TLF9UAH tlf9uah 系列型号列表/参数/数据手册

TAIYO YUDEN的TLF9UAH系列是一对双共模电感，专为电子电路中的有效噪声滤波设计。这些组件特别适用于需要抑制电磁干扰（EMI）并降低电源和信号线噪声的场景。如果您正在开发工业控制系统、医疗设备或其他对EMI合规性至关重要的应用，这些共模电感将是理想的选择。

值得注意的是，它们能够有效地处理高频噪声。当工程师需要从电源中滤除开关噪声或将信号净化以供敏感电路使用时，往往会选用这种电感。TLF9UAH系列以其紧凑的设计而闻名，这使得它们可以轻松集成到紧凑的PCB布局中而不影响性能。

另一个实用的观察是，这些共模电感通常与差模电感配合使用，以提供全面的噪声抑制策略。这种双重方法确保同时处理共模和差模噪声，从而实现更清洁、更可靠的电路运行。总体而言，TLF9UAH系列是通过有效的噪声管理增强电子设计的稳健性和可靠性的理想选择。

制造商零件编号	库存	价格	产品类别	其他名称	标准包装数量	电流	电感量	滤波器类型	包装方式	高度（最大）	安装类型	封装形式	尺寸/外形	线路数量	工作温度	直流电阻（DCR）	产品	RoHS	容差	最大额定电流	初始电阻（最小）	宽度	端接样式	类型	系列	制造商	输入电阻	电源电流（禁用）（最大）	尺寸	端部尺寸（如SMD/SMT、14mm等）	本体尺寸	产品子类型	结工作温度	标准包装规格
TLF9UAH202WR54K1 COMMON MODE CHOKE COIL 2.0MH BOX コモンモードフィルタ /チョーク COMMON MODE CHK COIL 2.0MH CHOKE COMMON MODE 2000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 2.0MH taiyo yuden	10	500: ¥1.9251	-	587-2796	500	540mA	2 mH	Power Line	Bulk	12 mm	Through Hole	Bulk	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	1 Ohm Max	Common Mode Filters	RoHS 認証	- 10 %, + 100 %	540 mA	1 Ohms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	Taiyo Yuden	1 Ohms	0.54 A	15 mm W x 17 mm L x 12 mm H	Radial	17 mm	Common Mode Filters	- 25 C to + 105 C	-
TLF9UAH502WR32K1 COMMON MODE CHOKE COIL 5.0MH BOX CHOKE COMMON MODE 5000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 5.0MH Common Mode Chokes Dual 5mH 1kHz 320mA Thru-Hole Bulk taiyo yuden	898	1: ¥5.78	-	587-2798	500	320mA	5mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	2.5 Ohm Max	Common Mode Filters	RoHS Compliant	- 10 %, + 100 %	320 mA	2.5 Ohms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	-	-	-	-	-	-	-	-	-
TLF9UAH102W0R8K1 COMMON MODE CHOKE COIL 1.0MH BOX CHOKE COMMON MODE 1000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 1.0MH Common Mode Chokes Dual 1mH 1kHz 800mA Thru-Hole Bulk taiyo yuden	342	1: ¥5.78	-	587-2794	500	800mA	1mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	500 mOhm Max	Common Mode Filters	RoHS Compliant	- 10 %, + 100 %	800 mA	500 mOhms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	-	-	-	-	-	-	-	-	-
TLF9UAH103WR23K1 COMMON MODE CHOKE COIL 10MH BOX コモンモードフィルタ /チョーク COMMON MODE CHK COIL 10MH CHOKE COMMON MODE 10000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 10MH taiyo yuden	4689	1: ¥5.78	-	587-2800	500	230mA	10 mH	Power Line	Bulk	12 mm	Through Hole	Bulk	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	4.5 Ohm Max	Common Mode Filters	RoHS 認証	- 10 %, + 100 %	230 mA	4.5 Ohms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	Taiyo Yuden	4.5 Ohms	0.23 A	15 mm W x 17 mm L x 12 mm H	Radial	17 mm	Common Mode Filters	- 25 C to + 105 C	-
TLF9UAH153W0R2K1 COMMON MODE CHOKE COIL 15MH BOX CHOKE COMMON MODE 15000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 15MH taiyo yuden	1200	1: ¥2.6724	-	587-2795	500	200mA	15mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	-	Common Mode Filters	RoHS Compliant	- 10 %, + 100 %	200 mA	5 Ohms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	-	-	-	-	-	-	-	-	-
TLF9UAH302WR42K1 COMMON MODE CHOKE COIL 3.0MH BOX CHOKE COMMON MODE 3000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 3.0MH taiyo yuden	2290	1: ¥5.78	-	587-2797	500	420mA	3mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	1.5 Ohm Max	Common Mode Filters	RoHS Compliant	- 10 %, + 100 %	420 mA	1.5 Ohms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	-	-	-	-	-	-	-	-	-
TLF9UAH802WR25K1 COMMON MODE CHOKE COIL 8.0MH BOX CHOKE COMMON MODE 8000UH Common Mode Filters / Chokes COMMON MODE CHK COIL 8.0MH taiyo yuden	10	500: ¥1.9251	-	587-2799	500	250mA	8mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	4 Ohm Max	Common Mode Filters	RoHS Compliant	- 10 %, + 100 %	250 mA	4 Ohms	15 mm	Radial	Leaded Common Mode Choke Coils for AC Lines	TLF	-	-	-	-	-	-	-	-	-
TLF9UAH102W0R8 CHOKE COMMON MODE 1000UH Taiyo Yuden	10	1: ¥3.468	-	LM TLF 9UAH102W0R8	500	800mA	1mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	500 mOhm Max	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	500
TLF9UAH103WR23 CHOKE COMMON MODE 10000UH Taiyo Yuden	0		-	LM TLF 9UAH103WR23	500	230mA	10mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	4.5 Ohm Max	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TLF9UAH202WR54 CHOKE COMMON MODE 2000UH Taiyo Yuden	10	1: ¥8.821	-	LM TLF 9UAH202WR54	500	540mA	2mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	1 Ohm Max	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TLF9UAH302WR42 CHOKE COMMON MODE 3000UH Taiyo Yuden	0		-	LM TLF 9UAH302WR42	500	420mA	3mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	1.5 Ohm Max	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
TLF9UAH502WR32 CHOKE COMMON MODE 5000UH Taiyo Yuden	10	1: ¥3.468	-	LM TLF 9UAH502WR32	500	320mA	5mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	2.5 Ohm Max	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	500
TLF9UAH802WR25 CHOKE COMMON MODE 8000UH Taiyo Yuden	0		-	LM TLF 9UAH802WR25	500	250mA	8mH	Power Line	Bulk	0.472" (12.00mm)	Through Hole	Vertical, 4 PC Pin	0.669" L x 0.591" W (17.00mm x 15.00mm)	2	-25°C ~ 105°C	4 Ohm Max	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
