cigen-SCE238C

SCE238C valves & tap 系列

Emerson Electric Co.

Emerson Electric Co.

Two-port normally closed solenoid valves for various voltage applications

系列图片（8 张）

常见问答

内容由 AI 生成，仅供参考

加载中...

03

SCE238C valves & tap - 型号列表

共 12 个型号

制造商零件编号	库存	价格	产品类别	操作方式	供电电压	连接器阻抗	并联饱和电流	预行程	基体材料	闭合力	孔径	螺纹长度	插入力	最大压力	节流孔径	主要材料	适用端子尺寸	第一连接器极性	最大工作高度	螺纹/螺钉/孔尺寸	类型	系列	时序	应用领域	应用	连接性	端口数	连接方式	其他规格	工作温度
2 SCE238C002 24/50 Asco Numatics Solenoid Valve SCE238C002 24/50, 2 port , NC, 24V ac, 01-Febin Asco Numatics 电磁阀, 2 端口, NC, 24 V 交流, 1/2in Emerson Electric Co.	0		-	Pilot	24 V ac	1/2in	2.4m³/h	NC	Brass	90ms	12mm	G	母	10bar	12mm	黄铜	1/2in	Female	30ms	G	2/2	238	30ms	空气、惰性气体、水	Air, Inert Gas, Water	1/2 in G 内螺纹	2	1/2 in G Female	NC	+60°C
2 SCE238C002 110/50 Asco Numatics Solenoid Valve SCE238C002 110/50, 2 port , NC, 115V ac, 01-Febin Asco Numatics 电磁阀, 2 端口, NC, 115 V 交流, 1/2in Emerson Electric Co.	0		-	Pilot	115 V ac	1/2in	2.4m³/h	NC	Brass	90ms	12mm	G	母	10bar	12mm	黄铜	1/2in	Female	30ms	G	2/2	238	30ms	空气、惰性气体、水	Air, Inert Gas, Water	1/2 in G 内螺纹	2	1/2 in G Female	NC	+60°C
2 SCE238C005 24/50 Asco Numatics Solenoid Valve SCE238C005 24/50, 2 port , NC, 24V ac, 1in Asco Numatics 电磁阀, 2 端口, NC, 24 V 交流, 1in Emerson Electric Co.	0		-	Pilot	24 V ac	1in	9.9m³/h	NC	Brass	200ms	25mm	G	母	10bar	25mm	黄铜	1in	Female	70ms	G	2/2	238	70ms	空气、惰性气体、水	Air, Inert Gas, Water	1 in G 内螺纹	2	1 in G Female	NC	+60°C
2 SCE238C004 24 DC Asco Numatics Solenoid Valve SCE238C004 24 DC, 2 port , NC, 24V dc, 03-Aprin Asco Numatics 电磁阀, 2 端口, NC, 24 V 直流, 3/4in Emerson Electric Co.	0		-	Pilot	24 V dc	3/4in	6.6m³/h	NC	Brass	110ms	20mm	G	母	10bar	20mm	黄铜	3/4in	Female	55ms	G	2/2	238	55ms	空气、惰性气体、水	Air, Inert Gas, Water	3/4 in G 内螺纹	2	3/4 in G Female	NC	+60°C
2 SCE238C004 24/50 Asco Numatics Solenoid Valve SCE238C004 24/50, 2 port , NC, 24V ac, 03-Aprin Asco Numatics 电磁阀, 2 端口, NC, 24 V 交流, 3/4in Emerson Electric Co.	0		-	Pilot	24 V ac	3/4in	6.6m³/h	NC	Brass	110ms	20mm	G	母	10bar	20mm	黄铜	3/4in	Female	55ms	G	2/2	238	55ms	空气、惰性气体、水	Air, Inert Gas, Water	3/4 in G 内螺纹	2	3/4 in G Female	NC	+60°C
2 SCE238C002 230/50 Asco Numatics Solenoid Valve SCE238C002 230/50, 2 port , NC, 230V ac, 01-Febin Asco Numatics 电磁阀, 2 端口, NC, 230 V 交流, 1/2in Emerson Electric Co.	0		-	Pilot	230 V ac	1/2in	2.4m³/h	NC	Brass	90ms	12mm	G	母	10bar	12mm	黄铜	1/2in	Female	30ms	G	2/2	238	30ms	空气、惰性气体、水	Air, Inert Gas, Water	1/2 in G 内螺纹	2	1/2 in G Female	NC	+60°C
2 SCE238C002 24 DC Asco Numatics Solenoid Valve SCE238C002 24 DC, 2 port , NC, 24V dc, 01-Febin Asco Numatics 电磁阀, 2 端口, NC, 24 V 直流, 1/2in Emerson Electric Co.	0		-	Pilot	24 V dc	1/2in	2.4m³/h	NC	Brass	90ms	12mm	G	母	10bar	12mm	黄铜	1/2in	Female	30ms	G	2/2	238	30ms	空气、惰性气体、水	Air, Inert Gas, Water	1/2 in G 内螺纹	2	1/2 in G Female	NC	+60°C
2 SCE238C004 230/50 Asco Numatics Solenoid Valve SCE238C004 230/50, 2 port , NC, 230V ac, 03-Aprin Asco Numatics 电磁阀, 2 端口, NC, 230 V 交流, 3/4in Emerson Electric Co.	0		-	Pilot	230 V ac	3/4in	6.6m³/h	NC	Brass	110ms	20mm	G	母	10bar	20mm	黄铜	3/4in	Female	55ms	G	2/2	238	55ms	空气、惰性气体、水	Air, Inert Gas, Water	3/4 in G 内螺纹	2	3/4 in G Female	NC	+60°C
2 SCE238C004 110/50 Asco Numatics Solenoid Valve SCE238C004 110/50, 2 port , NC, 115V ac, 03-Aprin Asco Numatics 电磁阀, 2 端口, NC, 115 V 交流, 3/4in Emerson Electric Co.	0		-	Pilot	115 V ac	3/4in	6.6m³/h	NC	Brass	110ms	20mm	G	母	10bar	20mm	黄铜	3/4in	Female	55ms	G	2/2	238	55ms	空气、惰性气体、水	Air, Inert Gas, Water	3/4 in G 内螺纹	2	3/4 in G Female	NC	+60°C
2 SCE238C005 24 DC Asco Numatics Solenoid Valve SCE238C005 24 DC, 2 port , NC, 24V dc, 1in Asco Numatics 电磁阀, 2 端口, NC, 24 V 直流, 1in Emerson Electric Co.	0		-	Pilot	24 V dc	1in	9.9m³/h	NC	Brass	200ms	25mm	G	母	10bar	25mm	黄铜	1in	Female	70ms	G	2/2	238	70ms	空气、惰性气体、水	Air, Inert Gas, Water	1 in G 内螺纹	2	1 in G Female	NC	+60°C
2 SCE238C005 110/50 Asco Numatics Solenoid Valve SCE238C005 110/50, 2 port , NC, 115V ac, 1in Asco Numatics 电磁阀, 2 端口, NC, 115 V 交流, 1in Emerson Electric Co.	0		-	Pilot	115 V ac	1in	9.9m³/h	NC	Brass	200ms	25mm	G	母	10bar	25mm	黄铜	1in	Female	70ms	G	2/2	238	70ms	空气、惰性气体、水	Air, Inert Gas, Water	1 in G 内螺纹	2	1 in G Female	NC	+60°C
2 SCE238C005 230/50 Asco Numatics Solenoid Valve SCE238C005 230/50, 2 port , NC, 230V ac, 1in Asco Numatics 电磁阀, 2 端口, NC, 230 V 交流, 1in Emerson Electric Co.	0		-	Pilot	230 V ac	1in	9.9m³/h	NC	Brass	200ms	25mm	G	母	10bar	25mm	黄铜	1in	Female	70ms	G	2/2	238	70ms	空气、惰性气体、水	Air, Inert Gas, Water	1 in G 内螺纹	2	1 in G Female	NC	+60°C
