D15P13A4GL00LF
| 制造商 | Amphenol Corporation |
| 描述 | 15 Position D-Sub Plug, Male Pins Connector, Through Hole, Right Angle Solder Amphenol FCI Delta D 系列 2.74mm 节距 15 路 直角 通孔安装 PCB D-sub 连接器 插头 |
电气参数
| 额定电压 | 300 V 交流 | 最大额定电流 | 5A |
机械参数
| 深度 | 20.75mm | 间距 | 2.74mm |
| 宽度 | 13.48mm | 长度 | 39.14mm |
| 方向 | 直角 | 安装类型 | 通孔 |
| 连接器类型 | 公插 | 接触镀层 | 金镀镍 |
| 尺寸/外形 | 39.14 x 13.48 x 20.75mm | 触点数 | 15 |
产品信息
| 系列 | Delta D | 其他规格 | 4-40 UNC 螺钉锁 |
