AGN210S signal relays, up to 2 amp 系列
Panasonic CorporationElectromechanical signal relays for various voltages
系列图片（21 张）
文档与媒体
常见问答
AGN210S signal relays, up to 2 amp - 型号列表
共 15 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 标准包装数量 | 工厂包装数量 | RoHS | 线圈类型 | 线圈功率 | 线圈电流 | 释放时间 | 线圈电阻 | 供电电压 | 开关电压 | 最大额定电流 | 最小输入电压 | 平均正向功率 | 集电极-发射极饱和电压（最大）@ Vge, Ic | 触点额定电流 | 触点额定值 @ 电压 | 重量 | 包装方式 | 触点形式 | 安装类型 | 触头材料 | 端接样式 | 典型触点布局 | 类型 | 继电器类型 | 动作时间 | 工作温度 | 电流 | 额定电压值 | 接触电阻 | 开关电流 | 击穿电压 | 触点电压（最大） | 绝缘电阻 | 压敏电压（最小） | 并联额定电流 | 功能 | 卡标准 | 电气寿命 | 温度 | 机械寿命 | 抗冲击能力 | 抗振性 | 存储/冷藏温度 | 产品特性 | 欧盟RoHS | 额定功率 | 可见输出 | 额定电压 | 推频（MHz/V） | 钳位电压 | 二极管配置 | 密封 | 深度 | 高度 | 总长度 | 触点数 | 海关税号 | 最大触点电流 | 供电电压 (Vcc/Vdd) | 额定交流电压（相对地/中性线） | 释放范围（时间） | 触点形状 | 操作力 | 其他名称 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 AGN210S1HZ Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 12V Electromechanical Relay DPDT 1A 1.5VDC 22.5Ohm Surface Mount RELAY TELECOM DPDT 1A 1.5V Signal Relay Coil Voltage: 1.5 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 200 | 1: ¥38.556 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant By Exemption | Latching, 1 Coil | * | 66.7 mA | * | * | 1.5 VDC | * | 1 A | 1.13 VDC | 100 mW | 1.13 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | * | Solder Pad | 2C DPDT | Relays | Telecom | * | * | 1 Amp | 2.25 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | * | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S4H Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 4.5V RELAY TELECOM DPDT 1A 4.5V Electromechanical Relay DPDT 1A 4.5VDC 202.5Ohm Surface Mount Signal Relay Coil Voltage: 4.5 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 48 | 1: ¥27.812 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant | Latching, 1 Coil | 100 mW | 22.2 mA | 4ms | 202.5 Ohms | 4.5 VDC | 125VAC, 110VDC - Max | 1 A | 3.38 VDC | 100 mW | 3.38 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Tube | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium (AgPd), Gold (Au) | Solder Pad | 2C DPDT | Relays | Telecom | 4ms | -40°C ~ 85°C | 1 Amp | 6.75 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S03 Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 3V Electromechanical Relay DPDT 1A 3VDC 90Ohm Surface Mount RELAY TELECOM DPDT 1A 3V SIGNAL RELAY, DPDT, 3VDC, 1A, SMD AGN,GN,Relay,SMDStype1-coillatch, Signal Relay Coil Voltage: 3 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 500 | 1: ¥27.812 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant | Latching, 1 Coil | 100 mW | 33.3 mA | 4ms | 90 Ohms | 3 VDC | 125VAC, 110VDC - Max | 1 A | 125 | 100 mW | 2.25 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | 0 | Tube | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium | Solder Pad | DPDT | General Purpose Relay | Latching Single Coil | 4ms | -40°C ~ 85°C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Compliant | 30W|37.5VA | No | 110 | No | 2.25VDC | No | Sealed | 5.7 | 10 | 10.6 | 8 | 85364110 | :1A | :30V | :125V | - | - | - | - |
 AGN210S4HZ Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 4.5V Electromechanical Relay DPDT 1A 4.5VDC 202.5Ohm Surface Mount RELAY TELECOM DPDT 1A 4.5V Signal Relay Coil Voltage: 4.5 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching AGN Series High Sensitivity 1 A DPDT 4.5 VDC Latching 1 Coil SMT Signal Relay Panasonic Electric Works | 500 | 1: ¥20.128 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant | Latching, 1 Coil | 100 mW | 22.2 mA | 4ms | 202.5 Ohms | 4.5 VDC | 125VAC, 110VDC - Max | 1 A | 3.38 VDC | 100 mW | 3.38 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium | Solder Pad | DPDT | General Purpose Relay | Latching Single Coil | 4ms | -40°C ~ 85°C | 1 Amp | 6.75 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | Compliant | 30W|37.5VA | No | 110 | No | 3.38VDC | No | Sealed | 5.7 | 10 | 10.6 | 8 | - | - | - | - | 4ms | DPDT (2 Form C) | 4ms | - |
 AGN210S1H Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 12V Electromechanical Relay DPDT 1A 1.5VDC 22.5Ohm Surface Mount RELAY TELECOM DPDT 1A 1.5V Signal Relay Coil Voltage: 1.5 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 288 | 1: ¥26.044 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant By Exemption | Latching, 1 Coil | * | 66.7 mA | * | * | 1.5 VDC | * | 1 A | 1.13 VDC | 100 mW | 1.13 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Tube | 2 Form C (DPDT-BM) | Surface Mount | * | Solder Pad | 2C DPDT | Relays | Telecom | * | * | 1 Amp | 2.25 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | * | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S24 Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 24V RELAY TELECOM DPDT 1A 24V Electromechanical Relay DPDT 1A 24VDC 4.8KOhm Surface Mount Signal Relay Coil Voltage: 24 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 50 | 1: ¥32.368 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant | Latching, 1 Coil | 120 mW | 5 mA | 4ms | 4.8 kOhms | 24 VDC | 125VAC, 110VDC - Max | 1 A | 18 VDC | 120 mW | 18 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Tube | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium (AgPd), Gold (Au) | Solder Pad | 2C DPDT | Relays | Telecom | 4ms | -40°C ~ 85°C | 1 Amp | 28.8 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S09 Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 9V RELAY TELECOM DPDT 1A 9V Electromechanical Relay DPDT 1A 9VDC 810Ohm Surface Mount Signal Relay Coil Voltage: 9 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 50 | 1: ¥31.96 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant | Latching, 1 Coil | 100 mW | 11.1 mA | 4ms | 810 Ohms | 9 VDC | 125VAC, 110VDC - Max | 1 A | 6.75 VDC | 100 mW | 6.75 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Tube | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium (AgPd), Gold (Au) | Solder Pad | 2C DPDT | Relays | Telecom | 4ms | -40°C ~ 85°C | 1 Amp | 13.5 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S06 Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 6V RELAY TELECOM DPDT 1A 6V Electromechanical Relay DPDT 1A 6VDC 360Ohm Surface Mount Signal Relay Coil Voltage: 6 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 200 | 1: ¥27.404 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant | Latching, 1 Coil | 100 mW | 16.7 mA | 4ms | 360 Ohms | 6 VDC | 125VAC, 110VDC - Max | 1 A | 4.5 VDC | 100 mW | 4.5 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Tube | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium (AgPd), Gold (Au) | Solder Pad | 2C DPDT | Relays | Telecom | 4ms | -40°C ~ 85°C | 1 Amp | 9 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S12 Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 12V Electromechanical Relay DPDT 1A 12VDC 1.44KOhm Surface Mount RELAY TELECOM DPDT 1A 12V Signal Relay Coil Voltage: 12 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 250 | 1: ¥30.192 | Low Signal Relays - PCB | 50 | 50 | RoHS Compliant | Latching, 1 Coil | 100 mW | 8.3 mA | 4ms | 1.44 kOhms | 12 VDC | 125VAC, 110VDC - Max | 1 A | 9 VDC | 100 mW | 9 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Tube | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium | Solder Pad | DPDT | General Purpose Relay | Latching Single Coil | 4ms | -40°C ~ 85°C | 1 Amp | 18 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | Compliant | 30W|37.5VA | No | 110 | No | 9VDC | No | Sealed | 5.7 | 10 | 10.6 | 8 | - | - | - | - | - | - | - | - |
 AGN210S06Z Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 6V RELAY TELECOM DPDT 1A 6V Electromechanical Relay DPDT 1A 6VDC 360Ohm Surface Mount Signal Relay Coil Voltage: 6 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 200 | 1: ¥38.556 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant | Latching, 1 Coil | 100 mW | 16.7 mA | 4ms | 360 Ohms | 6 VDC | 125VAC, 110VDC - Max | 1 A | 4.5 VDC | 100 mW | 4.5 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium (AgPd), Gold (Au) | Solder Pad | 2C DPDT | Relays | Telecom | 4ms | -40°C ~ 85°C | 1 Amp | 9 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S03Z Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 3V RELAY TELECOM DPDT 1A 3V Electromechanical Relay DPDT 1A 3VDC 90Ohm Surface Mount Signal Relay Coil Voltage: 3 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 500 | 1: ¥31.756 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant | Latching, 1 Coil | 100 mW | 33.3 mA | 4ms | 90 Ohms | 3 VDC | 125VAC, 110VDC - Max | 1 A | 2.25 VDC | 100 mW | 2.25 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | Silver Palladium (AgPd), Gold (Au) | Solder Pad | 2C DPDT | Relays | Telecom | 4ms | -40°C ~ 85°C | 1 Amp | 4.5 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 255-3878-1 |
 AGN210S09Z Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 9V Electromechanical Relay DPDT 1A 9VDC 810Ohm Surface Mount RELAY TELECOM DPDT 1A 9V Signal Relay Coil Voltage: 9 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 200 | 1: ¥38.556 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant By Exemption | Latching, 1 Coil | * | 11.1 mA | * | * | 9 VDC | * | 1 A | 6.75 VDC | 100 mW | 6.75 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | * | Solder Pad | 2C DPDT | Relays | Telecom | * | * | 1 Amp | 13.5 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | * | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S12Z Low Signal Relays - PCB 2 Form C 1 Form A 30VDC SMD 12V Electromechanical Relay DPDT 1A 12VDC 1.44KOhm Surface Mount RELAY TELECOM DPDT 1A 12V Signal Relay Coil Voltage: 12 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 200 | 1: ¥38.556 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant By Exemption | Latching, 1 Coil | * | 8.3 mA | * | * | 12 VDC | * | 1 A | 9 VDC | 100 mW | 9 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | * | Solder Pad | 2C DPDT | Relays | Telecom | * | * | 1 Amp | 18 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | * | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S24Z Low Signal Relays - PCB 3 Form C 1 Form A 30VDC SMD 12V Electromechanical Relay DPDT 1A 24VDC 4.8KOhm Surface Mount RELAY TELECOM DPDT 1A 24V Signal Relay Coil Voltage: 24 VDC Contact Configuration: 2C DPDT Current: 1 Amp Mounting: Surface Mount Operating Function: 1 Coil Latching Panasonic Electric Works | 173 | 1: ¥44.676 | Low Signal Relays - PCB | 500 | 500 | RoHS Compliant By Exemption | Latching, 1 Coil | * | 5 mA | * | * | 24 VDC | * | 1 A | 18 VDC | 120 mW | 18 VDC | 1 A | 1 A at 30 VDC / 300 mA at 125 VAC | Approx. 1 g .035 oz | Reel | 2 Form C (DPDT-BM) | Surface Mount | * | Solder Pad | 2C DPDT | Relays | Telecom | * | * | 1 Amp | 28.8 VDC | 100 mohm | 10 ?A 10 mV DC | 1,000 Vrms for 1min. | 1,500 Vrms for 1min. | Min. 10,000M ohm (at 500V DC) | 1,500 V (FCC Part 68) | 1 A 30 V DC, 0.3 A 125 V AC | 1 Coil Latching | Signal Relay | 1 A 30 V DC resistive - 10^5, 0.3 A 125 V AC resistive - 10^5 | Max. 50°C | 5 10^7 | Min. 750 m/s^2{75G] | 10 to 55 Hz at double amplitude of 5 mm | 5 to 85% R.H. | * | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 AGN210S03ZJ Panasonic Corporation | 0 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
