同轴电缆组件（RF）
Alpha Wire Corporation- 同轴电缆组件（RF）
同轴电缆组件（RF） - 型号列表
共 712 个型号| 制造商零件编号 | 库存 | 价格 | 标准包装数量 | 导体绞线 | 颜色 | 长度 | 电缆类型 | 导线线规 | 导体材料 | 护套（绝缘）直径 | 护套（绝缘）材料 | 工作温度 | 阻抗 | 传播速度（VoP） | 屏蔽类型 | 屏蔽覆盖率 | 屏蔽材料 | 绝缘直径 | 介电材料 | 导体数量 | 重量 | 线缆护套颜色 | 外径 | SVHC | 海关税号 | 外径（标称值） | 总长度 | 线规或范围 - AWG | RoHS | 电缆组 | 包装方式 | 产品类别 | 额定电压 | 连接器阻抗 | 屏蔽 | 电缆对数 | 系列 | 用途 | 产品特性 | 最高温度限值 | 位置/触点数量 | 标准包装规格 | 电压 | 导体绝缘 | 护套（绝缘）厚度 | 核心类型 | 电容 | 典型衰减 | 连接器类型 - 电压输入 | 电缆长度 | 连接器颜色 | 绝缘材料 - 类型 | 位数 | 减速比 | 核心数/总线宽度 |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Coaxial Cables 22AWG 1C SHIELD 500ft SPOOL BLACK CBL COAX 59U 22AWG BK 500' Cable; Coaxial; 22 AWG; Solid CW; 0.242 in.; PVC; 95% BC Braid; Solid PE; Black; 152m CABLE, COAX, RG59/U, BLACK, 152.4M Alpha Wire | 10 | 1: ¥1,123.44 | 1 | Solid | Black | 500 ft | Coaxial | 22 | Copper | 0.242" (6.15mm) | Polyvinyl Chloride - PVC | -20°C ~ 60°C | 73 Ohms | 66 | Braid | 95% | Copper, Bare | 0.146" (3.71mm) | Solid Polyethylene (PE) | :1 x 0.643mm | 21 lbs | Black | 0.242 in | :No SVHC (20-Jun-2013) | 85442000 | :6.15mm | :500ft | :22AWG | RoHS Compliant | RG-59 | Spool | Coaxial Cables | 30 V | 59/U | Shielded | Solid | 9059C | Network | - | 60 C | 1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Coaxial Cables 23AWG 1C SHIELD 1000ft SPOOL BLACK CBL COAX 59B/U 22AWG BK 1K' Cable; Coaxial; 23 AWG; Solid CW; 0.242 in.; PVC-NC (Type II); 95% BC Braid; 304m CABLE, COAX, RG59B/U, BLACK, 304.8M Manhattan-Electrical-Cables, Coaxial, 1 Coax, 23 AWG, Braid, 1700 V, PVC Jacket, 0.242 Jacket Diameter, 0.034 Jacket Thickness, 0.146 Core Diameter, Solid Alpha Wire | 26 | 1: ¥15,938.928 | 1 | Solid | Black | 1000 ft | Coaxial | 23 | Copper Coated Steel | 0.242" (6.15mm) | Polyvinyl Chloride - PVC | -20°C ~ 60°C | 75 Ohms | 66 | Braid | 94% | Copper, Bare | 0.146" (3.71mm) | Solid Polyethylene (PE) | :1 x 0.573mm | 40 lbs | Black | :6.15mm | :No SVHC (20-Jun-2013) | 85442000 | :6.15mm | :1000ft | :23AWG | RoHS Compliant | RG-59B | Spool | Coaxial Cables | 2.3 kV | RG59 B / U | Shielded | Solid | 9059B | Network | - | - | - | 1 | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Coaxial Cables 20AWG 1C SHIELD 500ft SPOOL BLACK CABLE COAX 58/U 20AWG BK 500' Cable; Coaxial; 20 AWG; Solid; 0.195 in.; PVC; 95% TC Braid; Solid PE; Black; 152m CABLE, COAX, RG58/U, BLACK, 152.4M Alpha Wire | 31 | 1: ¥1,860.9764 | 1 | Solid | Black | 500 ft | Coaxial | 20 | Bare Copper | 0.195" (4.95mm) | Polyvinyl Chloride (PVC) | -20°C ~ 60°C | 53.5 Ohms | 66 | Braid | 95% | Copper, Tinned | 0.033" (0.84mm) | Solid Polyethylene (PE) | :1 x 0.813mm | 15 lbs | Black | 0.195 in | :No SVHC (20-Jun-2013) | 85442000 | :4.95mm | :500ft | :20AWG | RoHS Compliant | RG-58 | Spool | - | 1.4 kV | RG-58/U | Shielded | Solid | - | Network | - | + 60 C | 1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
Coaxial Cables 20AWG 1C SHIELD 100ft SPOOL BLACK CABLE COAX 58/U 20AWG BK 100' Cable; Coaxial; 20 AWG; Solid; 0.195 in.; PVC; 95% TC Braid; Solid PE; Black; 30m CABLE, COAX, RG58/U, BLACK, 30.5M Alpha Wire | 10 | 1: ¥802.196 | 1 | Solid | Black | 100 ft | Coaxial | 20 | Bare Copper | 0.195" (4.95mm) | Polyvinyl Chloride (PVC) | -20°C ~ 60°C | 53.5 Ohms | 66 | Braid | 95% | Copper, Tinned | 0.033" (0.84mm) | Solid Polyethylene (PE) | :1 x 0.813mm | 3 lbs | Black | 0.195 in | :No SVHC (20-Jun-2013) | 85442000 | :4.95mm | :100ft | :20AWG | RoHS Compliant | RG-58 | Spool | - | 1.4 kV | RG-58/U | Shielded | Solid | - | Network | - | + 60 C | 1 | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Coaxial Cables 22AWG 6PR UNSHLD 500ft SPOOL SLATE 5026C SLATE 500 FT Multi-Conductor Cables 22AWG 6PR UNSHLD 500ft SPOOL SLATE Alpha Wire | 10 | 1: ¥41.344 | 1 | 7/30 | Slate | 500 ft | Multi-Pair | 22 AWG | Tinned Copper | 0.316" (8.03mm) | Polyvinyl Chloride - PVC | -30°C ~ 105°C | - | - | - | - | - | - | - | 12 (6 Pair Twisted) | 53 lbs | Gray / Black | 0.032 in | - | - | - | - | - | RoHS Compliant | - | Spool | Coaxial Cables | 300 V | 26 / C | Unshielded | 7 x 30 | 5026C | - | Rip Cord | + 80 C | - | - | 300V | Poly-Vinyl Chloride (PVC) | 0.032" (0.81mm) | - | - | - | - | - | - | - | - | - | - |
Coaxial Cables 22AWG 1C SHIELD 1000ft SPOOL BLACK CBL COAX 62A/U 22AWG BK 1K' Cable; Coaxial; 22 AWG; Solid CW; 0.242 in.; PVC; 95% BC Braid; SSP; Black; 304m Coaxial Cable 1Conductors 22AWG Black 750V CABLE, COAX, RG62A/U, BLACK, 304.8M Alpha Wire | 10 | 1: ¥2,120.04 | 1 | Solid | Black | 1000 ft | Coaxial | 22 | Copper Coated Steel | 0.242" (6.15mm) | Polyvinyl Chloride - PVC | -20°C ~ 80°C | 93 Ohms | 83 | Braid | 95% | Copper, Bare | 0.146" (3.71mm) | Solid Polyethylene (PE) | :1 x 0.643mm | 40 lbs | Black | :6.15mm | :No SVHC (20-Jun-2013) | 85442000 | :6.15mm | :1000ft | :22AWG | RoHS Compliant | RG-62A | Spool | Coaxial Cables | 750 V | RG62 A / U | Shielded | Solid | 9062AC | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 Coaxial Cables 10AWG 1C SHIELD 100ft SPOOL BLACK CABLE COAX 217/U 10AWG BK 100' Cable; Coaxial; 10 AWG; 0.545 in.; Double C Braid; Solid Polyethylene; Black; 30m CABLE, COAX, RG217/U, BLACK, 30.5M Alpha Wire | 10 | 1: ¥3,578.70 | 1 | :5.26mm² | Black | 100 ft | Coaxial | 10 | Copper | 0.545" (13.84mm) | Polyvinyl Chloride - PVC | -20°C ~ 60°C | 50 Ohms | 66 | Double Braid | 95% | Copper, Bare | 0.370" (9.40mm) | Solid Polyethylene (PE) | :1 x 2.59mm | 23 lbs | Black | :13.84mm | :No SVHC (20-Jun-2013) | 85442000 | :13.84mm | :100ft | :10AWG | RoHS Compliant | RG-217 | Spool | Coaxial Cables | - | RG217 / U | Shielded | Solid | 9217 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 INDUST TWINAX 18AWG 1PAIR 1000' INDUST TWINAX 18AWG 1PAIR 1000' Industrial Twinax 600V Cable 305m CABLE, TWINAX, 18AWG, 304.8M Alpha Wire | 12 | 1: ¥4,803.8872 | 1 | 7 Strands / 30 AWG | Blue | 1000' (304.8m) | Twinaxial | 18 AWG (0.90mm²) | Copper, Tinned | 0.324" (8.23mm) | Poly-Vinyl Chloride (PVC) | +75°C | 78 Ohm | 65 | Foil, Braid | 100%, 55% | Flexfoil®, Copper, Tinned | 0.096" (2.44mm) | - | :7 x 26AWG | 32.6 | :Blue | :8.23mm | :No SVHC (16-Dec-2013) | 85444920 | 8.23mm | :1000ft | 0.4 mm | Compliant | - | - | - | :600V | - | - | - | - | - | 20 AWG Drain Wire | - | - | - | - | - | - | 7/0.4 mm | 63.96 pF/m | 10.7dB/100ft@400 MHz, 3.8dB/100ft@50 MHz, 5.4dB/100ft@100 MHz, 7.6dB/100ft@200 MHz | :- | 305m | Blue | PP | :1 | 0.65 | 7 |
 CBL 1COAX 30AWG BLK 100' CBL 1COAX 30AWG BLK 100' Coaxial Cables 30AWG (7/38) SHIELD 100FT SPOOL BLACK Alpha Wire | 10 | 6: ¥514.012 | 1 | 7 Strands / 38 AWG | Black | 100' (30.5m) | Coaxial | 30 AWG (0.05mm²) | Copper, Tinned | 0.097" (2.46mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 60°C | 75 Ohm | 78 | Braid | 89% | Copper, Tinned | 0.058" (1.47mm) | Cellular (Foam) Polyethylene (Cellular FPE) | - | - | - | - | - | - | - | - | - | RoHS Compliant | - | Spool | Coaxial Cables | - | - | - | - | - | - | Miniature | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 CABLE COAX TWINAX 22AWG BK 100' CABLE COAX TWINAX 22AWG BK 100' CABLE, TWINAX, VIDEO, BLACK, 30.5M Alpha Wire | 10 | 1: ¥609.892 | 1 | 19 Strands / 34 AWG | Black | 100' (30.5m) | Twinaxial | 22 AWG | Copper, Tinned | 0.329" (8.36mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 60°C | 150 Ohm | 78 | Foil | 100% | Aluminum | 0.120" (3.05mm) | Cellular (Foam) Polyethylene (Cellular FPE) | :19 x 0.16mm | 1 | :Black | :21.3mm | :No SVHC (20-Jun-2013) | 85442000 | :21.3mm | :100ft | :22AWG | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 CABLE COAX 55B/U 20AWG BK 100' CABLE COAX 55B/U 20AWG BK 100' CABLE, COAX, RG55B/U, BLACK, 30.5M Alpha Wire | 10 | 1: ¥1,331.82 | 1 | Solid | Black | 100' (30.5m) | Coaxial | 20 AWG | Copper, Silver Coated | 0.201" (5.11mm) | Polyethylene (PE) | -55°C ~ 80°C | 53.5 Ohm | 66 | Braid | 95% | Copper, Tinned | 0.116" (2.95mm) | Solid Polyethylene (PE) | :1 x 0.813mm | 1 | :Black | :5.23mm | :No SVHC (20-Jun-2013) | 85442000 | :5.23mm | :100ft | :20AWG | - | RG-55B | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
CBL 1COAX 30AWG BLK 500' CBL 1COAX 30AWG BLK 500' Coaxial Cables 30AWG (7/38) SHIELD 500FT SPOOL BLACK Alpha Wire | 10 | 9: ¥2,359.26 | 1 | 7 Strands / 38 AWG | Black | 500' (152.44m) | Coaxial | 30 AWG (0.05mm²) | Copper, Tinned | 0.097" (2.46mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 60°C | 75 Ohm | 78 | Braid | 89% | Copper, Tinned | 0.058" (1.47mm) | Cellular (Foam) Polyethylene (Cellular FPE) | - | - | - | - | - | - | - | - | - | RoHS Compliant | - | Spool | Coaxial Cables | - | - | - | - | - | - | Miniature | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 CBL COAX 62A/U 22AWG BK 1K' CBL COAX 62A/U 22AWG BK 1K' CABLE, COAX, RG62A/U, BLACK, 304.8M Alpha Wire | 10 | 1: ¥2,219.70 | 1 | Solid | Black | 1000' (304.8m) | Coaxial | 22 AWG (0.32mm²) | Steel, Copper Coated | 0.242" (6.15mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 80°C | 93 Ohm | 84 | Braid | 95% | Copper, Tinned | 0.146" (3.71mm) | Solid Polyethylene (PE) | :1 x 0.643mm | 1 | :Black | :6.15mm | :No SVHC (20-Jun-2013) | 85442000 | :6.15mm | :1000ft | :22AWG | - | RG-62A | - | - | - | - | - | - | - | - | - | - | - | 1 | - | - | - | - | - | - | - | - | - | - | - | - | - |
CBL 1COAX 30AWG BLK 1000' CBL 1COAX 30AWG BLK 1000' Coaxial Cables 30AWG (7/38) SHIELD 1000FT SPOOL BLACK Alpha Wire | 10 | 1: ¥2,440.248 | 1 | 7 Strands / 38 AWG | Black | 1000' (304.8m) | Coaxial | 30 AWG (0.05mm²) | Copper, Tinned | 0.097" (2.46mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 60°C | 75 Ohm | 78 | Braid | 89% | Copper, Tinned | 0.058" (1.47mm) | Cellular (Foam) Polyethylene (Cellular FPE) | - | - | - | - | - | - | - | - | - | RoHS Compliant | - | Spool | Coaxial Cables | - | - | - | - | - | - | Miniature | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 CBL COAX 59U 22AWG RED 1K' CBL COAX 59U 22AWG RED 1K' CABLE, COAX, RG59/U, RED, 304.8M Alpha Wire | 10 | 1: ¥2,083.80 | 1 | Solid | Red | 1000' (304.8m) | Coaxial | 22 AWG (0.32mm²) | Steel, Copper Coated | 0.242" (6.15mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 60°C | 75 Ohm | 66 | Braid | 95% | Copper, Bare | 0.146" (3.71mm) | Solid Polyethylene (PE) | :1 x 0.643mm | 1 | :Red | :6.15mm | :No SVHC (20-Jun-2013) | 85442000 | :6.15mm | :1000ft | :22AWG | - | RG-59 | - | - | - | - | - | - | - | Network | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
CABLE COAX 11A/U 18AWG BK 500' CABLE COAX 11A/U 18AWG BK 500' Coaxial Cables 18AWG PVC 500FT SPOOL BLACK Alpha Wire | 10 | 2: ¥5,203.70 | 1 | 7 Strands / 26 AWG | Black | 500' (152.44m) | Coaxial | 18 AWG | Copper, Tinned | 0.405" (10.29mm) | Poly-Vinyl Chloride (PVC) | -30°C ~ 80°C | 75 Ohm | 66 | Braid | 95% | Copper, Bare | 0.285" (7.24mm) | Solid Polyethylene (PE) | - | - | - | - | - | - | - | - | - | RoHS Compliant | RG-11A | - | Coaxial Cables | 5 kV | RG-11A/U | Shielded | - | 9011A | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
CABLE PAIR TWINAX 20AWG BK 1K' CABLE PAIR TWINAX 20AWG BK 1K' CABLE, TWINAX, VIDEO, BLACK, 304.8M Alpha Wire | 10 | 1: ¥3,159.62 | 1 | 7 Strands / 28 AWG | Black | 1000' (304.8m) | Twinaxial | 20 AWG | Copper, Tinned | 0.330" (8.38mm) | Poly-Vinyl Chloride (PVC) | -20°C ~ 80°C | 100 Ohm | 66 | Braid | 85% | Copper, Tinned | 0.083" (2.11mm) | Solid Polyethylene (PE) | :7 x 0.32mm | 1 | :Black | :8.3mm | :No SVHC (20-Jun-2013) | 85442000 | :8.3mm | :1000ft | :20AWG | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
.jpg){kind=small} CABLE COAX 55B/U 20AWG BK 1K' CABLE COAX 55B/U 20AWG BK 1K' CABLE, COAX, RG55B/U, BLACK, 304.8M Alpha Wire | 10 | 1: ¥6,338.212 | 1 | Solid | Black | 1000' (304.8m) | Coaxial | 20 AWG | Copper, Silver Coated | 0.201" (5.11mm) | Polyethylene (PE) | -55°C ~ 80°C | 53.5 Ohm | 66 | Braid | 95% | Copper, Tinned | 0.116" (2.95mm) | Solid Polyethylene (PE) | :1 x 0.813mm | 1 | :Black | :5.23mm | :No SVHC (20-Jun-2013) | 85442000 | :5.23mm | :1000ft | :20AWG | - | RG-55B | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
CABLE COAX 59/U 20AWG BK 1K' CABLE COAX 59/U 20AWG BK 1K' CABLE, COAX, RG59/U, BLACK, 304.8M Alpha Wire | 10 | 1: ¥8,027.16 | 1 | Solid | Black | 1000' (304.8m) | Coaxial | 20 AWG | Steel, Copper Coated | 0.212" (5.38mm) | Polyvinylidene Fluoride (PVDF) | -10°C ~ 125°C | 75 Ohm | 82 | Foil, Braid | 100%, 94% | Aluminum; Copper, Tinned | 0.140" (3.56mm) | Fluorinated Ethylene-Propylene (FEP®) | :1 x 0.813mm | 1 | :Black | :5.4mm | :No SVHC (20-Jun-2013) | 85442000 | :5.4mm | :1000ft | :20AWG | - | RG-59 | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
 CABLE PAIR TWINAX 20AWG BLU 1K' CABLE PAIR TWINAX 20AWG BLU 1K' CABLE, TWINAX, BLUE, 304.8M Alpha Wire | 10 | 1: ¥10,065.66 | 1 | 7 Strands / 28 AWG | Black | 1000' (304.8m) | Twinaxial | 20 AWG | Copper, Tinned | 0.198" (5.03mm) | Fluorinated Ethylene-Propylene (FEP) | -70°C ~ 200°C | 78 Ohm | 69.5 | Braid | 95% | Copper, Tinned | 0.074" (1.88mm) | Fluorinated Ethylene-Propylene (FEP®) | :1 x 0.813mm | 1 | :Blue | :5.1mm | :No SVHC (20-Jun-2013) | 85442000 | :5.1mm | :1000ft | :20AWG | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - | - |
