商业参数
| 其他名称 | 708-1288 | 标准包装数量 | 10 |
合规参数
| RoHS | Compliant | SVHC | :No SVHC (19-Dec-2012) |
| 海关税号 | 85366990 | 认证机构 | :IEEE, UL |
| 材料阻燃等级 | :UL94V-0 | ||
电气参数
| 额定电压 | :30V | 极数 | :6 |
| 工作电压 | :30V | 最大额定电流 | :1A |
机械参数
| 颜色 | Black | 长度 | 0.48' (145.6mm) |
| 重量 | 0.024 | 屏蔽 | Shielded |
| 电缆类型 | Round | 连接器类型 | IEEE 1394 (Firewire) 6 pos Receptacle to Rectangular 7 pos Plug |
| 接触镀层 | :Nickel | 触头材料 | :Copper |
| 连接器颜色 | Black | 触点数 | :6 |
| 接触件端接 | :Crimp | 第一连接器安装类型 | :Panel |
产品信息
| 用途 | Industrial Environments - IP68 | 连接器性别 | Female |
| 系列 | :Buccaneer | ||
环境参数
| 插拔次数 | :1000 | NEMA 机架尺寸 | :IP68 |
