点击放大查看

70-IAC5

制造商	Grayhill, Inc.
描述	OptoCoupler Transistor-Out 1-CH 5-Pin I/O Module Relays Input Module 140VAC 8mA 4000Vrms Thru-Hole INPUT MODULE AC 8MA 5VDC Module; Input; 120; 8; 22 Kilohms (Nom.); 20 ms; 20 ms; -40 to ? degC Module;Input;120;8;22Kilohms(Nom.);20ms;20ms 70 Series 140 V 8 mA Yellow Color Standard Style AC Input Module
分类	工业电源组件和继电器固态继电器固态继电器

对参数有疑问？问 AI 助手

商业参数

交货时间	21 Days	子类别	I/O Module
标准包装数量	Bulk

合规参数

RoHS	Contains lead / RoHS non-compliant	欧盟RoHS	RoHS Not Applicable
标准	UL,CSA,CE,TUVCertified	认证机构标志	CE/CSA/TUV/UL

电气参数

输入端	90to140VAC	输入类型	AC
输入范围	90to140VAC	释放时间	20ms
开启时间	20ms	额定电压	90VAC
输出电流	10mA	关断延迟时间	20ms
供电电压	5VDC	通道数量	1
输入电阻	22Kiloohms(Nom.)	接收电流	8mA
隔离电压	4000Vrms	输入偏置电流	10mA
最大额定电流	50mA	最小输入电压	90 ~ 140VAC (120VAC Nom)
典型输入电压	120VAC	数字供电电压	5VDC (3 ~ 6VDC)
输入偏置电流（最大）	8mA	最大持续工作电压（MCOV）	120

机械参数

颜色	Yellow	安装类型	Screw
端子类型	PC Pins	主要材料	Control

产品信息

类型	AC	样式	Standard
系列	70	产品特性	Hold Down Screw
技术	Solid State	主要用途	Hold Down Screw
连接类型	BoardMount	模块/板类型	Input Module

环境参数

工作温度

-40to+100°C

文档与媒体

PDF 文档

IO_Mod_AC_Input.pdf

PDF 文档

L-15-16.pdf
