AC6100NM
| 制造商 | ebm-papst Mulfingen GmbH & Co. KG |
| 描述 | AC Fan Ball Bearing 115V/230V 14W 50Hz/60Hz 2850RPM 206CFM 52dB Flange Mount FAN AXIAL 178X51MM 115/230VAC Blowers ACMAXX TUBEAXIAL FAN FAN, AXIAL, 172mm x 51mm, 230V |
| 分类 |
商业参数
| 其他名称 | 381-2288 | 标准包装数量 | 25 |
合规参数
| 海关税号 | 00000000 | ||
电气参数
| 噪声 | 52 dB(A) | 功率（瓦） | 14.0W |
| 额定电压 | 85 ~ 265VAC | 供电电压 | :230V AC |
| 供电类型 | :Wire Leaded | ||
机械参数
| RPM | 2850 RPM | 重量 | 1.7 lbs (771.1g) |
| 风量 | 206.0 CFM (5.83m³/min) | 直径 | :172mm |
| 风扇类型 | Tubeaxial | 流量 (CFM) | :350m /h |
| 端接方式 | 2 Wire Leads | 轴承类型 | Ball |
| 刀片材料 | Polyamide (PA), Fiberglass Reinforced | 框架材料 | Polyamide (PA), Fiberglass Reinforced |
| 尺寸/外形 | Rectangular/Rounded - 165mm L x 178mm H x 51mm W | ||
产品信息
| 功能 | :AC | ||
环境参数
| 额定寿命 | 80000 hrs @ 40°C | 工作温度 | -4 ~ 158°F (-20 ~ 70°C) |
