Bulgin
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品种类 | Fuse Holders |
| RoHS | RoHS Compliant |
| 产品 | Fuse Holders |
| 额定电流 | 10 A |
| 额定电压 | 50 V |
| 极数 | 1 |
| 系列 | FX0 |
| 安装风格 | In-Line |
| 工作温度范围 | - 20 C to + 70 C |
| 颜色 | Clear, Black |
| 照明 | No |
| 工厂包装数量 | 100 |
| 电压 | 50V |
| 安装类型 | Free Hanging In Line |
| 保险丝座型 | Holder |
| 保险丝规格 | 5mm x 20mm |
| 端接类型 | Wire Leads |
| 触点表面涂层 | Nickel |
| 保险丝类型 | Cartridge |
| 配用/相关产品 | 5mm x 20mm |
| 标准包装 | 100 |
| 电路数 | 1 |
| 其他名称 | 708-1430 |
| 触点材料 | Brass |
| RoHS指令 | Lead free / RoHS Compliant |
| 阀体材质 | Nylon, Polybutene |
| 国际保护等级 | IP66 |
| 保护类别 | PC1 |
| Voltage Rating V DC | :250V |
| Voltage Rating V AC | :250V |
| Fuse Current | :10A |
| 保险丝座型 | :Fuse Holder |
| Holder Terminals | :Screw |
| No. of Fuses | :1 |
| Fuse Size Held | :5mm x 20mm |
| Fuse Size Metric | :5mm x 20mm |
| Fuse Size Imperial | :0.2" x 0.79" |
| 主体直径 | :16.5mm |
| External Length / Height | :79.2mm |
| IP / NEMA Rating | :IP66 |
| Operating Temperature Max | :70°C |
| Operating Temperature Min | :-20°C |
| Weight (kg) | 0.006 |
| Tariff No. | 85369010 |
| Multiplicity | 1 |
| Flammability rating | UL94V-0 |
| Body dimensions | Ø16.5 x 79.2mm |
| Fuses application | tube fuses |
| Maximum current | 10A |
| 额定电压 | 50V |
| Fuse size | 5x20mm |
| Body material | polybutane |
| Gross weight | 8.1 g |
| Operating temperature | -20...70°C |
| 安装 | in-line |
| Fuse accessories type | fuse holder |
| Collective package [pcs] | 100 |
| 密封 | IP66 |
| spg | 100 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
