Vishay/Sprague
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 产品种类 | Aluminum Electrolytic Capacitors - Leaded |
| RoHS | RoHS Compliant |
| 电容 | 10 uF |
| 容差 | - 10 %, + 75 % |
| 额定电压 | 50 V |
| 工作温度范围 | - 40 C to + 105 C |
| 端接类型 | Axial |
| 表壳直径 | 0.322 in |
| 表壳长度 | 0.723 in |
| 产品 | High Temp Electrolytic Capacitors |
| 系列 | TE |
| 工厂包装数量 | 1 |
| 引线直径 | 0.811 |
| 产品长度 | 18.364(Max) |
| 欧盟RoHS指令 | Compliant |
| 最高工作温度 | 105 |
| Leakage Current | 15 |
| 安装 | Through Hole |
| 寿命 | 2000 |
| 电容值 | 10uF |
| 电压 | 50VDC |
| 类型 | Electrolytic |
| Product Diameter | 8.179(Max) |
| RoHS指令 | Compliant |
| 外形尺寸 | 0.322 in Dia. x 0.723 in L |
| 负载寿命 | 2000 h |
| 电容公差 | :+75%, -10% |
| 直径 | :8.179mm |
| 身高 | :18.364mm |
| Capacitor Terminals | :Axial Leaded |
| Life Time @ Temperature | :2000 hours @ 85°C |
| Weight (kg) | 0.00159 |
| Tariff No. | 85322200 |
| CaseSize | 8.179mmDia.x18.364mmL |
| Material,Element | AluminumElectrolytic |
| 端子 | Axial |
| Voltage,Rating | 50VDC |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
