OSRAM Opto Semiconductors GmbH- 机架配件
机架配件 - 型号列表
共 60 个型号| 制造商零件编号 | 库存 | 价格 | 标准包装数量 | RoHS | 光通量 | 视角 | LED正向电压 | LED颜色 | 透镜样式 | 安装类型 | 引脚数 | 磁芯材质 | 包装数量 | 背景色 | LED数量 | 光通量 @ 电流/温度 | 封装形式 | 供电电压 | 输出电流 | 包装方式 | 颜色 | 最大额定电流 | 光效 @ 测试电流 | 25°C时测试电流下的光通量 | 光通量 @ 85°C, 测试电流 | 色温 (K) | 系列 | 显色指数（CRI） | LED | 透镜样式/尺寸 | 尺寸/外形 | 触点数 | 光学元件形状 | 其他名称 | 灯类型 | 灯颜色 | 安装样式 | 类型 | 透镜类型 | 高度 | 零件号别名 | 产品类别 | 工厂包装数量 | 封装热阻 | LED正向电流 | 宽度 | 长度 | 照明颜色 | 毫坎德拉等级 | 主波长 | 工作温度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 LED Uni-Color White 2-Pin SMD T/R LED,OSLON BLACK,White,6500K osram opto semiconductor | 2730 | 2: ¥21.4948 | Tape & Reel | Compliant | 56600 mcd | 90 ° | 3.7 V | White | Circular | PCB Surface Mount | 3 | InGaN | 3.95 x 3.85 x 2.41mm | 6500K | 1 | 56600 mcd | 2SMD | - | - | - | White | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 6500 K | Top Mount | Uni-Color | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED Uni-Color White 2-Pin SMD T/R Golden DRAGON Oval Plus,cool white osram opto semiconductor | 3743 | 1: ¥15.674 | Tape & Reel | Compliant | 112(Max) lm | 120/70 ° | 3.7 V | White | Oval | PCB Surface Mount | 2 | InGaN | 10.3 x 10 x 4.5mm | 6500K | 1 | 95830 mcd | 2SMD | - | - | - | White | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 6500 K | Top Mount | Uni-Color | Colorless | - | - | - | - | - | - | - | - | - | - | - | - |
 LED Uni-Color White 4-Pin PLCC T/R LED TOPLED WARM WHT 2700K 4-PLCC Power TOPLED Wm Wh,LCW E6SG-V1AB-4U9X Osram Opto Power TOPLED 系列 白色 2700K LED, , 3.8 V, 120 °视角, 4 针 PLCC 4 贴装 osram opto semiconductor | 40 | 20: ¥3.373 | Tape & Reel | Lead free / RoHS Compliant | 1800(Max) mcd | 120 ° | 3.8 V | White | Circular | Surface Mount | 4 | InGaN | 3.4 x 3 x 2.1mm | 2700K | 1 | 3.94 lm | 4PLCC | 3.4V | 30mA | Tape & Reel (TR) | White | - | - | - | - | - | Power TOPLED | - | 1 | Round with Flat Top, 2.4mm | 3.50mm L x 2.80mm W | 4 | 圆形 | 475-2609-1 | - | 4200(Max) K | Top Mount | Uni-Color | Colored Diffused | 1.90mm | - | - | - | - | - | - | - | - | 1255mcd | 2700K | - |
 LED Uni-Color White 2-Pin SMD T/R LED GOLDEN DRAGON PLUS 6500K SMD Golden DRAGON+,Ultra White,o/couple lens Osram Opto Golden DRAGON Plus 系列 白色 5700K 大功率 LED , 3.2 V, 170°视角, 表面安装 osram opto semiconductor | 10 | 1: ¥10.744 | Tape & Reel | Lead free / RoHS Compliant | 130 lm | 170° | 3.7 V | White | Circular | Surface Mount | 2 | InGaN | 7.2 x 6.2mm | 5700K | 1 | 212 lm | 2-SMD, Gull Wing | 3.2V | 350mA | Tape & Reel (TR) | 5700K | 1A | 95 lm/W | 106 lm (82 lm ~ 130 lm) | 80 lm | 6500K (Typ) | Golden DRAGON Plus | - | 1 | 170 ° | 7.2 x 6.2 x 3.1mm | 2 | 圆顶 | - | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED Uni-Color White 2-Pin SMD T/R Golden DRAGON+,Wm White,2700K,52lm min Osram Opto Golden DRAGON Plus 系列 白色 2700K 大功率 LED , 3.7 V, 170°视角, 表面安装 osram opto semiconductor | 199 | 1: ¥9.67 | Tape & Reel | Compliant | 19800 mcd | 170 ° | 3.7 V | White | Circular | PCB Surface Mount | 2 | InGaN | 7.2 x 6.2mm | 2700K | 1 | 19800 mcd | 2SMD | 3.7 V | - | - | White | - | - | - | - | - | Golden DRAGON Plus | - | 1 | 170 ° | 7.2 x 6.2mm | 2 | 圆形 | - | 透明 | 2700 K | Top Mount | Uni-Color | Colorless Non Diffused | - | - | - | - | - | - | - | - | - | - | - | - |
LED Uni-Color White 2-Pin SMD T/R Golden DRAGON+,White,o/couple lens osram opto semiconductor | 3149 | 1: ¥18.632 | Tape & Reel | Compliant | 130 lm | 170 ° | 3.7 V | White | Circular | PCB Surface Mount | 2 | InGaN | 7.2 x 6.2mm | 6200K | 1 | 28400 mcd | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED OSLON SSL 80 WHITE LED,OSLON SSL 80deg,White,3000K,CRI 80 Osram Opto OSLON SSL 80 系列 白色 3000K 大功率 LED , 3.25 V, 80 °视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 72 | 2: ¥8.32 | 600 | Lead free / RoHS Compliant | 97 → 121 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 3000K | 1 | 196 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 3000K | 800mA | 106 lm/W | 109 lm (97 lm ~ 121 lm) | 104 lm | 3000K | OSLON SSL 80 | 83 | 1 | 80 ° | 3.1 x 3.1 x 2.35mm | 2 | 圆形 | 475-2976-1 | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 LED OSLON SSL 150 WHITE LED,OSLON SSL 150deg,White,3000K,97lm Osram Opto OSLON SSL 150 系列 白色 3000K 大功率 LED , 3.25 V, 150°视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 5486 | 2: ¥10.6964 | 600 | Lead free / RoHS Compliant | 97 → 121 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 3000K | 1 | 207 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 3000K | 800mA | 106 lm/W | 109 lm (97 lm ~ 121 lm) | 104 lm | 3000K | OSLON SSL 150 | 83 | 1 | 150 ° | 3.1 x 3.1 x 1.58mm | 2 | 圆形 | 475-2981-1 | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 80 WHITE LED,OSLON SSL 80deg,White,5000K,121lm Osram Opto OSLON SSL 80 系列 白色 5000K 大功率 LED , 2.95 V, 80 °视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 56 | 50: ¥8.50 | 600 | Lead free / RoHS Compliant | 121 → 150 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 5000K | 1 | 258 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 5000K | 800mA | 132 lm/W | 136 lm (121 lm ~ 150 lm) | 122 lm | 5000K | OSLON SSL 80 | 70 | 1 | 80 ° | 3.1 x 3.1 x 2.3mm | 2 | 圆顶 | 475-2980-1 | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 4000K WHITE SMD LED,OSLON SSL 80deg,White,4000K,112lm Osram Opto OSLON SSL 80 系列 白色 4000K LED , 3.25 V, 80 °视角, 表面安装 OSRAM Opto Semiconductors Inc | 4063 | 2: ¥14.4432 | 600 | Compliant | 112 → 140 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 4000K | 1 | 227 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 4000K | 800mA | 122 lm/W | 126 lm (112 lm ~ 140 lm) | 113 lm | 4000K | OSLON SSL 80 | 70 | 1 | 80 ° | 3.1 x 3.1 x 2.35mm | 2 | 圆形 | LCWCR7P.PC-LPLR-5L7N-1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 4000K WHITE SMD LED,OSLON SSL 150deg,White,4000K,112lm Osram Opto OSLON SSL 150 系列 白色 4000K 大功率 LED , 3.25 V, 150°视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 144 | 2: ¥9.81 | 600 | Compliant | 112 → 140 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 4000K | 1 | 239 lm | 2-SMD, No Lead, Exposed Pad | 3.1V | 350mA | Tape & Reel (TR) | 4000K | 800mA | 116 lm/W | 126 lm (112 lm ~ 140 lm) | 120 lm | 4000K | OSLON SSL 150 | 70 | 1 | 150 ° | 3.1 x 3.1 x 1.58mm | 2 | 圆形 | LCWCRDP.PC-LPLR-5L7N-1 | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 6500K WHITE SMD LED,OSLON SSL 80deg,White,6000K,130lm High Power LEDs - White White 6500K Street White Osram Opto OSLON SSL 80 系列 白色 6000K 大功率 LED , 2.95 V, 80 °视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 1164 | 1: ¥15.844 | 600 | Compliant | 130 → 164 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 6000K | 1 | 331 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 6000K | 1A | 142 lm/W | 147 lm (130 lm ~ 164 lm) | 132 lm | 6000K | OSLON SSL 80 | 70 | 1 | 80 ° | 3.1 x 3.1 x 2.35mm | 2 | 圆顶 | - | 透明 | 6000 K | SMD/SMT | - | - | 2.23 mm | Q65111A2506 | High Power LEDs - White | 600 | 9.6°C/W | 350 mA | 3 mm | 3 mm | Cool White | - | - | - 40 C |
LED OSLON SSL 6500K WHITE SMD LED,OSLON SSL 150deg,White,6000K,130lm High Power LEDs - White White 6500K Street White OSRAM Opto Semiconductors Inc | 1941 | 1: ¥14.008 | 600 | Compliant | 130 → 164 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 6000K | 1 | 331 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | - | 1A | 142 lm/W | 147 lm (130 lm ~ 164 lm) | 132 lm | 6000K | OSLON SSL 150 | 70 | - | - | - | - | - | - | - | 6000 K | SMD/SMT | - | - | 1.58 mm | Q65111A2505 | High Power LEDs - White | 600 | 9.6°C/W | 350 mA | 2.7 mm | 2.7 mm | Cool White | - | - | - |
LED OSLON SSL 5000K WHITE SMD LED,OSLON SSL 150deg,White,5000K,121lm OSRAM Opto Semiconductors Inc | 18 | 2: ¥11.68 | 600 | Compliant | 121 → 150 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 5000K | 1 | 258 lm | 2-SMD, No Lead, Exposed Pad | 3.1V | 350mA | Tape & Reel (TR) | - | 800mA | 125 lm/W | 136 lm (121 lm ~ 150 lm) | 258 lm | 5000K | - | 70 | - | - | - | - | - | LCWCRDP.PC-LQLS-5H7I-1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 4000K WHITE SMD LED,OSLON SSL 80deg,White,4000K,CRI 80 OSRAM Opto Semiconductors Inc | 5087 | 2: ¥11.5328 | 600 | Compliant | 104.2 → 130 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 4000K | 1 | 211 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | - | 800mA | 113 lm/W | 117 lm (104 lm ~ 130 lm) | 111 lm | 4000K | - | 83 | - | - | - | - | - | LCWCR7P.EC-KULQ-5L7N-1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 4000K WHITE SMD LED,OSLON SSL 150deg,White,4000K,104.2lm Osram Opto OSLON SSL 150 系列 白色 4000K 大功率 LED , 3.25 V, 150°视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 52 | 2: ¥8.12 | 600 | Compliant | 104.2 → 130 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 4000K | 1 | 222 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 4000K | 800mA | 113 lm/W | 117 lm (104 lm ~ 130 lm) | 111 lm | 4000K | OSLON SSL 150 | 83 | 1 | 150 ° | 3.1 x 3.1 x 1.58mm | 2 | 圆形 | LCWCRDP.EC-KULQ-5L7N-1 | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 2700K WHITE SMD LED,OSLON SSL 80deg,White,2700K,CRI 77 OSRAM Opto Semiconductors Inc | 2976 | 1: ¥14.008 | 600 | Compliant | 97 → 121 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 2700K | 1 | 196 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | - | 800mA | 106 lm/W | 109 lm (97 lm ~ 121 lm) | 104 lm | 2700K | - | 83 | - | - | - | - | - | LCWCR7P.EC-KTLP-5U8X-1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 2700K WHITE SMD LED,OSLON SSL 150deg,White,2700K,97lm Osram Opto OSLON SSL 150 系列 白色 2700K 大功率 LED , 3.25 V, 150°视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 467 | 1: ¥14.008 | 600 | Compliant | 97 → 121 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 2700K | 1 | 207 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 2700K | 800mA | 106 lm/W | 109 lm (97 lm ~ 121 lm) | 104 lm | 2700K | OSLON SSL 150 | 83 | 1 | 150 ° | 3.1 x 3.1 x 1.58mm | 2 | 圆形 | LCWCRDP.EC-KTLP-5U8X-1 | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 5000K WHITE SMD LED,OSLON SSL 80deg,White,5000K,CRI 80 Osram Opto OSLON SSL 80 系列 白色 5000K 大功率 LED , 3.25 V, 80 °视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 86 | 2: ¥8.28 | 600 | Compliant | 112 → 140 lm | 80° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 2.35mm | 5000K | 1 | 227 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 5000K | 800mA | 122 lm/W | 126 lm (112 lm ~ 140 lm) | 120 lm | 5000K | OSLON SSL 80 | 83 | 1 | 80 ° | 3.1 x 3.1 x 2.35mm | 2 | 圆形 | - | 透明 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
LED OSLON SSL 5000K WHITE SMD LED,OSLON SSL 150deg,White,5000K,112lm High Power LEDs - White White 5000K Osram Opto OSLON SSL 150 系列 白色 5000K 大功率 LED , 3.25 V, 150°视角 3030 (1212) 贴装 OSRAM Opto Semiconductors Inc | 54 | 1: ¥14.008 | 600 | Compliant | 112 → 140 lm | 150° | 3.25 V | White | Circular | Surface Mount | 2 | GaN | 3.1 x 3.1 x 1.58mm | 5000K | 1 | 239 lm | 2-SMD, No Lead, Exposed Pad | 2.95V | 350mA | Tape & Reel (TR) | 5000K | 800mA | 122 lm/W | 126 lm (112 lm ~ 140 lm) | 120 lm | 5000K | OSLON SSL 150 | 83 | 1 | 150 ° | 3.1 x 3.1 x 1.58mm | 2 | 圆形 | - | 透明 | - | - | - | - | - | Q65111A2588 | High Power LEDs - White | 600 | 9.6°C/W | - | - | - | - | - | - | - |
