| Type | Description |
|---|---|
| Display Type | LCD |
| Measuring Range | 4 ~ 20mA |
| Mounting Type | Panel Mount, Rear Mounting Clip |
| Display Characters - Height | 0.750" (19.05mm) |
| Display Style | Black Characters, Grey Background |
| Type | Process Meter |
| Display Digits | 3.5 |
| Calibration | Required Periodically |
| Temperature Coefficient | 100ppm/°C |
| Operating Temperature | 0°C ~ 50°C |
| Voltage - Supply | 4 ~ 20mA, Loop Power |
| Panel Cutout Dimensions | Rectangular - 72.00mm x 40.00mm |
| Standard Package | 1 |
| Termination | Screw Terminals |
| Accuracy | 0.05% + 1 digit |
| Display Face Size | 2.99" W x 1.73" H (76.0mm x 44.0mm) |
