1NT1-5

制造商	Honeywell International Inc.
描述	Toggle Switches SPDT (ON)-OFF Screw Term MICRO SWITCH™ Electromechanical Switches, MICRO SWITCH™ Toggle Switches SWITCH TOGGLE SPDT 10A 125V Switch; Toggle; Screw Terminals; Standard Lever; 3 Position; SPDT; 10 Amps Switch Toggle (ON) OFF ON SPDT Round Lever Screw 15A 277VAC 250VDC Panel Mount with Threads Switch Toggle (ON) OFF ON SPDT Round Lever Screw 15A 277VAC 250VDC Panel Mount with Threads Product Highlights:Completely sealed switching chamberNEMA 3, 3R, 4, and 13UL recognized, File E12252, Vol. 1, Section 44CSA certified, File LR4442CE approvedPotential Applications:Aerial lifts, scissor lifts, truck mounted tele-handlers, and cranesConstruction equipmentAgriculture equipmentMaterial-handling equipmentFactory-floor control unitsMachine tool equipment manufacturers Switch;Toggle;ScrewTerminals;StandardLever;3Position;SPDT;10Amps NT Series Toggle Switch, 1 pole, 3 position, Screw terminal, Standard Lever
分类	开关拨动开关标准拨动开关

对参数有疑问？问 AI 助手

商业参数

产品类别

Toggle Switches

标准包装数量

RoHS

RoHS Compliant

认证机构标志

L192: 10 A-125, 250, 277 Vac; 1/4 Hp-125 Vac; 1/2 Hp-250, 277 Vac; 3 A-125 Vac "

电路	SPDT	操作方式	125873
额定电压	277 V	开关功能	On-Off-Mom
额定交流电压	277V VAC	最大额定电流	15 A
开关功能/额定值	ON OFF ON	直流击穿电压（标称）	250V VDC
最大持续工作电压（MCOV）	0.5 A at 250 Vdc\|0.75 A at 115 Vdc\|0.5 A to 10 A at 0.5 Vac to 7 Vac\|0.5 A to 15

备注	One-pole transportation grade toggle	类型	Toggle
系列	NT	产品特性	Sealed
电路结构	SPDT	UNSPSC代码	30211908
照明类型	Non-Illuminated	UNSPSC商品	30211908 Toggle switches

密封等级	Sealed	防护等级	IP67/68 - Dust Tight, Waterproof
工作温度	-40°C ~ 71°C	结工作温度	71C
