点击放大查看
1762208
| 制造商 | Phoenix Contact GmbH & Co. KG |
| 描述 | Pluggable Terminal Blocks 5.08mm PRE-PRINTED 3P 1-3 LEFT TO RIGHT Conn Terminal Block F 3 POS 5.08mm Screw RA Cable Mount 12A TERM BLOCK PLUG 3POS STR 5.08MM Plug MSTB 2,5/ 3-ST-5,08 BD: 1-3 Conn;TermBlk;Plug;Screw;3;5.08mm;Green;12A;250V;Pre-Printed Phoenix Contact COMBICON MSTB 系列 5.08mm 节距 3 路 母 绿色 直 插头, 插入式, 螺钉端接 |
| 分类 |
商业参数
| 产品 | Plugs | 商标名 | COMBICON Control |
| 产品类别 | Pluggable Terminal Blocks | 标准包装数量 | 50 |
| 工厂包装数量 | 50 | ||
合规参数
| RoHS | Lead free / RoHS Compliant | 欧盟RoHS | Compliant |
电气参数
| 电流 | 15A | 电压 | 300V |
| 额定电压 | 250 V | 最大额定电流 | 12 A |
| 最小输入电压 | 320V | ||
机械参数
| 颜色 | Green | 间距 | 0.200" (5.08mm) |
| 宽度 | 10.16mm | 重量 | 0.190479 oz |
| 材料（通用） | 聚酰胺 | 包装方式 | Bulk |
| 导线线规 | 12-30 AWG | 方向 | 直 |
| 端接方式 | Screw | 安装类型 | Cable Mount |
| 连接器类型 | 母座 | 接触镀层 | Tin |
| 排数 | 1 | 插头进线方向 | 180° |
| 壳体材料 | Polyamide | 端接排数 | 螺钉 |
| 端接样式 | Screw | 触点数 | 3 |
| 位数 | 3 | 接线端子类型 | Plug, Female Sockets |
| 线规或范围 - AWG | 24-12 | ||
产品信息
| 类型 | Terminal Block | 连接器性别 | F |
| 系列 | MSTB | 产品特性 | Positions Stamped, Retention Latches (Non-Wire Side) |
| 层数 | 1 | 每层位数 | 3 |
