脉冲电源解决方案
Microchip Technology Inc.- 脉冲电源解决方案
02
MODELS脉冲电源解决方案 - 型号列表共 954 个型号
| 制造商零件编号 | 价格/库存 | Package | Number of Supervisors | Minimum Reset Threshold Voltage | Minimum Operating Supply Voltage | Maximum Operating Supply Voltage | Watchdog Timer | Operating Temperature | Mounting | Standard Package | Packaging | Reset | Voltage - Threshold | Mounting Type | Supplier Device Package | Number of Voltages Monitored | Output | Type | Package/Case | rohs | Maximum Operating Temperature | Minimum Operating Temperature | Factory Pack Quantity | Operating Supply Current | Package / Case | Mounting Style | Product Category | Undervoltage Threshold | Supply Voltage - Max | Supply Voltage - Min | RoHS | Manual Reset | Watchdog | Overvoltage Threshold | Maximum Supply Current | Maximum Reset Threshold Voltage | Reset Timeout | Threshold Voltage | Unit Pack | MOQ | Output Driver | Height | Length | Width | Power Fail Detection | Chip Enable Signals | Output Type | Battery Backup Switching | Monitored Voltage | Pin Count | Package Type | Supply Current | Maximum Reset Active Time | Reset Delay Time | No. of Supervisors / Monitors | Supply Voltage Min | Supply Voltage Max | Reset Type | Digital IC Case Style | No. of Pins | Operating Temperature Min | Operating Temperature Max | MSL | SVHC | Operating Temperature Range | Supply Voltage Range | Weight (kg) | Tariff No. | Other Names | Dimensions | Delay Time | Base Number | Series | Matchcode | Standard Leadtime | Reset threshold | Leadfree Defin. | Mode | Op.temp.R.max | Automotive | Op.temp.R.min | Reset-Output | Supply voltage | Case | Multiplicity | Active logical level | Integrated circuit type | Gross weight | Operating voltage | Standby current | Kind of RESET output | Collective package [pcs] | Controlled voltage | spg | Number of Inputs Monitored | Watchdog Timers | Brand | Supply-current | IC Generic Number | Operating Temp Range | Number of Elements | Operating Temperature Classification | Monitored Voltage 1 (Typ) | Rad Hardened | Operating Supply Voltage (Min) | Operating Supply Voltage (Max) | Reset Threshold Voltage (Max) | Reset Threshold Voltage (Min) | Turn On Threshold Voltage | Current,Supply | PackageType | Temperature,Operating,Range | Voltage,Input | Voltage,Output,Low | Voltage,Supply | Voltage,Output | Voltage,Output,High | Maximum Monitored Voltage | Minimum Monitored Voltage | Termination Type | Reset Active Time | Voltage Supervisor Type | Output Current | 最高工作温度 | 安装类型 | 引脚数目 | 高度 | 输出驱动器 | 最低工作温度 | 监控器数目 | 最大监控电压 | 最小监控电压 | 封装类型 | 最大工作电源电压 | 长度 | 宽度 | 最小工作电源电压 | 尺寸 | Logic Function Number | Output Current Max | Maximum Power Dissipation | Typical Reset Threshold Voltage | Package Width | PCB | Screening Level | EU RoHS | Minimum Reset Threshold Voltage | Minimum Operating Temperature | Supplier Package | Standard Package Name | Maximum Operating Temperature | Maximum Reset Threshold Voltage | Monitored Voltage | Package Length | Minimum Operating Supply Voltage | Package Height | Maximum Supply Current | Maximum Operating Supply Voltage | Lead Shape | Supply Current (Typ) | Microprocessor Support IC Features | Microprocessor Support IC Type | 最长复位有效时间 | Pd - Power Dissipation | Programmability | Tolerance | Power-Up Reset Delay (Typ) | Typical Operating Supply Voltage | Typical Operating Supply Voltage | Maximum Reset Active Time | Operating Supply Voltage (Typ) | IC Temperature Range | Current,Output | Time,Fall | Time,Rise |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 | 询价 | 3SOT-23 | 1 | 2.85 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | REEL | Active Low | 2.925V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | +85 °C | -40 °C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 2.85 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 3 V | 60 uA | 3 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active Low/Open Drain | 0.95mm | 2.9mm | 1.3mm | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | 3 | SOT-23 | :45µA | 350(Typ) ms | 350 ms | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (16-Dec-2013) | :-40°C to +85°C | :1V to 5.5V | 0.002 | 85423190 | MCP130T-300I/TTCT | 2.9 x 1.3 x 0.95mm | :350ms | :130 | MCP130 | MCP130T-300I/TT | 17 weeks | 2.93V | RoHS-conform | POS | 85°C | NO | -40°C | OPEN DRAIN | 5.5V | SOT23 | 1 | low | Supervisor Integrated Circuit | 0.04 g | 1...5.5V | 45µA | open-drain | 3000 | 3,00 V | 3000 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | :2.925V | 45μA | SOT-23 | -40to+85°C | -0.6to+6.5V | 0.4V | 1to5.5V | -0.6to+6.5V | 4.8V | - | - | :SMD | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 3 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | REEL | Active Low | 3.075V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | + 85 C | - 40 C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 3 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 3.15 V | 60 uA | 3.15 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active Low/Open Drain | - | - | - | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | - | - | :45µA | 350(Typ) ms | 350 ms | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +85°C | :1V to 5.5V | 0.000033 | 85423190 | MCP130T-315I/TTCT | - | :350ms | :130 | - | MCP130T-315I/TT | 18 weeks | 3.08V | RoHS-conform | POS | 85°C | NO | -40°C | OPEN DRAIN | 5.5V | SOT23 | 1 | low | Supervisor Integrated Circuit | 0.15 g | 1...5.5V | 45µA | open-drain | 300 | 3,15 V | 300 | - | - | - | 32µA | :130 | - | - | - | - | - | - | - | - | - | :3.075V | 45μA | SOT-23 | -40to+85°C | -0.6to+6.5V | 0.4V | 1to5.5V | -0.6to+6.5V | 4.8V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 4.5 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | REEL | Active Low | 4.625V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | +85 °C | -40 °C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 4.5 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.75 V | 60 uA | 4.75 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active Low/Open Drain | 0.95mm | 2.9mm | 1.3mm | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | 3 | SOT-23 | :45µA | 350(Typ) ms | 350 ms | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +85°C | :1V to 5.5V | 0.000033 | 85423190 | MCP130T-475I/TTCT | 2.9 x 1.3 x 0.95mm | :350ms | :130 | - | MCP130T-475I/TT | 17 weeks | 4.63V | RoHS-conform | POS | 85°C | NO | -40°C | OPEN DRAIN | 5.5V | SOT23 | 1 | low | Supervisor Integrated Circuit | 0.04 g | 1...5.5V | 45µA | open-drain | 3000 | 4,75 V | 3000 | - | - | - | 32µA | :130 | - | - | - | - | - | - | - | - | - | :4.625V | 45μA | SOT-23 | -40to+85°C | -0.6to+6.5V | 0.6V | 1to5.5V | -0.6to+6.5V | 4.8V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 4.25 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | Tape & Reel (TR) | Active High | 4.375V | Surface Mount | SOT-23-3 | 1 | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | +85 °C | -40 °C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 4.25 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.5 V | 60 uA | 4.5 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active High/Push-Pull | 0.95mm | 2.9mm | 1.3mm | No | No Chip Enable | Active High, Push-Pull | No Backup | 3|3.3|5 V | 3 | SOT-23 | 0.06 mA | - | - | :1 | :1V | :5.5V | :Active-High | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +85°C | :1V to 5.5V | 0.000033 | 85423190 | - | 2.9 x 1.3 x 0.95mm | :350ms | :101 | - | - | - | - | - | - | - | - | - | - | - | SOT23 | 1 | high | Supervisor Integrated Circuit | 0.04 g | 1...5.5V | 45µA | push-pull | 3000 | 4,50 V | 3000 | - | - | - | - | :101 | -40C to 85C | 1 | Industrial | 3/3.3/5 V | No | 1 V | 5.5 V | 4.5 V | 4.25 V | :4.375V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 4.35 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Cut Tape | REEL | Active Low | 4.475V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | + 85 C | - 40 C | 3000 | 45 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 4.35 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.6 V | 60 uA | 4.6 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active Low/Open Drain | - | - | - | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | 3 | SOT-23 | 0.06 mA | 350(Typ) ms | 350 ms | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (16-Dec-2013) | :-40°C to +85°C | :1V to 5.5V | 0.0002 | 85423990 | MCP120T-460I/TTCT | - | :350ms | :120 | - | MCP120T-460I/TT | 14 weeks | 4.48V | RoHS-conform | POS | 85°C | NO | -40°C | OPEN DRAIN | 5.5V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 32µA | - | -40C to 85C | 1 | Industrial | 3/3.3/5 V | No | 1 V | 5.5 V | 4.6 V | 4.35 V | - | - | - | - | - | - | - | - | - | - | - | - | 350ms(Typ) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23B | 1 | 2.866 V | 1 V | 5.5 V | No | -40 to 125 °C | Surface Mount | Cut Tape | Tape & Reel (TR) | Active Low | 2.93V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Supply Voltage Supervisory | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | +125 °C | -40 °C | 3000 | 20 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 2.866 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 2.974 V | 20 uA | 2.974 V | 80 ms Minimum | 2.93 V | - | - | - | 0.95mm | 2.92mm | 1.3mm | - | - | - | - | - | 3 | SOT-23B | :20µA | - | - | :1 | :1V | :5.5V | :Active-Low | :SOT-23B | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (16-Dec-2013) | :-40°C to +125°C | :1V to 5.5V | 0.000033 | 85423990 | MCP121T-300E/TTCT | 2.92 x 1.3 x 0.95mm | :120ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Micropower | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 8SOIC N | 1 | 3 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | Tape & Reel (TR) | Active Low | 3.075V | Surface Mount | 8-SOIC N | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | 8-SOIC (0.154", 3.90mm Width) | Lead free / RoHS Compliant | + 85 C | - 40 C | 3300 | 60 uA | SOIC-8 | SMD/SMT | Supervisory Circuits | 3 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 3.15 V | 60 uA | 3.15 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3300 | 3300 | Active Low/Open Drain | 1.25 mm | 4.9 mm | 3.9 mm | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | - | - | - | 350(Typ) ms | 350 ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | MCP120 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | No Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 4.25 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | REEL | Active Low | 4.375V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | +85 °C | -40 °C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 4.25 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.5 V | 60 uA | 4.5 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active Low/Open Drain | 0.95mm | 2.9mm | 1.3mm | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | 3 | SOT-23 | 0.06 mA | 350(Typ) ms | 350 ms | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +85°C | :1V to 5.5V | 0.000033 | 85423190 | MCP120T-450I/TTCT | 2.9 x 1.3 x 0.95mm | :350ms | :120 | - | MCP120T-450I/TT | 18 weeks | 4.38V | RoHS-conform | POS | 85°C | NO | -40°C | OPEN DRAIN | 5.5V | SOT23 | 1 | low | Supervisor Integrated Circuit | 0.1 g | 1...5.5V | 45µA | open-drain | 300 | 4,50 V | 300 | - | - | - | 32µA | :120 | -40C to 85C | 1 | Industrial | 3/3.3/5 V | No | 1 V | 5.5 V | 4.5 V | 4.25 V | :4.375V | 45μA | SOT-23 | -40to+85°C | -0.6to+6.5V | 0.6V | 1to5.5V | -0.6to+6.5V | - | - | - | - | 350ms(Typ) | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
,TO-226_straightlead.jpg){kind=small} | 询价 | 3TO-92 | 1 | 3 V | 1 V | 5.5 V | No | -40 to 85 °C | Through Hole | Rail / Tube | Bulk | Active High | 3.075V | Through Hole | TO-92-3 | 1 | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | TO-226-3, TO-92-3 (TO-226AA) | Lead free / RoHS Compliant | +85 °C | -40 °C | 1000 | 60 uA | TO-92-3 | Through Hole | Supervisory Circuits | 3 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 3.15 V | 60 uA | 3.15 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 1000 | 2000 | Active High/Push-Pull | 4.62mm | 4.71mm | 3.62mm | No | No Chip Enable | Active High, Push-Pull | No Backup | 3|3.3|5 V | 3 | TO-92 | 0.06 mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 4.71 x 3.62 x 4.62mm | - | - | MCP101 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | No Watchdog | Microchip Technology | - | - | -40C to 85C | 1 | Industrial | 3/3.3/5 V | No | 1 V | 5.5 V | 3.15 V | 3 V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | +85 °C | 通孔 | 3 | 4.62mm | 高电平有效、推挽式 | -40 °C | 1 | 3.15V | 3.07V | TO-92 | 5.5 V | 4.71mm | 3.62mm | 1 V | 4.71 x 3.62 x 4.62mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23B | 1 | 4.561 V | 1 V | 5.5 V | No | -40 to 125 °C | Surface Mount | Tape & Reel | Tape & Reel (TR) | Active Low | 4.63V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Supply Voltage Supervisory | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | +125 °C | -40 °C | 3000 | 20 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 4.561 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.7 V | 20 uA | 4.7 V | 80 ms Minimum | 4.63 V | - | - | - | 1.02mm | 3.04mm | 1.4mm | No | No Chip Enable | Active Low, Open Drain | No Backup | - | 3 | SOT-23B | :1µA | - | 120 ms | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :125°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +125°C | :1V to 5.5V | 0.00004 | 85423190 | MCP121T-475E/TTCT | 3.04 x 1.4 x 1.02mm | :120ms | :121 | - | - | - | - | - | - | - | - | - | - | - | SOT23 | 1 | low | Supervisor Integrated Circuit | 0.51 g | 1...5.5V | 1µA | open-drain | 10 | 4,75 V | 10 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 4.746V | 4.514V | - | - | Power Supply Monitor | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | :121 | :10mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | :Active Low, Open Drain | :Micropower Voltage Supervisor | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3TO-92 | 1 | 4.314 V | 1 V | 5.5 V | No | -40 to 125 °C | Through Hole | Rail / Tube | Bulk | Active Low | 4.38V | Through Hole | TO-92-3 | 1 | Open Drain or Open Collector | Supply Voltage Supervisory | TO-226-3, TO-92-3 (TO-226AA) | Lead free / RoHS Compliant | +125 °C | -40 °C | 1000 | 90 uA | TO-92-3 | Through Hole | Supervisory Circuits | 4.314 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.446 V | 90 uA | 4.446 V | 80 ms Minimum | 4.38 V | 1000 | 2000 | Active Low, Open Drain | 4.95mm | 4.95mm | 3.94mm | - | - | - | - | - | 3 | TO-92 | - | 0.13ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 4.95 x 3.94 x 4.95mm | - | - | MCP131 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | No Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 4.49V | 4.271V | - | - | - | 10 mA | +125 °C | 通孔 | 3 | 4.95mm | 低电平有效、漏极开路 | -40°C | 1 | 4.49V | 4.271V | TO-92 | 5.5 V | 4.95mm | 3.94mm | 1 V | 4.95 x 3.94 x 4.95mm | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 0.13ms | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 5SOT-23 | 1 | 2.857 V | 1 V | 5.5 V | Yes | -40 to 125 °C | Surface Mount | Tape & Reel | Tape & Reel (TR) | Active High/Active Low | 2.9V | Surface Mount | SOT-23-5 | 1 | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | SC-74A, SOT-753 | Contains lead / RoHS non-compliant | + 125 C | - 40 C | 3000 | 10 uA | SOT-23-5 | SMD/SMT | Supervisory Circuits | 2.857 V | 5.5 V | 1 V | RoHS Compliant | Manual Reset | Watchdog | 2.944 V | 10 uA | 2.944 V | 140 ms Minimum | 2 V to 4.7 V | 3000 | 3000 | Active High/Active Low/Push-Pull | 1.3 mm | 3.1 mm | 1.8 mm | No | No Chip Enable | Active High, Active Low, Push-Pull | No Backup | 2 to 4.7 V | - | - | - | 2240 ms | 2240 ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | MCP131 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 240 mW | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 240 mW | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 3 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | REEL | Active Low | 3.075V | Surface Mount | SOT-23-3 | 1 | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | + 85 C | - 40 C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 3 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 3.15 V | 60 uA | 3.15 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 3000 | 3000 | Active Low/Push-Pull | - | - | - | No | No Chip Enable | Active Low, Push-Pull | No Backup | 3|3.3|5 V | 3 | SOT-23 | 0.06 mA | - | - | :1 | :1V | :5.5V | :Active-Low | :SOT-23 | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (16-Dec-2013) | :-40°C to +85°C | :1V to 5.5V | 0.000033 | 85423190 | MCP809T-315I/TTCT | - | - | :809 | - | MCP809T-315I/TT | 18 weeks | 3.08V | RoHS-conform | POS | 85°C | NO | -40°C | PUSH/PULL | 5.5V | SOT23 | 1 | low | Supervisor Integrated Circuit | 0.04 g | 1...5.5V | 45µA | push-pull | 3000 | 3,15 V | 3000 | - | - | - | 45µA | :809 | -40C to 85C | 1 | Industrial | 3/3.3/5 V | No | 1 V | 5.5 V | 3.15 V | 3 V | - | - | - | - | - | - | - | - | - | - | - | :SMD | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 3SC-70 | 1 | 2.591 V | 1 V | 5.5 V | No | -40 to 125 °C | Surface Mount | Tape & Reel | Tape and Reel | Active Low | 2.63V | Surface Mount | SC-70-3 | 1 | Push-Pull, Totem Pole | Supply Voltage Supervisory | SC-70, SOT-323 | Lead free / RoHS Compliant | + 125 C | - 40 C | 3000 | 1 uA | SC-70-3 | SMD/SMT | Supervisory Circuits | 2.591 V | 5.5 V | 1 V | RoHS Compliant | No | No Watchdog | 2.67 V | 1.75 uA | 2.67 V | 80 ms Minimum | 2.63 V | 3000 | 3000 | Active Low/Push-Pull | 1 mm | 2.25 mm (Max) | 1.35 mm | No | No Chip Enable | Push-Pull | No Backup | - | 3 | - | - | - | 120 ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | MCP102 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | No Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 10 mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 2.63 | 1.25 | 3 | Extended | Compliant | 2.591 | -40 | SC-70 | SOT-323 | 125 | 2.67 | 2.63 | 2 | 1 | 1(Max) | 1.75 | 5.5 | Gull-wing | - | - | - | - | - | Yes | - | - | - | - | - | - | - | - | - | - |
| 询价 | 8SOIC N | 1 | 2.85 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Rail / Tube | Tube | Active Low | 2.925V | Surface Mount | 8-SOIC N | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | 8-SOIC (0.154", 3.90mm Width) | Lead free / RoHS Compliant | + 85 C | - 40 C | 100 | 60 uA | SOIC-8 | SMD/SMT | Supervisory Circuits | 2.85 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 3 V | 60 uA | 3 V | 150 ms Minimum | 3 V, 3.3 V, 5 V | 100 | 2000 | Active Low/Open Drain | 1.25 mm | 4.9 mm | 3.9 mm | No | No Chip Enable | Active Low, Open Drain | No Backup | 3|3.3|5 V | - | - | - | 350(Typ) ms | 350 ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | MCP120 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | No Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23B | 1 | 1.872 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | Reel | Active Low | 1.9V | Surface Mount | SOT-23-3 | 1 | Open Drain or Open Collector | Supply Voltage Supervisory | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | + 85 C | - 40 C | 3000 | 20 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 1.872 V | 5.5 V | 1 V | RoHS Compliant | Not Resettable | No Watchdog | 1.929 V | 20 uA | 1.929 V | 80 ms Minimum | 1.9 V | 3000 | 3000 | Active Low | 1.02mm | 3.04mm | 1.4mm | Yes | - | - | - | 1.9 V | 3 | SOT-23B | :1µA | 130ms | - | :1 | :1V | :5.5V | :Active-Low, Open-Drain | :SOT-23B | :3 | :-40°C | :85°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :-40°C to +85°C | :1V to 5.5V | 0.0002 | 85423990 | MCP121T-195I/TTCT | 3.04 x 1.4 x 1.02mm | :120ms | :121 | - | MCP121T-195I/TT | 14 weeks | 1.90V | RoHS-conform | POS | 85°C | NO | -40°C | OPEN DRAIN | 5.5V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1.75µA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1.948V | 1.853V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 20 uA | - | - | - | - | - | 2% | - | - | - | - | - | - | - | - | - |
| 询价 | 3SOT-23 | 1 | 4.35 V | 1 V | 5.5 V | No | -40 to 85 °C | Surface Mount | Tape & Reel | Tape & Reel (TR) | Active High | 4.475V | Surface Mount | SOT-23-3 | 1 | Push-Pull, Totem Pole | Simple Reset/Power-On Reset | TO-236-3, SC-59, SOT-23-3 | Lead free / RoHS Compliant | + 85 C | - 40 C | 3000 | 60 uA | SOT-23-3 | SMD/SMT | Supervisory Circuits | 4.35 V | 5.5 V | 1 V | RoHS Compliant | No Manual Reset | No Watchdog | 4.6 V | 60 uA | 4.6 V | 150 ms Minimum | 4.475 V | 3000 | 3000 | Active High/Push-Pull | 0.95 mm | 2.9 mm | 1.3 mm | No | No Chip Enable | Active High, Push-Pull | No Backup | 3|3.3|5 V | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | MCP810T-460I/TTDKR | - | - | - | MCP810 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | No Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 | 询价 | 4SOT-223 | 1 | 4.25 V | 4.5 V | 5.5 V | Yes | -40 to 85 °C | Surface Mount | Tape & Reel | Reel | Active Low | 4.375V | Surface Mount | SOT-223-3 | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | TO-261-4, TO-261AA | Lead free / RoHS Compliant | + 85 C | - 40 C | 4000 | 200 uA | SOT-223-3 | SMD/SMT | Supervisory Circuits | 4.25 V | 5.5 V | 4.5 V | RoHS Compliant | Not Resettable | Watchdog | 4.5 V | 200 uA | - | 500 ms Minimum | - | 4000 | 4000 | Active Low/Open Drain | 1.6 mm | 6.5 mm | 3.5 mm | No | No | Active Low, Open Drain | No Backup | - | - | - | - | 900 ms | 900 ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | TC32MEDB713DKR | - | - | - | TC32M | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 1 Input | Watchdog | Microchip Technology | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 2 mA | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 200 uA | - | - | - | - | - | - | 900 ms | - | - | - | - | - | - | - | - |
| 询价 | 8SOIC N | 1 | 4.5|4.25 V | 4 V | 5.5 V | Yes | 0 to 70 °C | Surface Mount | Rail / Tube | TUBE | Active High/Active Low | 4.37V, 4.62V | Surface Mount | 8-SOIC N | 1 | Open Drain or Open Collector | Simple Reset/Power-On Reset | 8-SOIC (0.154", 3.90mm Width) | Lead free / RoHS Compliant | +70 °C | 0 °C | 100 | 200 uA | SOIC-8 | SMD/SMT | Supervisory Circuits | 4.5 V, 4.25 V | 5.5 V | 4 V | RoHS Compliant | Yes | YES | 4.74 V, 4.49 V | 200 uA | 4.74|4.49 V | 250 ms Minimum | 4.5 V to 4.75 V | 100 | 100 | Active High/Active Low/Open Drain/Push-Pull | 1.42mm | 4.9mm | 3.91mm | Yes | No | Active High, Active Low, Open Drain, Push-Pull | No | 4.5 to 4.75 V | 8 | SOIC N | 0.2 mA | 1000 ms | 1000 ms | :1 | :4V | :5.5V | :Active-High, Active-Low | :SOIC | :8 | :0°C | :70°C | :MSL 1 - Unlimited | :No SVHC (20-Jun-2013) | :0°C to +70°C | :4V to 5.5V | 0.000152 | 85423190 | - | 4.9 x 3.91 x 1.42mm | :1200ms | :1232 | - | TC1232COA | 14 weeks | 4.63V | RoHS-conform | POS | 70°C | NO | 0°C | OPEN DRAIN | 5.5V | SO8 | 1 | low, high | Supervisor Integrated Circuit | 0.19 g | 4...5.5V | 50µA | open-drain, push-pull | 350 | 4,25 V, 4,50 V | 350 | - | - | - | 50µA | :1232 | 0C to 70C | 1 | Commercial | 4.5 to 4.75 V | No | 4 V | 5.5 V | 4.74/4.49 V | 4.5/4.25 V | - | 50μA | SOIC | 0to+70°C | 5.3V(High),+0.8V(Low) | 0.4V | 5V | - | 2.4V | 4.75V | 4.5V | :SMD | 1000ms | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | :1232 | :-12mA | - | 4.62|4.37 | 3.91 | 8 | Commercial | Compliant | 4.5|4.25 | 0 | SOIC N | SOIC | 70 | 4.74|4.49 | 4.5 to 4.75 | 4.9 | 4 | 1.42 | 200 | 5.5 | Gull-wing | - | - | - | - | - | - | - | - | 5 V | 5 | 1000 | 5 V | :Commercial | -12mA(High),+10mA(Low) | 10μs | 0μs |
| 询价 | 3TO-92 | 1 | 2.06 V | 0.7 V | 10 V | No | -40 to 85 °C | Through Hole | Rail / Tube | Bulk | Active Low | 2.1V | Through Hole | TO-92-3 | 1 | Open Drain or Open Collector | Voltage Detector | TO-226-3, TO-92-3 (TO-226AA) | Lead free / RoHS Compliant | +85 °C | -40 °C | 1000 | 3.6 uA | TO-92-3 | Through Hole | Supervisory Circuits | 2.06 V | 10 V | 0.7 V | RoHS Compliant | No Manual Reset | No Watchdog | 2.14 V | - | 2.14 V | - | 1.1 V to 6 V | 1000 | 3000 | - | 0.210in | 0.205in | 0.165in | - | - | - | - | - | 3 | TO-92 | :1.1µA | - | - | :1 | :0.7V | :10V | :Active-Low, Open-Drain | :TO-92 | :3 | :-40°C | :85°C | :- | :No SVHC (20-Jun-2013) | :-40°C to +85°C | :700mV to 10V | 0.0002 | 85423990 | - | 0.205 x 0.165 x 0.210in | :200µs | :2102 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | Voltage Detector | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | 300 mW | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
第 1 / 48 页
