76RSB02 switche 系列
Grayhill, Inc.PC用两位置DIP摇杆开关
Grayhill, Inc. 的76RSB02系列是专为个人电脑（PC）应用设计的双位置DIP摇杆开关。这些开关常见于各种PC组件中，如电源供应器、主板以及外部设备，例如USB集线器或音频控制器。如果您正在做一个需要简单可靠方式在两种状态之间切换的项目，那么这些开关是一个不错的选择。
值得注意的是，它们具有紧凑的尺寸，使其非常适合空间受限的设计。当工程师需要一个坚固且具有触觉反馈机制的开关，而又不想使用更复杂、更昂贵的大尺寸替代品时，往往会选用这种开关。另一个实用的好处是其耐用性；这些开关被设计为能够承受数千次循环，因此适用于消费级和工业级PC环境。
系列图片（5 张）
文档与媒体
常见问答
76RSB02 switche - 型号列表
共 6 个型号| 制造商零件编号 | 库存 | 价格 | 产品类别 | 标准包装数量 | RoHS | 电路 | 触点额定值 @ 电压 | 包装方式 | 方向 | 致动器类型 | 安装类型 | 执行器水平位置 | 位数 | 可清洗 | 其他名称 | 欧盟RoHS | 额定电压 | 最大额定电流 | 开关功能/额定值 | 密封 | 深度 | 高度 | 柱间距 | 端子类型 | 接触镀层 | 触头材料 | 总长度 | 按钮样式/尺寸 | 开关驱动电平 | 电气寿命 | 机械寿命 | 工作温度 | 抗辐射加固 | 开关功能 | 直流反向电压（Vr）（最大） | 间距 | 安装样式 | 端接样式 | 转换前位置数 | 交货时间 | 子类别 | 适用产品/相关产品 | 已删除 | 极数 | 介电强度 | 端接方式 | 触点形式 | 类型 | 系列 | 电路类型 | 制造商全称 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycle/SwitchCycle 2.54mm Thru-Hole Tube Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube SWITCH DIP RECESS RCKR 2POS 30V grayhill | 98 | 22: ¥19.448 | - | Rail / Tube | Lead free / RoHS Compliant | SPST | 0.15A @ 30VDC | Tube | Top Actuated | Rocker | Through Hole | Recessed | 2 | Yes | GH7149 | Compliant | 30 V | 0.15@30VDC A | ON OFF | Tape(Polyester Film)/Base | 9.65 mm | 7.42 mm | 2.54 | PC Pins | Gold/Nickel Barrier | Copper Alloy | 7.1 mm | Recessed Rocker | SPST | 2000/Switch | 2000 | -40 to 85 °C | No | ON OFF | 30V | 2.5 mm | Through Hole | PC Pins | 2 | - | - | - | Compliant | - | - | - | - | - | - | - | - |
 Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycle/SwitchCycle 2.54mm Thru-Hole Tube Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube SWITCH DIP RECESS RCKR SLD 2POS grayhill | 10 | 35: ¥6.6783 | - | Rail / Tube | Lead free / RoHS Compliant | SPST | 0.15A @ 30VDC | Tube | Top Actuated | Rocker | Through Hole | Recessed | 2 | Yes | - | Compliant | 30 V | 0.15@30VDC A | ON OFF | Tape(Polyester Film)/Base | 9.65 | 7.42 | 2.54 | PC Pins | Gold/Nickel Barrier | Copper Alloy | 7.1 | Recessed Rocker | SPST | 2000/Switch | 2000/Switch | -40 to 85 °C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycle/SwitchCycle 2.54mm Thru-Hole Tube Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube SW DIP RECESS RCKR UNSL 2POS 30V Switch,DIP;0.280in.Lx0.380in.W;2;SPST;Thru-Hole;0.1in.;0.02in. 76 Series Raised and Recessed Rocker SPST 2 Position Through Hole DIP Switch grayhill | 251 | 1: ¥11.492 | - | Rail / Tube | Lead free / RoHS Compliant | SPST | 0.15A @ 30VDC | Tube | Top Actuated | Rocker | Through Hole | Recessed | 2 | No | GH7150 | Compliant | 30 V | 0.15@30VDC A | ON OFF | Base | 9.65 mm | 7.42 mm | 2.54 | PC Pins | Gold/Nickel Barrier | Copper Alloy | 7.1 mm | Recessed Rocker | SPST | 2000/Switch | 2000 | -40 to 85 °C | No | ON OFF | 30 V | 2.54 mm | Through Hole | PC Pins | 2 | - | - | - | - | 1 | 750V | PCBPins | SPST | Rocker | 76 | SPST | 76Series |
Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycle/SwitchCycle 2.54mm Thru-Hole Tube Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 2000Cycles/SwitchCycles 2.54mm Thru-Hole Tube SWITCH DIP RECESS RCKR 2POS grayhill | 10 | 35: ¥6.1404 | - | Rail / Tube | Lead free / RoHS Compliant | SPST | 0.15A @ 30VDC | Tube | Top Actuated | Rocker | Through Hole | Recessed | 2 | No | - | Compliant | 30 V | 0.15@30VDC A | ON OFF | Base | 9.65 | 7.42 | 2.54 | PC Pins | Gold/Nickel Barrier | Copper Alloy | 7.1 | Recessed Rocker | SPST | 2000/Switch | 2000/Switch | -40 to 85 °C | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 SWITCH 2 POS DIP RECESS ROCK SLD Switch DIP ON OFF SPST 2 Recessed Rocker 0.15A 30VDC PC Pins 20000Cycle/SwitchCycle 2.54mm Thru-Hole Tube Grayhill Inc | 150 | 1: ¥19.448 | - | 35 | Contains lead / RoHS non-compliant | SPST | 0.15A @ 30VDC | Tube | Top Actuated | Rocker | Through Hole | Recessed | 2 | Yes | GH1262 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 56 Days | Switch DIP | 76RSB02SLT76RSB02ST | - | - | - | - | - | - | - | - | - |
| 0 | - | 35 | Contains lead / RoHS non-compliant | SPST | 0.15A @ 30VDC | Tube | Top Actuated | Rocker | Through Hole | Recessed | 2 | No | GH1272 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 56 Days | Switch DIP | 76RSB02T76RSB02LT | - | - | - | - | - | - | - | - | - |
