点击放大查看
87759-0414
| 制造商 | Molex, LLC |
| 描述 | CONN HEADER 4POS DL 2MM VERT SMD Headers & Wire Housings MGRID 4CKT HDR DUAL ROW SMT Conn Unshrouded Header HDR 4 POS 2mm Solder ST SMD Tray HEADER, 2MM, SMD, VERT, 4WAY |
| 分类 |
商业参数
| 商标名 | Milli-Grid | 零件号别名 | 0877590414 |
| 产品类别 | Headers & Wire Housings | 标准包装数量 | 2,000 |
| 工厂包装数量 | 6000 | ||
合规参数
| RoHS | RoHS Compliant | SVHC | :No SVHC (20-Jun-2013) |
| 海关税号 | 85369010 | 材料阻燃等级 | :94V-0 |
电气参数
| 额定电压 | 125 V | 击穿电压 | :125V |
| 最大额定电流 | 2 A | 最大触点电流 | :2A |
机械参数
| 颜色 | Black | 间距 | 0.079" (2.00mm) |
| 重量 | 0.00001 | 包装方式 | Tube |
| 排间距 | 0.079" (2.00mm) | 端接方式 | Solder |
| 触头类型 | Male Pin | 安装类型 | Surface Mount |
| 连接器类型 | Header, Unshrouded | 接触镀层 | Gold |
| 排数 | 2 | 触头材料 | :Phosphor Bronze |
| 端接样式 | SMD | 连接器颜色 | :Black |
| 触点数 | :4 | 接触件端接 | :Solder |
| 位数 | 4 | 接触长度 - 配合 | 0.150" (3.81mm) |
| 接触镀层厚度 | 15µin (0.38µm) | ||
产品信息
| 类型 | Unshrouded | 连接器性别 | :Header |
| 系列 | 87759 | 产品子类型 | Headers |
| 加载位置数 | All | ||
环境参数
| 插拔次数 | :100 | 工作温度 | :+105°C |
