0009503162

制造商	Molex, LLC
描述	Conn Housing RCP 16 POS 3.96mm Crimp ST Cable Mount CONN TERM HSG W/RAMP 16POS
分类	连接器解决方案矩形连接器FPC/FFC矩形连接器

对参数有疑问？问 AI 助手

商业参数

交货时间	45 Days	子类别	Connector Discrete Wire Housing
标准包装数量	500

合规参数

RoHS

Lead free / RoHS Compliant

欧盟RoHS

Compliant

机械参数

颜色	Natural	深度	15.88
间距	0.156" (3.96mm)	高度	6.4
包装方式	Bulk	触头类型	Non Gendered
外壳颜色	Natural	安装类型	Straight
连接器类型	Receptacle	紧固类型	Locking Ramp
排数	1	壳体材料	Nylon
总长度	35.56	触点数	16
接触件端接	Crimp	位数	16

产品信息

备注	Contacts Not Provided	类型	Housing
连接器性别	RCP	产品特性	Position 2, 15 Molded Closed
行业别名	09-50-3162, 09503162, 9503162

环境参数

工作温度

文档与媒体

PDF 文档

Datasheets

PDF 文档

PCN Design/Specification

PDF 文档

datasheet
