霍尼韦尔国际公司（Honeywell International Inc.）是一家成立于1885年的跨国多元化高科技制造企业，总部位于美国北卡罗来纳州夏洛特市。1999年，原联信公司（AlliedSignal）与原霍尼韦尔公司合并，形成如今的霍尼韦尔。公司是《财富》500强企业及道琼斯工业平均指数的成分股，在纳斯达克上市，股票代码为HON。霍尼韦尔业务涵盖航空航天、建筑科技、高性能材料技术以及安全与生产力解决方案四大板块，在全球超过100个国家和地区运营。在电子元器件领域，霍尼韦尔是全球领先的传感与物联网解决方案提供商，专注于高性能传感器和开关的研发与生产。核心产品系列包括Data Instruments品牌下的压力传感器、称重传感器，以及线性/旋转电位计位置传感器、硅压力传感器、温度传感器、气体传感器、湿度传感器和磁传感器等。公司还提供微机电系统（MEMS）、热式流量传感器等先进传感技术，广泛应用于工业自动化、汽车、医疗器械和消费电子等领域。霍尼韦尔传感器以高精度、高可靠性和坚固耐用著称，在恶劣环境下具有显著优势。凭借百年技术积累，霍尼韦尔在全球工业传感器市场占据重要地位，尤其在压力和温度传感器细分市场拥有领先份额。公司正大力推动智能传感与物联网融合，每天有数以百万计的霍尼韦尔传感器在全球运行，赋能工业4.0和智慧楼宇。

MODELS

光电断续器 - 型号列表共 320 个型号

制造商零件编号	价格/库存	RoHS	Fall Time	Maximum Operating Temperature	Minimum Operating Temperature	Rise Time	Power Dissipation	Subcategory	Lead Time	Standard Package	Package/Case	rohs	Collector- Emitter Voltage VCEO Max	Type	Series Name	Operating Temperature Range	Package Components	Product Type	Maximum Power Dissipation	Package / Case	Collector-Emitter Breakdown Voltage	Collector-Emitter Saturation Voltage	Product	Emitter-Collector Breakdown Voltage	Package Style	Dark Current	Rise and Fall Time	Light Current Minimum	Viewing Angle	Mounting Type	Polarity	Standard Package Name	EU RoHS	Supplier Package	Pin Count	Wavelength	Voltage - Collector Emitter Breakdown (Max)	Maximum Operating Temperature	Maximum Collector Emitter Saturation Voltage	Maximum Rise Time	Maximum Collector Emitter Voltage	Number of Channels per Chip	Maximum Fall Time	Maximum Dark Current	Maximum Power Dissipation	Minimum Operating Temperature	Phototransistor Type	Half Intensity Angle Degrees	Product Category	Current - Dark (Id) (Max)	Orientation	Power - Max	Maximum Light Current	Maximum Emitter Collector Voltage	Operating Temperature	Lead Shape	Comment	Angular Response (Degree)	Current,Light	Dimensions	Time,Rise	AngularResponse	Current,Dark	Length,Lead	PackageType	PowerDissipation	Temperature,Operating,Maximum	Temperature,Operating,Minimum	Time,Fall	TransistorPolarity	Voltage,Breakdown,CollectortoEmitter	Voltage,Saturation,CollectortoEmitter	Current - Collector (Ic) (Max)	Series	Diameter,Lead	Package Color	Light Current Maximum	Package Type	Package	Packaging	Automotive	典型上升时间	安装类型	针数目	典型下降时间	长度	尺寸	Peak Wavelength	Matchcode	Unit Pack	Standard Leadtime	MOQ	Detection angle	Rise/Fall time	SMD/THT	Dark current	最大光电流	半感光角度	封装类型	最大暗电流	Sens.range min	Sens.range max.	Response Time	Maximum Dark Current	高度	宽度	Reverse Current	视角	取向	电流 - 暗 (Id)（最大值）	封装/外壳	装配类型	功率 - 最大值	波长	电压 - 集射极击穿（最大值）	Collector-emitter voltage	Case colour	Transmission angle	Wavelength of max photosensitivity	Lens Color	Collector-Emitter Voltage	Emitter-Collector Voltage (Max)	Half-Intensity Angle	Mounting	Operating Temp Range	Peak Wavelength	Dark Current (Max)	Light Current	Number of Elements	Operating Temperature Classification	Collector-Emitter Sat Volt (max)	Rad Hardened	Max.sensivity	V(CEO)	极性	通道数目	Photoelectric current min	Photoelectric current	Photoelectric current max	系列	电流 - 集电极 (Ic)（最大值）	Current - Dark (Typ)	Light Current Slope	Knee Point	Collector current	检测频谱	直径	检测到的最大波长	Output Device	Slot Width	Aperture Width	Forward Current	Sensing Method	Sensing Distance	Output Configuration	Lens Type	Output Rise Time	Output Fall Time	Reverse Breakdown Voltage	Hermetic Style	Angle of Half Sensitivity	Height	Length	Number of Channels	Number of Pins	Typical Fall Time	Typical Rise Time	Width	Other Names	Maximum Collector Current	Mounting Style	t rise	Top(max)	Gap width	P tot	Vcc(min)	t fall	Aperture width	Leadfree Defin.	If	Current - DC Forward (If)	Op.temp.max.	Op.temp.min.	Optempmin	Reverse V/Veco	Optempmax	Sensrange min	Sensrange max	Leadfree Defin	Forward Voltage	High Level Output Current	High Level Output Voltage	Low Level Output Current	Low Level Output Voltage	Reverse Voltage	Sensor Aperture	Housing Material	Duration of Output Short Vcc or Ground	Operating Supply Voltage	Hysteresis (H)	IRED Trigger Current	Mounting Configuration	Low Level Supply Current	Output	Propagation Delay&44; Low-High&44;High-Low	Output Logic	High Level Supply Current	Maximum Trigger Current	Supply Voltage	Current - Supply	Voltage - Supply	Continuous Forward Current	Propagation Delay Low-HighHigh-Low	Output Wavelength	Voltage,CollectortoEmitter	检测到的最小波长	PrimaryType
6 SD3410-002 Phototransistors Silicon Photodarling Flat Window Can Honeywell	询价	RoHS Compliant	75 us	+ 125 C	- 55 C	75 us	150 mW	Phototransistor	28 Days	1	TO-46-3 Lens Top Metal Can	Lead free / RoHS Compliant	15 V	Photodetector Transistors	Photodarlington	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	150 mW	TO-46	15 V	1.1 V	Photodarlingtons	5 V	T0-46, Flat Window	250 nA	75 µs	2.0 mA	90°	-	NPN	TO-206-AB	Compliant	TO-46	3	880nm	-	125	1.1	75000(Typ)	15	1	75000(Typ)	250	150	-55	Photodarlington	90	-	-	-	-	2000(Min)	5	-55°C ~ 125°C	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	90	0.6mA	0.153in.Hx0.219in.Dia.	75us	90°	250nA	0.5in.(Min.)	TO-46	150mW	125°C	-55°C	75us	NPN	15V	1.1V	-	-	0.018in.	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	75µs	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	250nA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
6 SD5410-002 Phototransistors Silicon PhtoDrlngton TO-46 Mtl/Gls LnsdPk Honeywell	询价	RoHS Compliant	75 us	+ 125 C	- 55 C	75 us	150 mW	Phototransistor	84 Days	1	TO-46-3 Metal Can	Lead free / RoHS Compliant	15 V	Photodetector Transistors	Photodarlington	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	150 mW	TO-46	15 V	1.1 V	Photodarlingtons	5 V	T0-46, Dome Lensed	250 nA	75 µs	4.0 mA	12°	Through Hole	NPN	TO-206-AB	Compliant	TO-46	3	880nm	15V	125	1.1	75000(Typ)	15	1	75000(Typ)	250	150	-55	Photodarlington	12	Phototransistors	250nA	Top View	150mW	4000(Min)	5	-55 °C to 125 °C [-67 °F to 257 °F]	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	12	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	75µs	通孔安装	3	75µs	5.56mm	5.56 x 5.56 x 3.89mm	-	-	-	-	-	-	-	-	-	4000µA	12 °	TO-46	250nA	-	-	-	250 nA	3.89mm	5.56mm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	NPN	1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
7 SDP8475-201 Phototransistors Low Light Rejection Phototransistor Honeywell	询价	RoHS Compliant	15 us	+ 85 C	- 40 C	15 us	70 mW	Phototransistor	84 Days	1	Radial	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Low Light Rejection Phototransistor	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	70 mW	T-1	30 V	0.4 V	Phototransistors	5 V	T1	100 nA	15 µs	4.0 mA	20°	Through Hole	NPN	-	-	-	-	935nm	30V	-	-	-	-	-	-	-	-	-	-	-	-	100nA	Top View	70mW	-	-	-40 °C to 85 °C [-40 °F to 185 °F]	-	The radiation source is a IRED with a peak wavelength of 935 nm.	20	-	3.94 x 3.94 x 6.35mm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Clear	14.0 mA	T-1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	100nA	-	-	40 µ A	20°	Top View	100nA	Radial	Through Hole	70mW	935nm	30V	30	clear	20 °	935	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	4	4...14 mA	14	-	-	-	4.0 mA/mW/cm² to 14.0 mA/mW/cm²	0.125 mW/cm²	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	20 °	6.35mm	3.94mm	1	2	15000ns	15000ns	3.94mm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
5 SD5410-003 Phototransistors Silicon PhtoDrlngton TO-46 Mtl/Gls LnsdPk Honeywell	询价	RoHS Compliant	75 us	+ 125 C	- 55 C	75 us	150 mW	Phototransistor	84 Days	1	TO-46-3 Metal Can	Lead free / RoHS Compliant	15 V	Photodetector Transistors	Photodarlington	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	150 mW	TO-46	15 V	1.1 V	Photodarlingtons	5 V	T0-46, Dome Lensed	250 nA	75 µs	8.0 mA	12°	Through Hole	NPN	TO-206-AB	Compliant	TO-46	3	-	30V	125	1.1	75000(Typ)	15	1	75000(Typ)	250	150	-55	Photodarlington	12	Phototransistors	100nA	Top View	150mW	8000(Min)	5	-55 °C to 125 °C [-67 °F to 257 °F]	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	12	-	-	-	-	-	-	-	-	-	-	-	-	-	-	8mA	*	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 SDP8476-201 Phototransistors .32mAPHOTOTRANSISTOR IR COMPONENT 20 deg Honeywell	询价	In Transition	15 us	+ 85 C	- 40 C	15 us	70 mW	Phototransistor	84 Days	1	Radial	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Low Light Rejection Phototransistor	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	70 mW	T-1	30 V	0.4 V	Phototransistors	5 V	T1	100 nA	15 µs	1.0 mA	20°	Through Hole	NPN	T-1	Compliant	T-1	2	935nm	30V	85	0.4	15000(Typ)	30	1	15000(Typ)	100	100	-40	Phototransistor	20	Phototransistors	100nA	Side View	100mW	-	-	-	Through Hole	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	6mA	*	-	Clear	6.0 mA	-	-	-	-	-	-	-	-	-	-	935	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	40 µ A	-	-	-	-	-	-	-	-	30	clear	20 °	935	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.0 mA/mW/cm² to 6.0 mA/mW/cm²	0.125 mW/cm²	6 mA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	480-1959	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
8 SDP8105-001 Phototransistors 10kOhm PULL UP TO-46 IR COMPONENT 12 deg Honeywell	询价	RoHS Compliant	75 us	+ 85 C	- 40 C	75 us	70 mW	Phototransistor	84 Days	1	Radial	Lead free / RoHS Compliant	15 V	Photodetector Transistors	Photodarlington	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	70 mW	T-1	15 V	1.1 V	Photodarlingtons	5 V	T1	250 nA	75 µs	0.5 mA	20°	Through Hole	NPN	T-1	Compliant	T-1	2	935nm	15V	85	1.1	75000(Typ)	15	1	75000(Typ)	250	70	-40	Photodarlington	20	Phototransistors	250nA	Top View	70mW	500(Min)	5	-40 °C to 85 °C [-40 °F to 185 °F]	Through Hole	The radiation source is a IRED with a peak wavelength of 935 nm.	20	0.5mA	0.25in.Hx0.125in.D	75us	20°	250nA	0.5in.(Min.)	T-1	70mW	85°C	-40°C	75us	NPN	15V	1.1V	-	-	-	Black	-	-	-	-	-	75µs	通孔安装	2	75µs	12.7mm	5.08 (Dia.) x 12.7mm	935	-	-	-	-	-	-	-	-	0.5mA	20 °	3mm (T-1)	250nA	-	-	-	250 nA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Black	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	红外	5.08mm	935nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
6 HOA1873-013 Optical Switches, Transmissive, Phototransistor Output Trnsmisve /Plstc Pkg Darlington Output Honeywell	询价	RoHS Compliant	75 us	+ 85 C	- 40 C	75 us	100 mW	Sensor Misc	84 Days	1	PCB Mount	Lead free / RoHS Compliant	15 V	Unamplified	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Through Hole	-	-	-	-	-	-	15V	-	-	-	-	-	-	-	-	-	-	-	Optical Switches, Transmissive, Phototransistor Output	-	-	-	-	-	-40°C ~ 85°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	30mA	HOA1873	-	-	-	-	THT	Bulk	NO	-	-	-	-	-	-	-	HOA1873-013	1	12 weeks	1	-	-	-	-	-	-	-	-	-	-	75µs	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Phototransistor	2.54 mm	1.52 mm	50 mA	Transmissive, Slotted	0.100" (2.54mm)	Photodarlington	-	-	-	-	-	-	-	-	-	-	-	-	-	-	30 mA	Through Hole	75µs	15°C	2.54mm	100mW	3V	75µs	1.52mm	RoHS-conform	20mA	50mA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
5 SDP8106-001 Phototransistors .5mA T1 BLK PLASTIC IR COMPONENT 20 deg Honeywell	询价	RoHS Compliant	75 us	+ 85 C	- 40 C	75 us	100 mW	Phototransistor	84 Days	1	Radial	Lead free / RoHS Compliant	15 V	Photodetector Transistors	Photodarlington	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	100 mW	Side Looker	15 V	1.1 V	Photodarlingtons	5 V	Side-Looking	250 nA	75 µs	1.0 mA	50°	Through Hole, Right Angle	NPN	Side Looker	Compliant	Side Looker	2	935nm	15V	85	1.1	75000(Typ)	15	1	75000(Typ)	250	100	-40	Photodarlington	50	Phototransistors	250nA	Side View	100mW	1000(Min)	5	-40 °C to 85 °C [-40 °F to 185 °F]	-	The radiation source is a IRED with a peak wavelength of 935 nm.	50	1mA	0.225in.Hx0.175in.W	75us	50°	250nA	0.5in.(Min.)	Side-LookingPlastic	100mW	85°C	-40°C	75us	NPN	15V	1.1V	-	-	0.02in.	Black	-	Side Looker	-	-	-	-	-	-	-	-	-	935	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Black	15 V	5 V	50 deg	Through Hole	-40C to 85C	935 nm	250 nA	1000 uA	1	Industrial	1.1 V	No	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Black	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
6 SDP8406-002 Phototransistors Silicon PhotoTrans Sd-looking Plstc Pkg Honeywell	询价	RoHS Compliant	15 us	+ 85 C	- 40 C	15 us	100 mW	Phototransistor	21 Days	1	Radial	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	100 mW	Side Looker	30 V	0.4 V	Phototransistors	5 V	Side-Looking	100 nA	15 µs	1.80 mA	50°	Through Hole, Right Angle	NPN	Side Looker	Compliant	Side Looker	2	880 nm	30V	85	0.4	15000(Typ)	30	1	15000(Typ)	100	100	-40	Phototransistor	50	Phototransistors	100nA	Side View	100mW	3600	5	-	-	-	-	1.8mA	0.225in.Hx0.175in.W	15us	50°	100nA	0.5in.(Min.)	Side-LookingPlastic	100mW	85°C	-40°C	15us	NPN	30V	0.4V	3.6mA	*	0.02in.	Clear	3.60 mA	Side Looker	SIDEVIEW	TUBE	NO	-	-	-	-	-	-	-	SDP8406-002	100	10 weeks	100	100°	1500ns	THT	4nA	-	-	-	-	800nm	940nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	30 V	5 V	50 deg	Through Hole	-40C to 85C	935 nm	100 nA	3600 uA	1	Industrial	0.4 V	No	880nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	85°C	-40°C	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
5 SDP8405-013 Phototransistors 0.37 mW/cm2 maximum OPEN COLLECTOR 50deg Honeywell	询价	In Transition	15 us	+ 85 C	- 40 C	15 us	70 mW	Phototransistor	84 Days	1	Radial	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	70 mW	T-1	30 V	0.4 V	Phototransistors	5 V	T1	100 nA	15 µs	0.32 mA	20°	Through Hole	NPN	T-1	Compliant	T-1	2	880 nm	30V	85	0.4	15000(Typ)	30	1	15000(Typ)	100	70	-40	Phototransistor	20	Phototransistors	100nA	Top View	70mW	920	5	-40 °C to 85 °C [-40 °F to 185 °F]	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	20	-	-	-	-	-	-	-	-	-	-	-	-	-	-	0.92mA	*	-	-	0.92 mA	T-1	-	-	-	-	-	-	-	-	-	935	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	20°	Top View	100nA	Radial	Through Hole	70mW	935nm	30V	-	-	-	-	Clear	30 V	5 V	20 deg	Through Hole	-40C to 85C	935 nm	100 nA	920 uA	1	Industrial	0.4 V	No	-	-	-	-	-	-	-	*	0.92mA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Clear	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
7 SD5491-004 Phototransistors Silicon PhotoTrans TO-18 Mtl Can Pkg Honeywell	询价	RoHS Compliant	2 us	+ 125 C	- 55 C	2 us	150 mW	Phototransistor	84 Days	1	TO-206AA, TO-18-3 Metal Can	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	150 mW	TO-18	30 V	0.4 V	Phototransistors	5 V	T0-18, Dome Lensed	100 nA	2.0 µs	4.0 mA	12°	Through Hole	NPN	TO-206-AA	Compliant	TO-18	3	880 nm	30V	125	0.4	2000(Typ)	30	1	2000(Typ)	100	150	-55	Phototransistor	12	Phototransistors	100nA	Top View	150mW	8000	5	-55 °C to 125 °C [-67 °F to 257 °F]	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	12	4mA	0.2in.Hx0.212in.Dia.	2us	12°	100nA	0.5in.(Min.)	TO-18	150mW	125°C	-55°C	2us	NPN	30V	0.4V	4mA	*	0.017in.	-	8.0 mA	T0-18, Dome Lensed	TO18	BULK	NO	2µs	通孔安装	3	2µs	17.77mm	4.06 (Dia.) x 17.77mm	935	-	-	-	-	5 °	15 ns	THT	16 nA	2mA	12 °	TO-18	100nA	-	-	-	-	-	-	-	12°	Top View	100nA	TO-206AA, TO-18-3 Metal Can	Through Hole	150mW	935nm	30V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	*	4MA	-	-	-	-	红外	4.06mm	880nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-55 °C	5 V	125 °C	150 nm	18 nm	RoHS-conform	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 HOA6971-N51 Optical Switches, Transmissive, Photo IC Output Opaque Optoschmitt No Mount Tab Honeywell	询价	RoHS Compliant	70 ns	+ 70 C	- 40 C	70 ns	100 mW	Photointerrupter	28 Days	1	PCB Mount	Lead free / RoHS Compliant	-	-	Optoschmitt Sensor	-40 °C to 70 °C [-40 °F to 158 °F]	Plastic	IR Switch	-	-	-	-	-	-	-	-	-	-	-	Through Hole	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Optical Switches, Transmissive, Photo IC Output	-	-	-	-	-	-40 °C to 70 °C [-40 °F to 158 °F]	-	Output is LO when incident light intensity is above the turn-on threshold level.	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Black	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	70ns	-	-	-	10 µA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Open Collector, Buffer	3.18 mm	1.27 mm, 0.25 mm	50 mA	Transmissive, Slotted	0.125" (3.18mm)	NPN - Open Collector, Buffer	-	70 ns	70 ns	3 V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.6 V	800 uA	2.4 V	12.8 mA	0.4 V	3 V	1,52 mm x 0,25 mm [0.060 in x 0.010 in]	Polysulfone, Opaque	1.0 second	4.5 V to 12.0 V	0.05	15 mA	No Mounting Tab	15 mA	Open-Collector	5.0 µs	Buffer	15 mA	15 mA	12.0 Vdc	15mA	4.5 V ~ 12 V	50 mA	5.0 µs	-	-	-	-
5 SD1440-004L Phototransistors Silicon PhotoTrans Mtl Can Coaxial Pkg Honeywell	询价	RoHS Compliant	15 us	+ 125 C	- 55 C	15 us	75 mW	Phototransistor	28 Days	1	Coaxial, Metal Can	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	75 mW	Metal Can	30 V	0.4 V	Phototransistors	5 V	Coaxial, Lead Case	100 nA	15 µs	6.0 mA	24°	Through Hole	NPN	TO-99	Compliant	Metal Can	2	935 nm	30V	125	0.4	15000(Typ)	30	1	15000(Typ)	100	75	-55	Phototransistor	24	Phototransistors	100nA	Top View	75mW	6000(Min)	5	-	Through Hole	-	-	1.5mA	0.062in.Dia.x0.122in.H	15us	-	100nA	1in.	CompactMetalCanCoaxialPackage	75mW	125°C	-55°C	15us	NPN	30V	-	-	-	0.02in.	-	-	-	METALL	BULK	NO	-	-	-	-	-	-	-	SD1440-004L	10	8 weeks	100	5°	15ns	THT	6nA	-	-	-	-	75nm	24nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	880nm	30V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	50 V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	935 nm	0.4V(Sat.)	-	-
8 SDP8405-003 Phototransistors PHOTOTRANSISTOR T1 Honeywell	询价	RoHS Compliant	15 us	+ 85 C	- 40 C	15 us	70 mW	Phototransistor	84 Days	1	Radial, 3mm Dia (T-1)	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	70 mW	T-1	30 V	0.4 V	Phototransistors	5 V	T1	100 nA	15 µs	12.0 mA	20°	Through Hole	NPN	T-1	Compliant	T-1	2	880 nm	30V	85	0.4	15000(Typ)	30	1	15000(Typ)	100	70	-40	Phototransistor	20	Phototransistors	100nA	Top View	70mW	24000	5	-40 °C to 85 °C [-40 °F to 185 °F]	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	20	12mA	0.25in.Hx0.125in.Dia.	15us	20°	100nA	0.5in.(Min.)	T-1	70mW	85°C	-40°C	15us	NPN	30V	0.4V	24mA	*	-	Clear	24.0 mA	T1	-	-	-	15000ns	通孔安装	2	15000ns	3.94mm	3.94 x 3.94 x 6.35mm	935	-	-	-	-	-	-	-	-	24000µA	20 °	3mm (T-1)	100nA	-	-	-	-	6.35mm	3.94mm	-	20°	Top View	100nA	Radial, 3mm Dia (T-1)	Through Hole	70mW	935nm	30V	30	clear	20 °	935	Clear	-	-	-	-	-	-	-	-	-	-	-	-	-	-	NPN	1	12	12...24 mA	24	*	24mA	-	-	-	24 mA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	935nm	-
8 SDP8406-003 Phototransistors PHOTOTRANSISTOR SIDE VIEW Honeywell	询价	RoHS Compliant	15 us	+ 85 C	- 40 C	15 us	100 mW	Phototransistor	21 Days	1	Radial	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-40 °C to 85 °C [-40 °F to 185 °F]	Plastic	IR Component	100 mW	Side Looker	30 V	0.4 V	Phototransistors	5 V	Side-Looking	100 nA	15 µs	3.40 mA	50°	Through Hole, Right Angle	NPN	Side Looker	Compliant	Side Looker	2	880 nm	30V	85	0.4	15000(Typ)	30	1	15000(Typ)	100	100	-40	Phototransistor	50	Phototransistors	100nA	Side View	100mW	6500	5	-	-	-	-	1.8mA	0.225in.Hx0.175in.W	15us	50°	100nA	0.5in.(Min.)	Side-LookingPlastic	100mW	85°C	-40°C	15us	NPN	30V	0.4V	6.5mA	*	0.02in.	Clear	6.50 mA	Side Looker	SIDEVIEW	INDIVIDUAL	NO	-	-	-	-	-	-	-	SDP8406-003	1	11 weeks	100	5°	15ns	THT	3.4nA	-	-	-	-	100nm	50nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	30 V	5 V	50 deg	Through Hole	-40C to 85C	935 nm	100 nA	6500 uA	1	Industrial	0.4 V	No	880nm	30V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 SD5443-002 Phototransistors Silicon PhotoTrans TO-46 Mtl/Gls LnsdPk Honeywell	询价	RoHS Compliant	15 us	+ 125 C	- 55 C	15 us	150 mW	Phototransistor	33 Days	1	TO-46-3 Metal Can	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	150 mW	TO-46	30 V	0.4 V	Phototransistors	5 V	T0-46, Dome Lensed	100 nA	15 µs	4.0 mA	18°	Through Hole	NPN	TO-206-AB	Compliant	TO-46	3	880 nm	30V	125	0.4	15000(Typ)	30	1	15000(Typ)	100	150	-55	Phototransistor	18	Phototransistors	100nA	Top View	150mW	4000(Min)	5	-	Through Hole	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	4mA	*	-	-	-	-	TO46	INDIVIDUAL	NO	-	-	-	-	-	-	-	SD5443-002	100	11 weeks	100	5°	15ns	THT	4nA	-	-	-	-	150nm	18nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	880nm	30V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
9 SMD2440-001 Phototransistors Glass Lens Phototransistor Honeywell	询价	RoHS Compliant	15 us	+ 125 C	- 55 C	15 us	125 mW	Interface Misc	42 Days	100	2-SMD, No Lead	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-55 °C to 125 °C [-67 °F to 257 °F]	Ceramic	IR Component	125 mW	CSMD	30 V	0.4 V	Phototransistors	5 V	Surface Mount (Glass Lens)	100 nA	15 µs	1.5 mA	28°	Surface Mount	-	CSMD	Compliant	CSMD	2	880 nm	30V	-	-	-	-	-	-	-	-	-	-	-	-	100nA	Top View	125mW	-	-	-55 °C to 125 °C [-67 °F to 257 °F]	No Lead	Bulk Packaged	28	1.5-4.0uA	-	15us	30°	-	-	-	-	-	-	-	-	-	-	-	-	-	-	4.0 mA	Surface Mount (Glass Lens)	SMD	Bulk	-	15µs	表面安装	2	15µs	3.8mm	3.8 x 2.5 x 2.1mm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	2.1mm	2.5mm	-	-	-	-	-	-	-	-	-	30	clear	28 °	880	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	1.5	1.5...4 mA	4	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	15 µs	15 µs	-	Ceramic	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Detector
7 SD1410-003L Phototransistors 24deg 4.0mA Coaxial Honeywell	询价	RoHS Compliant	75 us	+ 125 C	- 55 C	75 us	75 mW	Phototransistor	84 Days	1	Coaxial, Metal Can	Lead free / RoHS Compliant	15 V	Photodarlington	Photodarlington	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	75 mW	Metal Can	15 V	1.1 V	Photodarlingtons	5 V	Coaxial, Lead Case	250 nA	75 µs	4.0 mA	24°	Through Hole	NPN	TO-99	Compliant	Metal Can	2	880nm	15V	125	1.1	75000(Typ)	15	1	75000(Typ)	250	75	-55	Photodarlington	24	Phototransistors	250nA	Top View	75mW	4000(Min)	5	-55 °C to 125 °C [-67 °F to 257 °F]	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	24	4mA	0.091in.Hx0.079in.Dia.	75us	24°	250nA	1in.(Min.)	CompactMetalCanCoaxial	75mW	125°C	-55°C	75us	NPN	15V	1.1V	-	-	0.02in.	-	-	-	-	-	-	75000ns	通孔安装	2	75000ns	2.41mm	2.41 x 2.41 x 3.1mm	-	-	-	-	-	-	-	-	-	4000µA	24 °	金属罐	250nA	-	-	-	250 nA	3.1mm	2.41mm	40 µ A	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	NPN	1	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
4 SD2440-002 Phototransistors Silicon Phototransis Honeywell	询价	RoHS Compliant	15 us	+ 125 C	- 55 C	15 us	125 mW	Phototransistor	84 Days	1	Pill	Lead free / RoHS Compliant	30 V	Photodetector Transistors	Phototransistor	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	125 mW	Metal Can	30 V	0.4 V	Phototransistors	5 V	Miniature, Pill	100 nA	15 µs	2.0 mA	48°	PCB, Through Hole	NPN	TO-99	Compliant	Metal Can	2	880 nm	30V	125	0.4	15000(Typ)	30	1	15000(Typ)	100	125	-55	Phototransistor	48	-	100nA	Top View	125mW	2000(Min)	5	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	PILL	BULK	NO	-	-	-	-	-	-	-	SD2440-002	100	13 weeks	100	5°	15ns	THT	7nA	-	-	-	-	125nm	48nm	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	30V	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	Yes	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
5 SD3410-001 Phototransistors 3mA MINI, PILL 48deg IR COMPONENT Honeywell	询价	RoHS Compliant	75 us	+ 125 C	- 55 C	75 us	150 mW	Phototransistor	84 Days	1	TO-46-3 Lens Top Metal Can	Lead free / RoHS Compliant	15 V	Photodetector Transistors	Photodarlington	-55 °C to 125 °C [-67 °F to 257 °F]	Metal	IR Component	150 mW	TO-46	15 V	1.1 V	Photodarlingtons	5 V	T0-46, Flat Window	250 nA	75 µs	0.6 mA	90°	-	NPN	TO-206-AB	Compliant	TO-46	3	880nm	-	125	1.1	75000(Typ)	15	1	75000(Typ)	250	150	-55	Photodarlington	90	Phototransistors	-	-	-	600(Min)	5	-55°C ~ 125°C	Through Hole	The radiation source is a tungsten lamp operating at a color temperature of 2870°K.	90	0.6mA	0.153in.Hx0.219in.Dia.	75us	90°	250nA	0.5in.(Min.)	TO-46	150mW	125°C	-55°C	75us	NPN	15V	1.1V	-	-	0.018in.	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	75µs	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	250nA	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-	-
