GRM31BR72J 系列
murata
1206封装高压多层陶瓷电容器
GRM31BR72J系列是一款高性能多层陶瓷电容器(MLCC)产品线，专为满足现代电子应用的严苛要求而设计。该系列电容器以卓越的可靠性、坚固结构和多功能性著称，已成为各行业工程师和设计人员的首选方案。采用C0G(NP0)介电材料制造，GRM31BR72J系列具有超稳定电容特性，温度系数为0±30ppm/°C，可在-55°C至+125°C宽温范围内保持稳定性能，是精度与可靠性要求严苛应用的理想选择。
该系列采用紧凑型1206封装(3.2mm×1.6mm)，在性能与空间效率之间实现完美平衡。其电容值专为高频高压应用优化，特别适用于射频电路、电源系统和信号调理系统。低等效串联电阻(ESR)和高绝缘电阻特性，使其在滤波、去耦和储能应用中表现尤为出色。此外，该系列支持宽电压等级范围，可同时兼容低压与高压设计。
GRM31BR72J系列的突出设计特点是能耐受高湿度、机械应力等恶劣环境条件。这种耐久性与优异电气特性的结合，使其成为汽车电子、通信基础设施和工业控制系统的可靠选择。在汽车应用中，该电容器常用于发动机控制单元(ECU)、信息娱乐系统和高级驾驶辅助系统(ADAS)等对稳定性和使用寿命要求极高的场合；在通信领域，则广泛应用于基站、天线和信号处理设备，确保关键通信网络的不间断运行。
总体而言，GRM31BR72J系列是为追求高精度、耐久性和能效的工程师提供的多功能可靠解决方案。其先进的材料技术、紧凑型设计和稳健性能的结合，使其成为从消费电子到工业及汽车关键系统等广泛电子设备中的核心元件。
系列图片（10 张）
常见问答
内容由 AI 生成，仅供参考
加载中...
GRM31BR72J - 型号列表共 12 个型号
| 制造商零件编号 | 价格/库存 | Package/Case | Mounting | Capacitance Value | Voltage | Tolerance | Dielectric | Operating Temperature | Construction | Product Length | Product Height | Product Depth | Standard Package | Product Category | RoHS | Capacitance | Voltage Rating | Temperature Coefficient / Code | Case Code - in | Case Code - mm | Operating Temperature Range | Product | Packaging | Capacitance - nF | Dimensions | Package / Case | Series | Factory Pack Quantity | Termination Style | Product Length | EU RoHS | Maximum Operating Temperature | Product Depth | Product Height | Case Style | Technology | Temperature Coefficient | rohs | Case Length | Case Height | Case Width | Type | Product Range | Capacitance Tolerance | Dielectric Characteristic | Capacitor Case Style | Operating Temperature Min | Operating Temperature Max | MSL | SVHC | Capacitor Terminals | Weight (kg) | Tariff No. | Capacitance - uF | Mounting Type | Voltage - Rated | Size / Dimension | Applications | Thickness (Max) | Other Names | Maximum Operating Temperature | Minimum Operating Temperature | Tolerance Minus | Tolerance Plus | Unit Pack | MOQ | Operating Temp Range | Rad Hardened | Failure Rate | Tolerance (+ or -) | Temp Coeff (Dielectric) | Wire Form | Mounting Style | Product Length (mm) | Product Depth (mm) | Product Height (mm) | Product Diameter (mm) | Matchcode | Style | Electrodes | T(A) min | Tape type | Standard Leadtime | C(N) | T(A) max | Leadfree Defin. | Case size | Automotive | Termination | V(N) | Package | DELETED | Capacitance - pF |
|---|
 | 询价 | 1206 | Surface Mount | 0.0033 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 3300 pF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 3.3 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | X7R | Lead free / RoHS Compliant | 3.2 mm | 1.25 mm | 1.6 mm | General Purpose MLCC | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | 0.0033 uF | Surface Mount, MLCC | 630V | 0.126" L x 0.063" W (3.20mm x 1.60mm) | General Purpose | 0.049" (1.25mm) | 490-3509-2 | +125°C | -55°C | -10% | +10% | 3000 | 3000 | - | - | - | - | - | - | - | - | - | - | - | KC3,3N1206X7R630K NORM | CHIP | BME | -55°C | BLISTER | 13 weeks | 3,3nF | +125°C | RoHS-conform | 1206 | NO | NISN | 630V | 1206 | - | - |
| 询价 | 1206 | Surface Mount | 0.0022 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 2200 pF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 2.2 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | X7R | Lead free / RoHS Compliant | 3.2 mm | 1.25 mm | 1.6 mm | General Purpose MLCC | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | 0.0022 uF | Surface Mount, MLCC | 630V | 0.126" L x 0.063" W (3.20mm x 1.60mm) | General Purpose | 0.049" (1.25mm) | 490-3508-2 | +125°C | -55°C | -10% | +10% | - | - | -55C to 125C | No | Not Required | 10% | X7R | Not Required | Surface Mount | 3.2 mm | 1.6 mm | 1.25 mm | Not Required mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Compliant | - |
| 询价 | 1206 | Surface Mount | 0.01 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 0.01 uF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 10 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | X7R | Lead free / RoHS Compliant | 3.2 mm | 1.25 mm | 1.6 mm | Flat | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | - | Surface Mount, MLCC | 630V | 0.126" L x 0.063" W (3.20mm x 1.60mm) | General Purpose | 0.049" (1.25mm) | 490-3512-2 | +125°C | -55°C | -10% | +10% | 3000 | 3000 | -55C to 125C | No | Not Required | 10% | X7R | Not Required | Surface Mount | 3.2 mm | 1.6 mm | 1.25 mm | Not Required mm | KC10N1206X7R630K NORM | CHIP | BME | -55°C | BLISTER | 14 weeks | 10nF | +125°C | RoHS-conform | 1206 | NO | NISN | 630V | 1206 | - | 10000 pF |
| 询价 | 1206 | Surface Mount | 0.0047 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 4700 pF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 4.7 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | X7R | Lead free / RoHS Compliant | 3.2 mm | 1.25 mm | 1.6 mm | General Purpose MLCC | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | 0.0047 uF | Surface Mount, MLCC | 630V | 0.126" L x 0.063" W (3.20mm x 1.60mm) | General Purpose | 0.049" (1.25mm) | 490-3510-2 | +125°C | -55°C | -10% | +10% | 3000 | 3000 | -55C to 125C | No | Not Required | 10% | X7R | Not Required | Surface Mount | 3.2 mm | 1.6 mm | 1.25 mm | Not Required mm | KC4,7N1206X7R630K NORM | CHIP | BME | -55°C | BLISTER | 14 weeks | 4,7nF | +125°C | RoHS-conform | 1206 | NO | NISN | 630V | - | - | - |
 | 询价 | 1206 | Surface Mount | 0.001 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 1206 | Surface Mount | 0.01 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 1206 | Surface Mount | 0.0047 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 1206 | Surface Mount | 0.001 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 1000 pF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 1 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | ±15% | Compliant | 3.2 mm | 1.25 mm | 1.6 mm | General Purpose MLCC | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | 0.001 uF | - | - | - | - | - | - | +125°C | -55°C | -10% | +10% | - | - | -55C to 125C | No | Not Required | 10% | X7R | Not Required | Surface Mount | 3.2 mm | 1.6 mm | 1.25 mm | Not Required mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Compliant | - |
| 询价 | 1206 | Surface Mount | 0.0068 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 6800 pF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 6.8 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | X7R | Lead free / RoHS Compliant | 3.2 mm | 1.25 mm | 1.6 mm | General Purpose MLCC | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | 0.0068 uF | Surface Mount, MLCC | 630V | 0.126" L x 0.063" W (3.20mm x 1.60mm) | General Purpose | 0.049" (1.25mm) | 490-3511-2 | - | - | - | - | 3000 | 3000 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 1206 | Surface Mount | 0.0022 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
GRM31BR72J102KW01L/BKN Cap Ceramic 0.001uF 630V X7R 10% SMD 1206 125°C Embossed T/R murata electronics | 询价 | 1206 | Surface Mount | 0.001 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Cut Tape | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 1206 | Surface Mount | 0.0015 uF | 630 Vdc | 10 % | X7R | -55 to 125 °C | Flat | 3.2 mm | 1.25 mm | 1.6 mm | Tape & Reel | Multilayer Ceramic Capacitors MLCC - SMD/SMT | RoHS Compliant | 1500 pF | 630 V | X7R | 1206 | 3216 | - 55 C to + 125 C | General Type MLCCs | Reel | 1.5 nF | 1.6 mm W x 3.2 mm L x 1.25 mm H | 1206 (3216 metric) | GRM | 3000 | SMD/SMT | 3.2 | Compliant | 125 | 1.6 | 1.25 | Ceramic Chip | Standard | X7R | Lead free / RoHS Compliant | 3.2 mm | 1.25 mm | 1.6 mm | General Purpose MLCC | :MURATA - GRM Series | :± 10% | :X7R | :1206 [3216 Metric] | :-55°C | :125°C | :- | :No SVHC (20-Jun-2013) | :SMD | 0.000053 | 85322400 | 0.0015 uF | Surface Mount, MLCC | 630V | 0.126" L x 0.063" W (3.20mm x 1.60mm) | General Purpose | 0.049" (1.25mm) | 490-3507-2 | +125°C | -55°C | -10% | +10% | 3000 | 3000 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
共 12 个型号
