点击放大查看
PXM7012/03S/ST
| 制造商 | |
| 描述 | CONN RCPT PNL MNT 3POS W/SKTS Standard Circular Connector Metal 3pos Female Panel Mnt screw term CIRCULAR CONN, RECEPTACLE, 3 WAY, PANEL Connector;PanelMount;3-Pole;Female/Socket;ScrewTerm.;Metal;7000Series Panel-mount connector 3, PXM7012/03S/ST, Bulgin Bulgin Buccaneer 系列 7000 3路 面板安装 直向 连接器 插头 , 母触点, 快速连接接合 |
| 分类 |
商业参数
| 其他名称 | 708-1842 | 标准包装数量 | 1 |
合规参数
| RoHS | RoHS Compliant | 海关税号 | 85369010 |
电气参数
| 额定电压 | 600V | 最大额定电流 | 25A |
| 连接器类型 - 电压输入 | Female | ||
机械参数
| 重量 | 0.156 | 包装方式 | Bulk |
| 方向 | Keyed | 外壳样式 | Receptacle |
| 端接方式 | Screw | 安装类型 | Panel Mount, Bulkhead - Rear Side Nut |
| 外壳镀层 | Nickel | 连接器类型 | Receptacle, Female Sockets |
| 接触镀层 | Nickel | 紧固类型 | Bayonet Lock |
| 安装样式 | Panel | 外壳材料（壳体） | Zinc Alloy |
| 插入角度 | :- | 本体材料 | :Zinc |
| 触头材料 | Brass | 端接样式 | Screw |
| 第一触头极性 | Socket (Female) | 触点数 | 3 |
| 接触件端接 | :Screw | 位数 | 3 |
| 外壳尺寸-插件 | :(Not Available) | 外壳材料及表面处理 | Zinc Alloy, Nickel Plated |
| 第一连接器安装类型 | :Panel | ||
产品信息
| 连接器性别 | :Receptacle | 系列 | 7000 |
| 产品特性 | Shielded | 产品子类型 | Connectors |
环境参数
| 防护等级 | IP66/68/69K - Dust Tight, Water Resistant, Waterproof | 工作温度 | -40°C ~ 120°C |
