D225K15 wirewound resistor 系列
Ohmite Manufacturing CompanyHigh-power wirewound ceramic resistors for chassis mounting
系列图片（4 张）
常见问答
内容由 AI 生成，仅供参考
加载中...
03
D225K15 wirewound resistor - 型号列表
共 4 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 标准包装数量 | 容差 | 功率（瓦） | 电阻值（欧姆） | 长度 | 直径 | 包装方式 | 端接方式 | 安装类型 | 封装形式 | 调节方式 | 产品 | 商标名 | RoHS | 电阻 | 额定功率 | 额定电压 | 端接样式 | 类型 | 系列 | 工作温度 | 温度系数 | 尺寸/外形 | 交货时间 | 子类别 | 适用产品/相关产品 | 工厂包装数量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 D225K15KE Wirewound Resistors - Chassis Mount 225watt 15K 10% Tubular Ceramic RESISTOR POWER ADJ 15K OHM 225W Wirewound Resistors 225watt 15K 10% Tubular Ceramic Ohmite | 10 | ¥162.58 | Wirewound Resistors - Chassis Mount | 1 | 10 % | 225W | 15k | 10.500" (266.70mm) | 1.126" OD, 0.752" ID (28.60mm x 19.10mm) | Bulk | Solder Lug | Chassis Mount | Cylinder, Tube | Slide | Power Resistors Wirewound Vitreous Enamel | Dividohm | RoHS Compliant | 15 kOhms | 225 W | 4.595 kV | Solder Lug | Vitreous Enamel Adjustable Power | 210 | + 25 C to + 350 C | 260 PPM / C | 28.6 mm Dia. x 266.7 mm L | - | - | - | - |
 D225K15K Wirewound Resistors - Chassis Mount 225watt 15K 10% Tubular Ceramic RESISTOR POWER ADJ 15K OHM 225W Wirewound Resistors 225watt 15K 10% Tubular Ceramic Res Wirewound 15K Ohm 10% 225W ±260ppm/°C Ceramic RDL Lug Bolt-On Ohmite | 10 | ¥161.35 | Wirewound Resistors | 1 | ±10% | 225W | 15k | 10.500" (266.70mm) | 1.126" OD, 0.752" ID (28.60mm x 19.10mm) | Bulk | Solder Lug | Chassis Mount | Cylinder, Tube | Slide | Power Resistors Wirewound Vitreous Enamel | Dividohm | Contains lead / RoHS non-compliant | 15 kOhms | 225 W | 4.595 kV | Solder Lug | Vitreous Enamel Adjustable Power | 210 | + 25 C to + 350 C | 260 PPM / C | - | 56 Days | Resistor Fixed Single-Other Mounting | D225K15KE | - |
 D225K150E RESISTOR POWER ADJ 150 OHM 225W Wirewound Resistors 225W 150 Ohms 10% Res Wirewound 150 Ohm 10% 225W ±260ppm/°C Ceramic RDL Lug Bolt-On Ohmite | 32 | ¥155.81 | Wirewound Resistors | 1 | ±10% | 225W | 150 | 10.500" (266.70mm) | 1.126" OD, 0.752" ID (28.60mm x 19.10mm) | Bulk | Solder Lug | Chassis Mount | Cylinder, Tube | Slide | Power Resistors Wirewound Vitreous Enamel | Dividohm | RoHS Compliant | 150 Ohms | 225 W | 4.595 kV | Solder Lug | Vitreous Enamel Adjustable Power | 210 | + 25 C to + 350 C | 260 PPM / C | - | - | - | - | 1 |
 D225K150 RESISTOR POWER ADJ 150 OHM 225W Res Wirewound 150 Ohm 10% 225W ±260ppm/°C Ceramic RDL Lug Bolt-On Ohmite | 10 | ¥161.35 | - | 1 | ±10% | 225W | 150 | 10.500" (266.70mm) | 1.126" OD, 0.752" ID (28.60mm x 19.10mm) | Bulk | Solder Lug | Chassis Mount | Cylinder, Tube | Slide | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
