RDK-239
| 制造商 | |
| 描述 | REFERENCE DESIGN REPORT FOR A 150 W LLC HIGH-VOLTAGE DC-DC R BOARD EVAL FOR LCS702HG |
| 分类 |
商业参数
| 标准包装数量 | 1 | ||
电气参数
| 额定输出功率 | 150W | 输出电流 | 6.25A |
| 稳压器拓扑 | Resonant | 最小输入电压 | 24V |
机械参数
| 电路板厚度 | Fully Populated | ||
产品信息
| 内容 | Board | 主要用途 | DC/DC, Step Down |
| 输出及类型 | 1, Isolated | 使用的IC/零件 | LCS702HG |
