Panasonic
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| Capacitance | 0.01F |
| Construction | Snap-In |
| Diameter | 25mm |
| Dimensions | 25 Dia. x 40mm |
| Equivalent Series Resistance | 0.05Ω |
| Height | 40mm |
| Lead Diameter | 0.8mm |
| Lead Pitch | 10mm |
| Lifetime | 3000h |
| Maximum Operating Temperature | +85°C |
| Minimum Operating Temperature | -40°C |
| Mounting Type | Through Hole |
| Ripple Current | 4.42A |
| Tolerance | ±20% |
| Tolerance Minus | -20% |
| Tolerance Plus | +20% |
| Voltage | 35 V dc |
| Product Range | :PANASONIC - TS-UP Series |
| Capacitance Tolerance | :± 20% |
| Voltage Rating | :35V |
| ESR | :0.05ohm |
| Lead Spacing | :10mm |
| Life Time @ Temperature | :3000 hours @ 85°C |
| Operating Temperature Min | :-40°C |
| Operating Temperature Max | :85°C |
| External Length / Height | :40mm |
| Leakage Current | :1774.8µA |
| No. of Pins | :2 |
| Operating Lifetime | :3000h |
| Operating Temperature Range | :-40°C to +85°C |
| PCB Hole Diameter | :2mm |
| Ripple Current AC | :4.42A |
| Ripple Current Frequency | :120Hz |
| Ripple Current Temperature | :85°C |
| Series | :TSUP |
| Tolerance + | :20% |
| Tolerance - | :20% |
| Voltage Rating V DC | :35V |
| Weight (kg) | 0.034 |
| Tariff No. | 85322200 |
