panasonic
所示图像仅为示意图。请从产品数据表中获得准确的规格。
| Type | Description |
|---|---|
| 封装/外壳 | 11.5(Max) X 10.5(Max) X 6.5(Max) |
| 安装 | Through Hole |
| 电容值 | 0.33 F |
| 电压 | 5.5 Vdc |
| 产品厚度 | 10.5(Max) mm |
| 产品长度 | 11.5(Max) mm |
| 引脚间距为径向 | 10 mm |
| 工作温度 | -25 to 70 °C |
| 结构 | Stacked Coin |
| 端接类型 | Radial |
| 容差 | -20 to 80 % |
| 标准包装 | Bulk |
| 电容 | 0.33F |
| 身高 | 6.5mm |
| 引线直径 | 0.8mm |
| 引线间距 | 10mm |
| 寿命 | 1000h |
| 最高工作温度 | +70°C |
| 最低工作温度 | -25°C |
| 安装类型 | Through Hole |
| 公差减 | -20% |
| 公差加 | +80% |
| RoHS指令 | Compliant |
| 电容公差 | :± 30% |
| 额定电压 | :5.5V |
| Capacitor Case Style | :Coin |
| Capacitor Terminals | :Radial Leaded |
| 引线间距 | :10mm |
| 血沉 | :75ohm |
| Operating Temperature Min | :-25°C |
| Operating Temperature Max | :70°C |
| 主体直径 | :10.5mm |
| Capacitor Mounting | :Through Hole |
| External Length / Height | :11.5mm |
| No. of Pins | :2 |
| 工作温度范围 | :-25°C to +70°C |
| 系列 | :SD |
| Weight (kg) | 0.01 |
| Tariff No. | 85322200 |
| Body dimensions | Ø10 x 6.5mm |
| Gross weight | 1.07 g |
| Capacitor type | electrolytic |
| Capacitor kind | backup capacitor, supercapacitor |
| Operating voltage | 5.5V |
| Multiplicity | 1 |
| Terminal pitch | 10mm |
| Collective package [pcs] | 100 |
| spg | 100 |
| RESOURCE TYPE | LINK |
|---|---|
| Datasheets |
|
