3214686

制造商	Phoenix Contact GmbH & Co. KG
描述	CONN TERM BLOCK DIN Rail Terminal Blocks PTTBS 1,5/S-PV PTTBS1,5/S-PV
分类	连接器解决方案接线端子DIN导轨接线端子

对参数有疑问？问 AI 助手

商业参数

商标名	CLIPLINE PT	其他名称	PTTBS 1 5/S-PV
标准包装数量	50

合规参数

RoHS

RoHS Compliant

材料阻燃等级

UL94 V-0

电气参数

电流 - UL	15A	UL电压	300V
电流 - IEC	16A	IEC电压	500V
额定电压	300 V, 600 V	最大额定电流	5 A, 15 A

机械参数

颜色	Gray	间距	1.5 mm
宽度	3.5 mm	高度	78 mm
导线线规	14	剥线长度（范围）	8mm
端子宽度	3.5mm	端接样式	Push In, Spring
触点数	2	位数	4
绝缘材料 - 材质	Polyamide (PA), Nylon	线规或范围 - AWG	14-26 AWG
线规或范围 - mm²	0.14-1.5mm²

产品信息

类型	Feed Through	系列	PT
层数	2; Connected
