料 | Copper Alloy | 壳体材料 | Thermoplastic |
| 总长度 | 20.32 mm | 主要材料 | Interconnect |
| 连接器颜色 | Black | 触点数 | 16 |
| 位数 | 16 | 兼容外壳尺寸（如TM-700等） | 双排母端组件 |
产品信息
| 类型 | Cover | 系列 | MT |
| 覆盖范围 | Front | 产品特性 | Latch Lock |
| 盖类型 | Latching | 制造商全称 | AMP |
| 产品子类型 | Accessory | 附件类型 | Cap (Cover), Front |
| 射频系列/标准 | 102681 | 适用产品/相关产品 | Double Row Receptacle Assemblies |
环境参数
| 工作温度 | - 65 C to + 105 C | ||
