1-1624094 系列
tyco
3613系列线绕贴片电感器
1-1624094系列是一系列高性能连接器，专为满足现代电子应用的严苛需求而设计。这些连接器在可靠性、多功能性和易用性方面进行了精心设计，使其成为电信、汽车和工业自动化等多个行业的理想选择。
1-1624094系列的关键特点之一是其坚固的设计，包括高密度引脚配置，能够在保持优异电气性能的同时显著节省空间。该系列采用耐用材料，确保机械完整性，并具有抗潮湿和温度波动等环境因素的能力。这些连接器适用于高电流和高电压应用，非常适合复杂系统中的电力分配和信号完整性需求。
1-1624094系列连接器设计用于快速简便的安装，配备用户友好的锁定机制，确保连接牢固，同时在需要时便于拆卸。这一设计特点在需要频繁连接和断开的应用中尤为有益，例如原型设计和测试环境。此外，该系列支持多种端接方式，包括焊接和压接选项，增强了其在不同装配工艺中的适应性。
在应用方面，1-1624094系列连接器非常适合用于电信设备，其中可靠的信号传输至关重要。它们还广泛应用于汽车系统，在这些系统中，耐用性和在恶劣操作条件下的性能至关重要。此外，这些连接器在工业自动化系统中也有应用，有助于各种组件的无缝集成，确保复杂机械内部的高效运行和通信。
总体而言，1-1624094系列作为一种可靠且多功能的连接器解决方案脱颖而出，旨在满足电子元件市场不断变化的需求。其坚固的结构、广泛的应用和用户友好的功能使其成为工程师和设计师寻求高质量连接解决方案的绝佳选择。
系列图片（10 张）
常见问答
内容由 AI 生成，仅供参考
加载中...
1-1624094 - 型号列表共 10 个型号
| 制造商零件编号 | 价格/库存 | Industry Aliases | Subcategory | Packaging | Lead Time | Inductance | Tolerance | Standard Package | Current Rating | DC Resistance (DCR) | Height - Seated (Max) | Material - Core | Frequency - Self Resonant | Shielding | Supplier Device Package | Size / Dimension | Operating Temperature | Mounting Type | Q @ Freq | Frequency - Test | rohs | Other Names | Package/Case | Type | Maximum DC Current | Maximum DC Resistance | Minimum Quality Factor | Core Material | Product Height | RoHSELV Compliance | RoHSELV Compliance History | Current Maximum | Mount Style | Shielded | Series | Brand | Lead Free Solder Processes | Element | Application | DC Resistance | Package Type | Inductor Type | Packaging Style | Package Component Size | Product Type | Quality Factor | Lead Type | 电感器结构 | 深度 | 电感值 | 系列 | 容差 | 最高工作温度 | 最小质量系数 | 高度 | 最低工作温度 | 长度 | 屏蔽 | 尺寸 | 封装/外壳 | 模制 | Board Level Components | 最大自谐振频率 | 最大直流电阻值 | 最大直流电流 | 芯材 | Package / Case | Standard Pack: | 不同频率时的 Q 值 | 操作温度 | 直流电阻 (DCR) | 频率 - 测试 | 电感 | 装配类型 | 额定电流 | 频率 - 自谐振 | 大小/尺寸 | 材料 - 磁芯 |
|---|
 1-1624094-5 Ind Chip Molded/Unshielded Wirewound 3.3uH 10% 7.96MHz 50Q-Factor Ferrite 355mA 1812 T/R te connectivity / amp | 询价 | 3613C3R3K | Inductor Surface Mount | Tape and Reel | 101 Days | 3.3 uH | 10 % | Tape & Reel | 355mA | 800 mOhm Max | 0.134" (3.40mm) | Ferrite | 45MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 50 @ 7.96MHz | 7.96MHz | Lead free / RoHS Compliant | A102548CT | 1812 | Chip | 355 mA | 800 mOhm | 50@7.96MHz | Ferrite | 3.4 mm | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 355.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 0.8 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 50.0 | Surface Mount Terminals | 线绕 | 3.2mm | 3.3 μH | 3613C | ±10% | +100°C | 50 | 3.2mm | -30°C | 4.5mm | 是 | 4.5 x 3.2 x 3.2mm | 1812 | 是 | Y | Minimum of 45MHz | 800mΩ | 355mA | 铁氧体 | - | 500 | - | - | - | - | - | - | - | - | - | - |
1-1624094-7 Ind Chip Molded/Unshielded Wirewound 470uH 10% 796KHz 40Q-Factor Ferrite 62mA 1812 T/R te connectivity / amp | 询价 | 3613C471K | Inductor Surface Mount | Tape and Reel | 101 Days | 470 uH | 10 % | Bulk | 62mA | 26 Ohm Max | 0.134" (3.40mm) | Ferrite | 3MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 40 @ 796kHz | 796kHz | Lead free / RoHS Compliant | 3613C471K | 1812 | Chip | 62 mA | 26 Ohm | 40@796KHz | Ferrite | 3.4 mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1812 (4532 Metric) | - | - | - | - | - | - | - | - | - | - | - |
1-1624094-8 Ind Chip Molded/Unshielded Wirewound 4.7uH 10% 7.96MHz 50Q-Factor Ferrite 315mA 1812 T/R te connectivity / amp | 询价 | 3613C4R7K | Inductor Surface Mount | Tape and Reel | 87 Days | 4.7 uH | 10 % | Tape & Reel | 315mA | 1 Ohm Max | 0.134" (3.40mm) | Ferrite | 35MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 50 @ 7.96MHz | 7.96MHz | Lead free / RoHS Compliant | A102074CT | 1812 | Chip | 315 mA | 1 Ohm | 50@7.96MHz | Ferrite | 3.4 mm | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 315.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 1.0 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 50.0 | Surface Mount Terminals | 线绕 | 3.2mm | 4.7 μH | 3613C | ±10% | +100°C | 50 | 3.2mm | -30°C | 4.5mm | 是 | 4.5 x 3.2 x 3.2mm | 1812 | 是 | Y | Minimum of 35MHz | 1Ω | 315mA | 铁氧体 | - | - | - | - | - | - | - | - | - | - | - | - |
1-1624094-4 Ind Chip Molded/Unshielded Wirewound 330uH 10% 796KHz 40Q-Factor Ferrite 85mA 1812 T/R te connectivity / amp | 询价 | 3613C331K | Inductor Surface Mount | Tape and Reel | 56 Days | 330 uH | 10 % | Tape & Reel | 85mA | 14 Ohm Max | 0.134" (3.40mm) | Ferrite | 3.5MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 40 @ 796kHz | 796kHz | Lead free / RoHS Compliant | 3613C331K | 1812 | Chip | 85 mA | 14 Ohm | 40@796KHz | Ferrite | 3.4 mm | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 85.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 14.0 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 40.0 | Surface Mount Terminals | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1812 (4532 Metric) | - | - | - | - | - | - | - | - | - | - | - |
1-1624094-3 Ind Chip Molded/Unshielded Wirewound 33uH 10% 2.52MHz 50Q-Factor Ferrite 160mA 1812 T/R te connectivity / amp | 询价 | 3613C330K | Inductor Surface Mount | Tape and Reel | 101 Days | 33 uH | 10 % | Tape & Reel | 160mA | 4 Ohm Max | 0.134" (3.40mm) | Ferrite | 11MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 50 @ 2.52MHz | 2.52MHz | Lead free / RoHS Compliant | A102193CT | 1812 | Chip | 160 mA | 4 Ohm | 50@2.52MHz | Ferrite | 3.4 mm | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 160.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 4.0 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 50.0 | Surface Mount Terminals | 线绕 | 3.2mm | 33 μH | 3613C | ±10% | +100°C | 50 | 3.2mm | -30°C | 4.5mm | 是 | 4.5 x 3.2 x 3.2mm | 1812 | 是 | Y | Minimum of 11MHz | 4Ω | 160mA | 铁氧体 | - | 500 | - | - | - | - | - | - | - | - | - | - |
1-1624094-6 Ind Chip Molded/Unshielded Wirewound 47uH 10% 2.52MHz 50Q-Factor Ferrite 140mA 1812 T/R te connectivity / amp | 询价 | 3613C470K | Inductor Surface Mount | Tape and Reel | 100 Days | 47 uH | 10 % | Tape & Reel | 140mA | 5 Ohm Max | 0.134" (3.40mm) | Ferrite | 10MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 50 @ 2.52MHz | 2.52MHz | Lead free / RoHS Compliant | A102549CT | 1812 | Chip | 140 mA | 5 Ohm | 50@2.52MHz | Ferrite | 3.4 mm | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 140.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 5.0 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 50.0 | Surface Mount Terminals | 线绕 | 3.2mm | 47 μH | 3613C, Sigma Inductors | ±10% | +100°C | 50 | 3.2mm | -30°C | 4.5mm | Unshielded | 4.5 x 3.2 x 3.2mm | 1812 (4532 Metric) | 是 | Y | Minimum of 10MHz | 5Ω | 140mA | 铁氧体 | - | - | 50 @ 2.52MHz | -30°C ~ 100°C | 5 Ohm Max | 2.52MHz | 47µH | Surface Mount | 140mA | 10MHz | 0.177" L x 0.126" W (4.50mm x 3.20mm) | Ferrite |
1-1624094-9 Ind Chip Molded/Unshielded Wirewound 5.6uH 10% 7.96MHz 50Q-Factor Ferrite 300mA 1812 T/R te connectivity / amp | 询价 | 3613C5R6K | Inductor Surface Mount | Tape and Reel | 101 Days | 5.6 uH | 10 % | Tape & Reel | 300mA | 1.1 Ohm Max | 0.134" (3.40mm) | Ferrite | 33MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 50 @ 7.96MHz | 7.96MHz | Lead free / RoHS Compliant | A102550CT | 1812 | Chip | 300 mA | 1.1 Ohm | 50@7.96MHz | Ferrite | 3.4 mm | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 300.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 1.1 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 50.0 | Surface Mount Terminals | 线绕 | 3.2mm | 5.6 μH | 3613C | ±10% | +100°C | 50 | 3.2mm | -30°C | 4.5mm | 是 | 4.5 x 3.2 x 3.2mm | 1812 | 是 | Y | Minimum of 33MHz | 1.1Ω | 300mA | 铁氧体 | 1812 (4532 Metric) | 500 | - | - | - | - | - | - | - | - | - | - |
1-1624094-2 Ind Chip Molded/Unshielded Wirewound 2.2uH 10% 7.96MHz 50Q-Factor Ferrite 380mA 1812 T/R te connectivity / amp | 询价 | 3613C2R2K | Inductor Surface Mount | Tape and Reel | 87 Days | 2.2 | 10.0 | Tape & Reel | 380mA | 700 mOhm Max | 0.134" (3.40mm) | Ferrite | 55MHz | Unshielded | 1812 | 0.177" L x 0.126" W (4.50mm x 3.20mm) | -30°C ~ 100°C | Surface Mount | 50 @ 7.96MHz | 7.96MHz | Lead free / RoHS Compliant | A102545CT | - | - | - | - | - | - | - | RoHS compliant / ELV compliant | Converted to comply with RoHS directive | 380.0 | Surface Mount | No | 3613 | Sigma Inductors | Reflow solder capable to 245°C / Reflow solder capable to 260°C | Wirewound | Standard | 0.7 | Taped and Reeled | Molded Wirewound | 1812 | 4.5 x 3.2 | Inductor | 50.0 | Surface Mount Terminals | 线绕 | 3.2mm | 2.2 μH | 3613C, Sigma Inductors | ±10% | +100°C | 50 | 3.2mm | -30°C | 4.5mm | Unshielded | 4.5 x 3.2 x 3.2mm | 1812 (4532 Metric) | 是 | Y | Minimum of 55MHz | 700mΩ | 380mA | 铁氧体 | 1812 (4532 Metric) | - | 50 @ 7.96MHz | -30°C ~ 100°C | 700 mOhm Max | 7.96MHz | 2.2µH | Surface Mount | 380mA | 55MHz | 0.177" L x 0.126" W (4.50mm x 3.20mm) | Ferrite |
 | 询价 | 3613C270K | Inductor Surface Mount | Tape and Reel | 365 Days | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3613C271K | Inductor Surface Mount | Tape and Reel | 365 Days | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
共 10 个型号
