Würth Elektronik GmbH & Co. KG- 音频变压器
音频变压器 - 型号列表
共 60 个型号| 制造商零件编号 | 库存 | 价格 | RoHS | 包装方式 | 尺寸/外形 | 产品 | 电感量 | 隔离电压 | 宽度 | 高度 | 长度 | 封装形式 | 端接样式 | 类型 | 工作温度 | 其他名称 | 标准包装数量 | 安装类型 | 主要材料 | 产品子类型 | 初始电阻（最小） | 次级直流电阻（DCR） | 安装高度（最大） | 应用 | 目标芯片组 | 芯片组制造商 | 初级电压 | 最大额定电流 | 频率范围 | 频率 | 额定功率 | 辅助电压 | 系列 | 制造商 | 最大频率 | 尺寸 | 端部尺寸（如SMD/SMT、14mm等） | 结工作温度 | 直流电阻（DCR） | 产品类别 | 输入电阻 | 25°C时电阻 | 磁芯材质 | 其他规格 | 峰值脉冲功率 | 初级阻抗（欧姆） | 次级阻抗（欧姆） | 容差 | 测试频率 | 串联饱和电流 | 屏蔽 | 电流 | 滤波器类型 | 高度（最大） | 线路数量 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 変圧器 オーディオとシグナル Buck Inductor with Aux for Europe TRANS BUCK SSL2101 95UH RAD Transformers Audio & Signal Buck Inductor with Aux for Europe Midcom / Wurth Electronics | 23 | 1: ¥40.256 | RoHS 認証 | Tray | 13.97mm L x 13.97mm W | Transformers | 180 uH | 1000Vrms | 13.97 mm | 12.7 mm | 13.97 mm | 13.97 mm x 13.97 mm x 12.7 mm | Through Hole | Power Transformers | -40°C ~ 125°C | 732-2900 | 50 | Through Hole | 0.11 Ohms | Transformers | 300 mOhms | 0.3 Ohms | 12.7 mm | LED Drivers, AC/DC SMPS | SSL2101 | NXP Semiconductors | 230V | - | - | - | - | - | - | Wurth Electronics | 13.97 mm | 13.97 mm L x 13.97 mm W x 12.7 mm H | Through Hole | - 40 C to + 125 C | - | - | 300 mOhms | 0.11 Ohms | 0.3 Ohms | 1000 VAC | - | - | - | - | - | - | - | - | - | - | - |
 変圧器 オーディオとシグナル MID-T8T Transformer 2.5mH 85kHz 0.75A TRANS 4500V SMD Transformers Audio & Signal MID-T8T Transformer 2.5mH 85kHz 0.75A Midcom / Wurth Electronics | 160 | 1: ¥156.673 | RoHS 認証 | Tape & Reel (TR) | 36.50mm L x 18.80mm W | General Purpose Transformers | 2.5 mH | 4500Vrms | 18.8 mm | 12 mm | 36.5 mm | Reel | SMD/SMT | - | -40°C ~ 125°C | 732-3322-2 | 160 | Surface Mount | - | General Purpose Transformers | - | - | 12 mm | LED Drivers, AC/DC SMPS | - | - | 280 ~ 380V | - | - | 85kHz | 20 W | 19V @ 20mA | - | Wurth Electronics | 18.8 mm | 36.5 mm L x 18.8 mm W x 12 mm H | SMD/SMT | - 40 C to + 125 C | - | - | - | - | - | - | 20 W | 2.27 Ohms | 0.026 Ohms | - | - | - | - | - | - | - | - |
 変圧器 オーディオとシグナル Flyback Transformer for High Efficiency TRANS FLYBACK NCL30000 1.72MH Transformers Audio & Signal Flyback Transformer for High Efficiency Midcom / Wurth Electronics | 10 | 1: ¥78.472 | RoHS Compliant | Tray | 26.67mm L x 26.92mm W | Transformers | 1.72 mH | 4500Vrms | 26.67 mm | 14.81 mm | 26.92 mm | 26.92 mm x 26.67 mm x 14.81 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2899 | 65 | Through Hole | 0.235 Ohms | Control Transformers | 845 mOhms | 0.09 Ohms | 14.81mm | LED Drivers, AC/DC SMPS | NCL30000 | On Semiconductor | 127 ~ 431V | 1.05 A | 39 kHz | 39kHz | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 変圧器 オーディオとシグナル Boost Inductor IND BOOST CY8CLEDAC02 1.2MH RAD Transformers Audio & Signal Boost Inductor Midcom / Wurth Electronics | 600 | 1: ¥54.508 | RoHS Compliant | Tray | 0.580" Dia x 0.365" W (14.73mm x 9.27mm) | Transformers | 1.2mH | - | 10.18 mm | 9.78 mm | 8.26 mm | Radial | Through Hole | Wirewound | - 40 C to + 125 C | 732-2905 | 300 | Through Hole | 1.1 Ohms | Control Transformers | 1.1 Ohms | - | - | - | - | - | - | 200mA | - | - | - | - | - | - | - | - | - | - | 1.1 Ohm | - | - | - | - | - | - | - | - | ±10% | 10kHz | 200mA | Unshielded | - | - | - | - |
 変圧器 オーディオとシグナル Offline Transformer Transformers Audio & Signal Offline Transformer Midcom / Wurth Electronics | 128 | 1: ¥81.257 | RoHS Compliant | Tray | 18.8 mm L x 16.9 mm W x 13 mm H | Transformers | 1.67 mH | 4500 VAC | 16.9 mm | 13 mm | 18.8 mm | 18.8 mm x 16.9 mm x 13 mm | Through Hole | Off-Line Transformer We-Unit | - 40 C to + 125 C | - | - | - | 2.77 Ohms | Offline Transformers | 2.77 Ohms | 0.024 Ohms | - | - | - | - | - | 450 mA | 100 kHz | - | 6 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
変圧器 オーディオとシグナル WE-UNIT Off-Line 1.85mH 4.6ohm Transformers Audio & Signal WE-UNIT Off-Line 1.85mH 4.6ohm Midcom / Wurth Electronics | 11 | 1: ¥65.484 | RoHS Compliant | Tray | 15.75 mm L x 15 mm W x 18.5 mm H | General Purpose Transformers | 1.85 uH | 4.5 kV | 15 mm | 18.5 mm | 15.75 mm | 15.75 mm x 15 mm x 18.5 mm | Through Hole | Off-Line Transformer We-Unit | - 40 C to + 125 C | - | - | - | 4.6 Ohms | - | - | - | - | - | - | - | - | 230 mA | 100 kHz | - | 7 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 変圧器 オーディオとシグナル Flyback Transformer 25uH 0.275ohm TRANS FLYBACK LT3573 25UH SMD Transformers Audio & Signal Flyback Transformer 25uH 0.275ohm Midcom / Wurth Electronics | 49 | 1: ¥46.784 | Lead free / RoHS Compliant | Tape & Reel (TR) | 15.24mm L x 13.34mm W | - | - | 1500Vrms | - | - | - | - | - | For DC/DC Converters | -40°C ~ 125°C | 732-2219-2 | 250 | Surface Mount | - | - | - | - | 11.43mm | Flyback Converters | LT3573, LT3574, LT3575, LT3748 | Linear Technology | 18 ~ 30V | - | - | 200kHz | - | 12V @ 20mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Transformers Audio & Signal Common Mode Choke for US and Europe CHOKE COM MODE TPS92210DR 45MH Midcom / Wurth Electronics | 365 | 1: ¥28.152 | RoHS Compliant | Tube | 0.620" L x 0.343" W (15.75mm x 8.71mm) | Transformers | 45mH | 1500 VAC | 8.71 mm | 13 mm | 15.75 mm | Vertical, 4 PC Pin | Through Hole | Power Transformers | -40°C ~ 125°C | 732-2902-5 | 140 | Through Hole | 10.05 Ohms | Control Transformers | 10.05 Ohms | 10.05 Ohms | - | - | - | - | - | 180 mA | 300 kHz | - | - | - | - | - | - | - | - | - | 10.05 Ohm | - | - | - | - | - | - | - | - | - | - | - | - | 200mA | Power Line | 0.512" (13.00mm) | 2 |
 Transformers Audio & Signal Transformer 270uH 0.135ohm TRANS BUCK SSL2101 142UH RAD Midcom / Wurth Electronics | 46 | 1: ¥92.752 | RoHS Compliant | Tray | 13.80mm L x 13.80mm W | Transformers | 270 uH | 1000Vrms | 13.97 mm | 12.7 mm | 13.97 mm | 13.97 mm x 13.97 mm x 12.7 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2903 | 50 | Through Hole | 0.135 Ohms | Control Transformers | 400 mOhms | 0.4 Ohms | 12.70mm | LED Drivers, AC/DC SMPS | SSL2101 | NXP Semiconductors | 130V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Transformers Audio & Signal Flyback Transformer TRANS FLYBACK CY8CLEDAC02 1.2MH Midcom / Wurth Electronics | 17 | 1: ¥111.112 | RoHS Compliant | Tray | 18.80mm L x 16.90mm W | Transformers | 1.2 mH | 1500Vrms | 16.9 mm | 13.31 mm | 18.8 mm | 18.8 mm x 16.9 mm x 13.31 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2906 | 1 | Through Hole | 0.815 Ohms | Control Transformers | 2.9 Ohms | 0.24 Ohms | 13.31mm | LED Drivers, AC/DC SMPS | CY8CLEDAC02 | Cypress Semiconductor Corp | 153 ~ 187V | 540 mA | 65 kHz | 65kHz | - | 12.2V @ 10mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Transformers Audio & Signal Flyback Transformer for Compact Size TRANS FLYBACK NCL30000 870UH Midcom / Wurth Electronics | 38 | 1: ¥59.50 | RoHS Compliant | Tray | 21.08mm L x 21.59mm W | Transformers | 870 uH | 4500Vrms | 21.59 mm | 10.8 mm | 21.08 mm | 21.08 mm x 21.59 mm x 10.8 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2897 | 50 | Through Hole | 0.68 Ohms | Control Transformers | 680 mOhms | 0.057 Ohms | 10.80mm | LED Drivers, AC/DC SMPS | NCL30000 | On Semiconductor | - | - | - | - | 5 W to 75 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Transformers Audio & Signal Flyback Transformer TRANS FLYBACK ON SEMI NCP1652 Midcom / Wurth Electronics | 10 | 100: ¥44.3496 | RoHS Compliant | Tray | 35.56mm L x 37.34mm W | Transformers | 625 uH | 3000Vrms | 35.56 mm | 34.29 mm | 37.34 mm | 37.34 mm x 35.56 mm x 34.29 mm | Through Hole | For AC/DC Converters | - 40 C to + 125 C | 732-2260 | 100 | Through Hole | 0.28 Ohms | Control Transformers | 280 mOhms | 0.140 Ohms | 34.29mm | Flyback Converters | NCP1652 | On Semiconductor | - | 1.5 A | 70 kHz | - | 5 W to 75 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Transformers Audio & Signal Offline Transformer TRANS OFF LINE POWER PI LNK603 Midcom / Wurth Electronics | 123 | 1: ¥60.316 | RoHS Compliant | Tray | 24.38mm L x 20.32mm W | Transformers | 2.28 mH | 4000Vrms | 20.32 mm | 16 mm | 24.38 mm | 24.38 mm x 20.32 mm x 16 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2245 | 250 | Through Hole | 2.15 Ohms | Offline Transformers | 2.15 Ohms | 0.025 Ohms | 16.00mm | Flyback Converters | LNK603 | Power Integrations | 120 ~ 375V | 300 mA | 66 kHz | 66kHz | 2.4 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Transformers Audio & Signal MID-UNIT Transformer 1.07mH 10kHz .118ohm TRANS OFF LINE POWER PI LNK616 Midcom / Wurth Electronics | 20 | 1: ¥107.78 | RoHS Compliant | Tray | 24.38mm L x 20.32mm W | Transformers | 1.07 mH | 4000Vrms | 20.32 mm | 16 mm | 24.38 mm | 24.38 mm x 20.32 mm x 16 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2247 | 250 | Through Hole | 2.05 Ohms | Offline Transformers | 2.05 Ohms | 0.015 Ohms | 16.00mm | Flyback Converters | LNK616 | Power Integrations | 120 ~ 375V | 700 mA | 65 kHz | 65kHz | 5 W | - | MID-UNIT | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Transformers Audio & Signal MID-UNIT Transformer 2.64mH 10kHz 2.15ohm TRANS OFF LINE POWER PI LNK362 Midcom / Wurth Electronics | 47 | 1: ¥107.78 | RoHS Compliant | Tray | 24.38mm L x 20.32mm W | Transformers | 2.64 mH | 4000Vrms | 20.32 mm | 16 mm | 24.38 mm | 24.38 mm x 20.32 mm x 16 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2248 | 250 | Through Hole | 2.85 Ohms | Offline Transformers | 2.85 Ohms | 0.04 Ohms | 16.00mm | Flyback Converters | LNK362 | Power Integrations | 120 ~ 375V | 350 mA | 132 kHz | 132kHz | 2 W | - | MID-UNIT | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Transformers Audio & Signal MID-UNIT Transformer 2.58mH 10kHz .118ohm TRANS OFF LINE POWER PI LNK613 Midcom / Wurth Electronics | 67 | 1: ¥107.78 | RoHS Compliant | Tray | 24.38mm L x 20.32mm W | Transformers | 2.58 mH | 4000Vrms | 20.32 mm | 16 mm | 24.38 mm | 24.38 mm x 20.32 mm x 16 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2246 | 250 | Through Hole | 3.05 Ohms | Offline Transformers | 3.05 Ohms | 0.015 Ohms | 16.00mm | Flyback Converters | LNK613 | Power Integrations | 120 ~ 375V | 330 mA | 65 kHz | 65kHz | 2.8 W | - | MID-UNIT | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Transformers Audio & Signal Flyback Transformer for US TRANS FLYBACK TPS92210DR 430UH Midcom / Wurth Electronics | 36 | 1: ¥59.50 | RoHS Compliant | Tray | 14.40mm L x 22.25mm W | Transformers | 430 uH | 3750VDC | 14.4 mm | 22.86 mm | 22.25 mm | 22.25 mm x 14.4 mm x 22.86 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2908 | 99 | Through Hole | 0.26 Ohms | Control Transformers | 260 mOhms | 0.16 Ohms | 22.86mm | LED Drivers, AC/DC SMPS | TPS92210DR | Texas Instruments | 88 ~ 269V | - | 130 kHz | 130kHz | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Transformers Audio & Signal Offline Transformer TRANS OFF LINE POWER PI LNK564 Midcom / Wurth Electronics | 65 | 1: ¥107.78 | RoHS Compliant | Tray | 24.38mm L x 20.32mm W | Transformers | 2.7 mH | 4000Vrms | 20.32 mm | 16 mm | 24.38 mm | 24.38 mm x 20.32 mm x 16 mm | Through Hole | For AC/DC Converters | -40°C ~ 125°C | 732-2249 | 250 | Through Hole | 3.35 Ohms | Offline Transformers | 3.35 Ohms | 0.028 Ohms | 16.00mm | Flyback Converters | LNK564 | Power Integrations | 120 ~ 375V | 250 mA | 132 kHz | 132kHz | 2 W | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 TRANS POWR FOR LT3751/LT3750 SMD Transformers Audio & Signal WE-FB Flyback XFMR 10.0uH +-10% Wurth Electronics Inc | 892 | 1: ¥32.776 | Lead free / RoHS Compliant | Tape & Reel (TR) | 23.11mm L x 18.01mm W | Transformers | 10 uH | 1000VDC | 18.01 mm | 9.4 mm | 23.11 mm | 23.11 mm x 18.01 mm x 9.4 mm | SMD/SMT | For DC/DC Converters | - | 732-2128-1 | 200 | Surface Mount | 0.02 Ohms | Flyback Transformers | 1.45 Ohms | 1.45 Ohms | 9.40mm | Flyback Converters | LT3751, LT3750 | Linear Technology | 3 ~ 24V | 3 A | 100 kHz to 400 kHz | 100 ~ 400kHz | - | - | - | - | - | - | - | - | - | Transformers Audio & Signal | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 TRANS POWER FOR LT3751 SMD Transformers Audio & Signal WE-FB Flyback XFMR 5.0uH +-10% Wurth Electronics Inc | 174 | 1: ¥82.28 | RoHS Compliant | Tray | 42.00mm L x 36.50mm W | Transformers | 5 uH | 1000Vrms | 36.5 mm | 23 mm | 42 mm | 42 mm x 36.5 mm x 23 mm | SMD/SMT | For DC/DC Converters | -40°C ~ 125°C | 732-2130 | 125 | Surface Mount | 0.01 Ohms | Flyback Transformers | 500 mOhms | 0.5 Ohms | 23.00mm | Capacitor Charger | LT3751 | Linear Technology | 18 ~ 30V | 18 A | - | - | - | - | - | - | - | - | - | - | - | Transformers Audio & Signal | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
