点击放大查看

OA180APL-11-1TB

制造商	Orion Fans
描述	Fans Fan 180x65 115VAC Ball Term 400cfm FAN AC 180X65 115V 405CFM Fan; 180mm x 65mm;115 V; 450 CFM; 70 W; AC; 60 dB; Ball Bearing Fans Fan AC 180x65mm 115V Ball 405CFM Terminal AC Fan Ball Bearing 115V 70W 50Hz/60Hz 3300RPM 405CFM 60dB Flange Mount Fan;AC;115V;50/60Hz;180x180x65mm;Sq;405CFM;60/70W;60dBA;Terminals
分类	硬件与散热解决方案直流风扇鼓风机

对参数有疑问？问 AI 助手

商业参数

产品	Fans	产品类别	Fans
标准包装数量	1

合规参数

RoHS

Compliant

电气参数

噪声	60 dB	转速	2750 RPM to 3300 RPM
频率	50/60Hz	功率（瓦）	70W
额定功率	60 W to 70 W	电压范围	60 ~ 130VAC
额定电压	115VAC	供电电压	115 V
最大额定电流	0.48A

机械参数

RPM	3300 RPM	尺寸	7.1x2.6(180x65)In.(mm)
风量	405.0 CFM (11.47m³/min)	风扇类型	Tubeaxial
材料（通用）	DiecastAluminum	端接方式	2 Terminals
轴承类型	Ball	静压	0.830 in H2O (206.7 Pa)
壳体材料	Aluminum	刀片材料	Polybutylene Terephthalate (PBT)
框架材料	Aluminum	主要材料	Fans
尺寸/外形	Square - 180mm L x 180mm H x 65mm W	端接样式	Terminals
风扇附件类型	7.1x2.6(180x65)In.(mm)	总体尺寸	7.1x7.1x2.6In.

产品信息

类型	Square	系列	OA180APL
功能	AC	方向	IntakeoverStruts
开关类型	AC	制造商全称	OA180APLSeries
配置	Square

环境参数

额定寿命	60000 hrs @ 40°C	工作温度	-4 ~ 176°F (-20 ~ 80°C)
自然散热热阻	405CFM	结工作温度	80°C
